EMERSON 5X00453G01 | Analog Input Module | 5X00784G01

Description

Product Overview ：EMERSON 5X00453G01

Technical Specifications ：EMERSON 5X00453G01

Parameter Name	Parameter Value
Product Model	5X00453G01
Manufacturer	Emerson
Product Type	Analog Input Module
Channels	16 isolated channels
Signal Types	4–20 mA, 0–10 V DC, thermocouples (J/K/T/E/R/S/B), RTDs (2/3/4-wire)
Resolution	16-bit ADC
Accuracy	±0.05% of full scale
Isolation	Galvanic isolation (2500 V RMS) between channels and system ground
Power Supply	24 V DC ±10% (redundant inputs)
Physical Dimensions	100 mm (H) × 160 mm (W) × 60 mm (D)
Weight	0.8 kg
Mounting	DIN rail or rack-mounted (35 mm standard)
Operating Temperature	-40°C to +85°C

EMERSON 5X00453G01

Key Features and Advantages ：EMERSON 5X00453G01

Scalable Architecture: As part of the Ovation™ modular ecosystem, the 5X00453G01 can be combined with other I/O modules (e.g., digital inputs/outputs, communication gateways) to build scalable control systems, from small-scale installations to large industrial plants.

EMERSON 5X00453G01

Application Areas ：EMERSON 5X00453G01

• Power Generation: Monitors steam temperature, boiler pressure, and turbine load in thermal and nuclear power plants, supporting efficient energy production and grid stability.
• Oil & Gas: Measures flow rates, wellhead pressures, and process temperatures in refineries, pipelines, and offshore platforms, ensuring compliance with safety standards and optimizing production workflows.
• Chemical Processing: Controls reactor conditions, distillation column parameters, and material blending ratios in chemical plants, enhancing product quality and reducing waste.
• Water/Wastewater Treatment: Tracks 液位 (liquid level), pH levels, and dissolved oxygen concentrations in treatment facilities, enabling automated control of pumps, valves, and filtration systems.

• Process Control Loops: Provides feedback signals for PID controllers to maintain setpoints in critical processes like temperature regulation in furnaces or pressure control in pipelines.
• Environmental Monitoring: Integrates with sensors to measure emissions, air quality, or water purity, supporting regulatory compliance and sustainability initiatives.
• Machine Health Monitoring: Connects to vibration sensors or thermal imagers to detect early signs of equipment degradation, enabling predictive maintenance and reducing unplanned outages.


  EMERSON 5X00453G01

Related Products ：EMERSON 5X00453G01

1. 5X00452G01 Analog Output Module: Complements the 5X00453G01 by providing analog control signals to actuators and valves, forming a complete input/output control loop.
2. 5X00160G01 Digital Input Module: Expands the system’s capability to monitor discrete signals (e.g., switch states, alarm contacts) alongside analog data.
3. 5X00230G01 Communication Module: Enables integration with third-party systems via protocols like MODBUS or Profibus, enhancing the 5X00453G01’s interoperability in hybrid control environments.
4. 5X00485G01 Terminal Block: Simplifies field wiring by providing a centralized connection point for analog signals, reducing installation time and minimizing errors.
5. 5X00454G01 High-Speed Analog Input Module: Designed for applications requiring fast sampling rates (e.g., vibration analysis), offering complementary functionality to the standard 5X00453G01.
6. OVATION™ Controller Module: Works in tandem with the 5X00453G01 to execute control logic, providing a complete DCS solution for process automation.
7. 5X00120G01 Power Supply Module: Redundant 24 V DC power supply designed for Ovation™ systems, ensuring stable operation of the 5X00453G01 in demanding environments.
8. 5X00370G01 Alarm and Event Module: Enhances the 5X00453G01 by providing real-time alarm processing and event logging, improving operational visibility and response times.
