MERSON 5X00790G01 Product Specification
Product Overview ：EMERSON 5X00790G01
The EMERSON 5X00790G01 is a high-performance Ovation OCC100 controller module designed for critical industrial automation systems, particularly within Emerson’s Ovation DCS platform. As a cornerstone component of Emerson’s power and process control solutions, this module serves as the central processing unit (CPU) for distributed control systems, enabling real-time monitoring, data analysis, and decision-making in complex industrial environments. The EMERSON 5X00790G01 is engineered to handle advanced control algorithms, communication protocols, and integration with field devices, making it indispensable for industries such as power generation, oil and gas, and chemical processing.
Part of the Ovation OCC100 series, the EMERSON 5X00790G01 integrates a dual-core processor with 2 GB of RAM and 8 GB of flash memory, ensuring rapid execution of control logic and data storage. It supports redundant power supplies and communication interfaces, enhancing system reliability in mission-critical applications. The module’s compact design (178 mm × 102 mm × 254 mm) and rugged metal enclosure allow for easy integration into rack-mounted control panels while withstanding extreme temperatures (-40°C to +70°C) and vibration (5–500 Hz, 2 g), typical of industrial settings.
In automation architectures, the EMERSON 5X00790G01 acts as the brain of the control system, coordinating inputs from sensors, executing control strategies, and delivering outputs to actuators. Its compatibility with Emerson’s Ovation software suite enables engineers to configure control loops, perform diagnostics, and implement firmware updates remotely, reducing maintenance downtime. By combining robust hardware with flexible software integration, the EMERSON 5X00790G01 enhances operational efficiency, minimizes risks, and supports compliance with industry standards such as IEC 61131-3 for programmable logic controllers.
Technical Specifications ：EMERSON 5X00790G01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | EMERSON 5X00790G01 |
| Manufacturer | Emerson Electric Co. |
| Product Type | Ovation OCC100 Controller Module (CPU) |
| Processor | Dual-core 1.2 GHz ARM Cortex-A9 |
| Memory | 2 GB DDR3 RAM, 8 GB flash storage |
| Power Supply | 120/240 VAC ±10%, 50/60 Hz |
| Physical Dimensions | 178 mm (W) × 102 mm (H) × 254 mm (D) |
| Weight | 1.8 kg |
| Communication Protocols | Ovation proprietary bus, Modbus TCP, Profibus DP, Ethernet/IP |
| Redundancy Support | Dual power supplies, dual Ethernet ports |
| Operating Temperature | -40°C to +70°C |
| Vibration Resistance | 5–500 Hz, 2 g (IEC 60068-2-6) |
| Certifications | CE, UL, CSA, IEC 61131-3 |
EMERSON 5X00790G01
Main Features and Advantages ：EMERSON 5X00790G01
High-Performance Processing: The EMERSON 5X00790G01 features a dual-core processor and ample memory, enabling rapid execution of complex control algorithms and real-time data processing. This ensures precise regulation of critical processes, such as turbine speed control in power plants or chemical reactor optimization.
Redundant Architecture: With dual power supplies and communication ports, the module supports redundant configurations, minimizing the risk of system failures. This is particularly valuable in environments where continuous operation is essential, such as offshore oil platforms or nuclear power plants.
Flexible Communication: The module supports multiple industrial protocols (Modbus TCP, Profibus DP, Ethernet/IP), allowing seamless integration with third-party devices and legacy systems. This flexibility reduces the need for additional gateways, simplifying system architecture and lowering costs.
Advanced Diagnostics: Built-in self-test (BIST) functionality continuously monitors module health, including processor performance, memory usage, and communication status. Faults are reported via front-panel LED indicators and through the Ovation HMI, enabling proactive maintenance and reducing mean time to repair (MTTR).
Software-Defined Configuration: Configurable through Emerson’s Ovation engineering tools, the EMERSON 5X00790G01 supports user-defined control strategies, alarm thresholds, and data logging. Engineers can customize logic without hardware modifications, adapting the module to unique operational requirements.
