EMERSON 5X00419G02 Micro Motion Coriolis Flowmeter Electronics Module
Product Overview：EMERSON 5X00419G02
The EMERSON 5X00419G02 Micro Motion Coriolis flowmeter electronics module is a cutting-edge industrial device designed to deliver precise and reliable measurement of mass flow, density, and temperature in complex fluid systems. As part of Emerson’s Micro Motion series, this module serves as the brain of Coriolis flowmeters, converting sensor signals into accurate process data while ensuring seamless integration with automation systems. Engineered for high-performance environments, the 5X00419G02 is ideal for industries requiring stringent measurement accuracy, such as oil & gas, chemical processing, and food & beverage production.
Featuring advanced digital signal processing, the 5X00419G02 enhances the reliability of Coriolis flowmeters by filtering out noise and correcting for environmental fluctuations. Its 24V DC power input and compact design (229mm x 152mm x 102mm, 2.3 kg) make it suitable for both field-mounted and panel-mounted applications, while the -40°C to 60°C operating temperature range ensures durability in harsh conditions. The module supports HART, Modbus, and Foundation Fieldbus protocols, enabling real-time data transmission to distributed control systems (DCS) or supervisory control and data acquisition (SCADA) platforms.
In automation systems, the 5X00419G02 plays a critical role in optimizing process efficiency and quality control. By providing instantaneous measurements of mass flow and density, it helps operators monitor material usage, detect leaks, and ensure compliance with regulatory standards. The module’s built-in diagnostic tools offer real-time health checks, reducing downtime through predictive maintenance. Its rugged construction and IP67 protection rating further enhance its suitability for challenging industrial environments, where reliability is non-negotiable.
Technical Specifications：EMERSON 5X00419G02
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 5X00419G02 |
| Manufacturer | EMERSON |
| Product Type | Coriolis Flowmeter Electronics Module |
| Input Voltage | 24V DC (10–30V DC range) |
| Communication Protocols | HART 7, Modbus RTU, Foundation Fieldbus |
| Physical Dimensions | 229mm (H) x 152mm (W) x 102mm (D) |
| Weight | 2.3 kg |
| Operating Temperature | -40°C to 60°C |
| Humidity Resistance | 5–95% non-condensing |
| Protection Rating | IP67 |
| Mounting Type | Flange-mounted or panel-mounted |
| Country of Origin | United States |
| Accuracy | ±0.1% of reading for mass flow |
EMERSON 5X00419G02
Main Features and Advantages：EMERSON 5X00419G02
Unmatched Measurement Accuracy: The 5X00419G02 delivers ±0.1% accuracy in mass flow measurements, making it suitable for applications where precision is critical, such as batching, inventory management, and custody transfer. Its ability to measure density and temperature simultaneously reduces the need for additional sensors, simplifying system design.
Versatile Communication Options: With support for HART, Modbus, and Foundation Fieldbus, the module integrates seamlessly with both legacy and modern control systems. This flexibility allows for easy retrofitting in existing setups or deployment in cutting-edge smart factories, ensuring compatibility with diverse automation architectures.
Rugged and Reliable Design: The IP67 protection rating ensures the module is fully protected against dust and water immersion, making it suitable for outdoor or washdown environments. Its robust casing and wide temperature range (-40°C to 60°C) enable reliable operation in extreme climates, from arctic oil fields to tropical refineries.
Advanced Diagnostics: Built-in Smart Meter Verification technology allows operators to perform on-line health checks without interrupting the process. This feature identifies potential issues such as sensor degradation or process upsets, enabling proactive maintenance and reducing unplanned downtime.
Energy Efficiency: The module’s low power consumption (typically <10W) contributes to energy savings in large-scale operations. Its efficient design also minimizes heat generation, reducing the need for additional cooling systems in control panels.
EMERSON 5X00419G02
Application Areas：EMERSON 5X00419G02
The EMERSON 5X00419G02 Micro Motion Coriolis flowmeter electronics module is widely applied in industries that demand precise fluid measurement and process control:
- Oil & Gas: Used in upstream production for measuring wellhead flow, multiphase flow, and crude oil density. In downstream applications, it ensures accurate custody transfer measurements and monitors chemical injection rates in refineries.
- Chemical Processing: Ideal for measuring aggressive or high-viscosity fluids in batch reactors, distillation columns, and pipeline systems. The module’s accuracy supports precise formulation of chemical blends and compliance with environmental regulations.
