EMERSON 5X00226G04 Product Specification
Product Overview ：EMERSON 5X00226G04
The EMERSON 5X00226G04 is a high-performance Ethernet Link Controller Module designed for industrial automation systems, specifically engineered for seamless integration with Emerson’s Ovation Distributed Control System (DCS). As a core component of Emerson’s Power & Water Solutions portfolio, this module serves as a critical interface between field devices and higher-level control systems, enabling real-time data exchange and system monitoring across industries such as power generation, oil and gas, and manufacturing. The EMERSON 5X00226G04 is renowned for its robust design, advanced diagnostic capabilities, and compatibility with multiple communication protocols, making it an ideal choice for mission-critical applications requiring reliable and scalable automation solutions.
Engineered to support Modbus TCP, Ethernet/IP, and OPC UA protocols, the EMERSON 5X00226G04 ensures high-speed data transfer between field sensors, actuators, and the Ovation controller platform. Its dual Gigabit Ethernet ports enable redundant network configurations, enhancing system resilience against communication failures. The module’s compact form factor (220 mm x 160 mm x 80 mm) and DIN rail mounting facilitate easy installation in control cabinets, while its rugged construction (IP54-rated enclosure) ensures reliable operation in harsh industrial environments with temperatures ranging from -40°C to +70°C.
In automation architectures, the EMERSON 5X00226G04 acts as a bridge between legacy systems and modern IIoT platforms, providing seamless integration of third-party devices into the Ovation ecosystem. Its built-in security features, including encrypted data transmission and access control, comply with industry standards such as Achilles Level 1 certification, ensuring protection against cyber threats. By combining high-speed communication with advanced signal conditioning, the module empowers industries to optimize operational efficiency, reduce downtime, and achieve regulatory compliance.
Technical Specifications ：EMERSON 5X00226G04
| Parameter Name | Parameter Value |
|---|---|
| Product Model | EMERSON 5X00226G04 |
| Manufacturer | Emerson Electric Co. |
| Product Type | Ethernet Link Controller Module |
| Communication Protocols | Modbus TCP, Ethernet/IP, OPC UA, Profinet (via optional gateway) |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 220 mm (depth) × 160 mm (height) × 80 mm (width) |
| Weight | 1.2 kg |
| Redundancy Support | Dual Ethernet ports for redundant network configurations |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Installation | DIN rail mounting with integrated TP867 baseplate |
| Certifications | CE, UL, CSA, Achilles Level 1 |
| Interface Type | 6 x RJ45 Ethernet ports, 2 x RS-485 serial ports |
| Firmware Update | Remote firmware updates via Emerson AMS Suite |
EMERSON 5X00226G04
Main Features and Advantages ：EMERSON 5X00226G04
Multi-Protocol Connectivity: The EMERSON 5X00226G04 supports a wide range of industrial communication protocols, including Modbus TCP, Ethernet/IP, and OPC UA, allowing seamless integration of diverse field devices (e.g., PLCs, drives, and smart sensors) into the Ovation DCS. This versatility reduces the need for multiple communication gateways, simplifying system architecture and lowering hardware costs.
Redundant Network Architecture: With dual Ethernet ports, the module enables redundant network setups, minimizing the risk of communication 中断 in critical applications such as power plants or offshore oil platforms. This feature ensures continuous data flow even in the event of a single network failure, enhancing system availability and reliability.
Advanced Diagnostic Capabilities: Built-in self-diagnostic tools monitor module health in real-time, including communication status, power supply stability, and thermal conditions. Faults are reported via front-panel LED indicators and through the Ovation HMI, enabling proactive maintenance and reducing mean time to repair (MTTR).
Security-Enhanced Design: The module incorporates encryption and access control mechanisms to protect against unauthorized access and data breaches. Its Achilles Level 1 certification ensures compliance with cybersecurity standards for industrial control systems, making it suitable for applications where data integrity is paramount.
