EMERSON 5X00875G01 | Analog Input Module | 5X00453G01

Description

Product Overview：EMERSON 5X00875G01

Technical Specifications：EMERSON 5X00875G01

Parameter Name	Parameter Value
Product Model	5X00875G01
Manufacturer	Emerson
Product Type	Analog Input Module
Channels	16 isolated channels
Input Types	4–20 mA, 0–10 V DC, RTD (3/4-wire), thermocouple (J/K/T/E/R/S/B types)
Resolution	16 bits
Accuracy	±0.05% of full scale
Isolation	250 V RMS galvanic isolation per channel
Power Supply	24 V DC ±10% (module-powered via backplane)
Physical Dimensions	177.8 mm (H) × 101.6 mm (W) × 76.2 mm (D)
Weight	0.9 kg
Operating Temperature	0°C to +60°C
Mounting	Rack-mounted in Ovation I/O chassis
Communication	Proprietary Ovation backplane protocol

EMERSON 5X00875G01

Key Features and Advantages：EMERSON 5X00875G01

Rugged Industrial Design: The module’s metal enclosure and conformal-coated circuitry protect against dust, moisture, and vibration, ensuring long-term reliability in harsh industrial settings. Its wide operating temperature range (0°C to +60°C) accommodates both indoor and outdoor installations.

EMERSON 5X00875G01

Application Areas：EMERSON 5X00875G01

• Power Generation: Monitors steam temperature, boiler pressure, and turbine vibration in thermal and nuclear power plants, enabling optimal load management and compliance with environmental regulations.
• Oil & Gas: Measures flow rates, tank levels, and pipeline pressures in refineries, offshore platforms, and pipeline networks, supporting real-time process optimization and leak detection.
• Chemical Processing: Controls reactor temperatures, pH levels, and solvent concentrations in batch and continuous production systems, ensuring product quality and safety.
• Water/Wastewater Treatment: Tracks water levels, chemical dosages, and effluent quality in treatment plants, optimizing pump efficiency and regulatory compliance.

• Closed-Loop Control: Provides feedback signals for PID controllers to maintain process variables within tight tolerances, such as maintaining constant pressure in a steam distribution system.
• Safety Instrumented Systems (SIS): Integrates with Emerson’s DeltaV SIS to provide analog inputs for emergency shutdown systems, ensuring rapid response to critical process deviations.
• Predictive Maintenance: Uses vibration and temperature data from RTDs and accelerometers to detect early signs of equipment degradation, such as bearing wear in rotating machinery.

By delivering accurate and timely analog data, the 5X00875G01 enhances operational visibility, reduces unplanned outages, and supports data-driven decision-making across industrial sectors.