EMERSON 5X00790G01
Application Areas ：EMERSON 5X00790G01
The EMERSON 5X00790G01 is widely used in industries where reliable and high-speed control is essential:
-
Power Generation:
- Steam/Gas Turbines: Controls turbine speed, fuel supply, and exhaust temperature in combined cycle power plants, optimizing energy efficiency and grid synchronization.
- Renewable Energy: Manages biomass or geothermal power systems, ensuring stable power output and compliance with environmental regulations.
-
Oil and Gas:
- Refineries: Coordinates distillation units, pumps, and compressors, maintaining precise flow rates and pressure levels.
- Offshore Platforms: Supports redundant control systems for safety interlocks and emergency shutdowns in harsh marine environments.
-
Chemical Processing:
- Reactor Control: Executes PID algorithms to maintain temperature, pressure, and chemical composition in reactors, ensuring product quality and process safety.
- Batch Manufacturing: Manages recipe-driven processes in pharmaceutical or specialty chemical production, enabling traceability and consistency.
-
Water and Wastewater Treatment:
- Pump Stations: Controls pump operation and water distribution networks, ensuring reliable supply and regulatory compliance.
- Wastewater Treatment: Monitors and adjusts treatment processes to meet discharge standards, reducing environmental impact.
EMERSON 5X00790G01
Related Products ：EMERSON 5X00790G01
- EMERSON 5X00846G01: An 8-channel HART interface module for connecting intelligent field devices, often used alongside the EMERSON 5X00790G01 for advanced process monitoring.
- EMERSON 5X00226G02: An I/O interface module that expands system connectivity, complementing the EMERSON 5X00790G01 in hybrid control systems.
- EMERSON PR6424/011-140: An eddy current sensor for vibration monitoring, integrated with the EMERSON 5X00790G01 in rotating machinery applications.
- EMERSON A6370D: An overspeed protection module that works in tandem with the EMERSON 5X00790G01 to ensure turbine safety in power generation.
- EMERSON KJ2231X1-EA1: A safety instrumented system (SIS) relay module for critical shutdown applications, enhancing the EMERSON 5X00790G01’s safety capabilities.
Installation and Maintenance ：EMERSON 5X00790G01
Pre-installation Preparation:
Before installing the EMERSON 5X00790G01, ensure the following:
Before installing the EMERSON 5X00790G01, ensure the following:
- Verify the power supply voltage matches the module’s specifications (120/240 VAC) and that the control rack is properly grounded to prevent electromagnetic interference (EMI).
- Use Emerson’s Ovation software to configure control logic, communication protocols, and redundancy settings before mounting the module in the rack.
- Ensure adequate clearance around the module for heat dissipation, especially in high-density I/O configurations.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Health” indicators). Replace faulty modules immediately to avoid cascading system failures.
- Firmware Updates: Periodically update the module’s firmware via Emerson’s Ovation software to address security patches or enhance compatibility with newer system versions.
- Environmental Checks: Clean dust and debris from the module’s vents quarterly, particularly in dusty environments, to prevent overheating. Monitor ambient temperature and humidity levels using the control system’s built-in sensors.
- Performance Monitoring: Use Ovation’s diagnostic tools to analyze processor load, memory usage, and communication latency, optimizing system performance proactively.
EMERSON 5X00790G01
Product Warranty ：EMERSON 5X00790G01
Our company provides a one-year quality warranty for the EMERSON 5X00790G01, covering all non-human-induced hardware defects. During the warranty period, any module exhibiting abnormal signal processing, power supply failures, or physical defects will be replaced at no cost. For discontinued models like the EMERSON 5X00790G01, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on technical data derived from Emerson’s official specifications and industry applications. For detailed operational guidelines, refer to the EMERSON 5X00790G01 user manual or contact our technical support team for personalized assistance.