- Food & Beverage: Ensures hygienic and accurate measurement of liquids such as dairy, juices, and edible oils. Its IP67 rating allows for easy cleaning in sanitary environments, meeting strict food safety standards.
- Pharmaceuticals: Critical for measuring raw materials and finished products in pharmaceutical manufacturing, where traceability and precision are essential. The module’s ability to measure density aids in quality control for drug formulation.
- Water & Wastewater: Monitors water treatment chemicals, sludge density, and effluent flow rates, supporting efficient water management and compliance with discharge regulations.
Related Products：EMERSON 5X00419G02
- EMERSON 5700 Series Flowmeters: Compatible with the 5X00419G02, these flowmeters offer a range of tube sizes and materials for diverse applications, from low-flow laboratory setups to high-pressure industrial pipelines.
- EMERSON 2700 Series Density Meters: Work in tandem with the 5X00419G02 to provide enhanced density measurement capabilities, particularly for slurry or two-phase flow applications.
- EMERSON 9700 Series Coriolis Flowmeters: High-performance models that integrate the 5X00419G02 for advanced features like multi-variable measurement and wireless connectivity.
- EMERSON XMT 3000 Transmitter: A versatile transmitter that can be paired with the 5X00419G02 to convert analog signals into digital outputs for integration with PLC or DCS systems.
- EMERSON CT4000 Temperature Sensor: Complementary sensor that enhances the 5X00419G02’s temperature measurement accuracy, suitable for high-temperature process environments.
- EMERSON DynaMass Flowmeters: Legacy models that use the 5X00419G02 as a replacement electronics module, offering retrofitting solutions for older Coriolis systems.
EMERSON 5X00419G02
Installation and Maintenance：EMERSON 5X00419G02
Pre-installation Preparations:
Before installing the 5X00419G02, ensure the power supply matches the 24V DC requirement and that the mounting location meets IP67 environmental standards. Clean the mounting surface and verify proper grounding to minimize electromagnetic interference. Attach the module to the flowmeter sensor using the provided flange or panel mounts, ensuring secure alignment. Connect the sensor cables to the module’s terminal blocks, following Emerson’s wiring diagrams to avoid polarity errors. Finally, configure the communication protocol (HART, Modbus, etc.) using Emerson’s Asset Management Software to match the control system’s requirements.
Before installing the 5X00419G02, ensure the power supply matches the 24V DC requirement and that the mounting location meets IP67 environmental standards. Clean the mounting surface and verify proper grounding to minimize electromagnetic interference. Attach the module to the flowmeter sensor using the provided flange or panel mounts, ensuring secure alignment. Connect the sensor cables to the module’s terminal blocks, following Emerson’s wiring diagrams to avoid polarity errors. Finally, configure the communication protocol (HART, Modbus, etc.) using Emerson’s Asset Management Software to match the control system’s requirements.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for signs of water ingress, loose connections, or physical damage. Use a dry cloth to clean the module’s exterior, especially in dusty or corrosive environments.
- Performance Calibration: Annually calibrate the module with Emerson’s Micro Motion Flow Calibration Services to ensure ongoing accuracy. This is particularly critical for custody transfer applications.
- Firmware Updates: Periodically update the module’s firmware via Emerson’s software to access new features and security patches, ensuring compatibility with evolving automation systems.
- Diagnostic Testing: Use the module’s built-in diagnostics to perform quarterly health checks, including sensor integrity and signal strength. Address any alerts promptly to prevent unexpected failures.
EMERSON 5X00419G02
Product Warranty：EMERSON 5X00419G02
Our company offers a 12-month quality warranty for the EMERSON 5X00419G02 Micro Motion Coriolis flowmeter electronics module, covering non-human-induced hardware defects. During the warranty period, we will replace any faulty module at no cost to ensure your system’s continuity. For discontinued models or urgent needs, our global supply chain network ensures rapid delivery of scarce spare parts, leveraging our 17 years of expertise in industrial control distribution.
We pride ourselves on providing not just products but comprehensive solutions, including technical support for installation, configuration, and troubleshooting. Whether you need assistance with protocol setup or predictive maintenance strategies, our team is dedicated to ensuring the 5X00419G02 delivers optimal performance in your application. Contact us today to explore how this module can enhance your process efficiency and measurement accuracy.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for Emerson’s official technical documentation. Always refer to the manufacturer’s guidelines for detailed installation and safety instructions.