Flexible Configuration: The EMERSON 5X00226G04 can be configured using Emerson’s AMS Suite software, allowing engineers to define communication parameters, map data points, and implement custom logic without hardware modifications. This flexibility supports rapid deployment and adaptability to changing operational requirements.
Application Areas ：EMERSON 5X00226G04
The EMERSON 5X00226G04 is widely deployed in industries where reliable and secure communication is essential:
-
Power Generation:
- Steam/Gas Turbines: Integrates with turbine control systems to monitor performance parameters (e.g., speed, temperature) and optimize fuel efficiency.
- Renewable Energy: Enables real-time data exchange between wind farms or solar plants and grid control systems, ensuring stable power output and grid synchronization.
-
Oil and Gas:
- Refineries: Manages distributed control systems in crude oil processing units, facilitating remote monitoring of pressure, flow, and temperature sensors.
- Offshore Platforms: Provides redundant communication for safety-critical systems such as emergency shutdown (ESD) and fire and gas detection.
-
Manufacturing:
- Automotive Production: Synchronizes robotics, conveyor systems, and quality control devices in high-speed assembly lines, ensuring precise coordination and minimizing downtime.
- Pharmaceutical Industry: Supports batch processing systems by connecting process analyzers and actuators to the control room, ensuring compliance with FDA and EUGMP standards.
-
Water and Wastewater Treatment:
- Pump Stations: Monitors and controls pump operations in water distribution networks, optimizing energy consumption and water quality.
- Wastewater Treatment Plants: Integrates with SCADA systems to manage sludge processing and chemical dosing, ensuring regulatory compliance.
EMERSON 5X00226G04
Related Products ：EMERSON 5X00226G04
- EMERSON 5X00225G01: A legacy Ethernet interface module for older Ovation systems, offering similar functionality with reduced protocol support.
- EMERSON 5X00273G01: A high-speed Profinet IO module that complements the EMERSON 5X00226G04 in multi-vendor automation environments.
- EMERSON 5X00357G01: A Modbus RTU/ASCII gateway module for connecting legacy devices to the Ovation DCS, extending the EMERSON 5X00226G04’s compatibility.
- EMERSON 5X00411G01: A redundant power supply module designed for use with the EMERSON 5X00226G04 in mission-critical applications requiring continuous operation.
- EMERSON 5X00481G01: A fiber optic transceiver module that expands the EMERSON 5X00226G04’s communication range in large-scale industrial networks.
Installation and Maintenance ：EMERSON 5X00226G04
Pre-installation Preparation:
Before installing the EMERSON 5X00226G04, ensure the following:
Before installing the EMERSON 5X00226G04, ensure the following:
- Verify the power supply meets the module’s requirements (24 VDC ±10%) and that the control rack is properly grounded to prevent EMI interference.
- Use Emerson’s AMS Suite software to configure communication protocols, IP addresses, and device parameters prior to installation.
- Ensure adequate ventilation around the module to maintain operating temperature within specified limits (-40°C to +70°C).
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Health” indicators). Replace faulty modules immediately to avoid cascading system failures.
- Firmware Updates: Periodically update the module’s firmware using Emerson’s AMS Suite to access the latest features and security patches.
- Environmental Checks: Clean dust and debris from the module’s vents quarterly, particularly in dusty environments, to prevent overheating. Monitor ambient humidity levels to ensure they remain below 95% non-condensing.
- Network Testing: Perform annual network integrity tests using Emerson’s diagnostic tools to validate communication latency and packet loss, ensuring optimal performance.
EMERSON 5X00226G04
Product Warranty ：EMERSON 5X00226G04
Our company provides a one-year quality warranty for the EMERSON 5X00226G04, covering hardware failures due to non-human factors. During the warranty period, if the product exhibits abnormal performance or functional failure, we will provide replacement services. For discontinued models or urgent demands, our global supply chain network ensures rapid response to scarce spare parts requests, supporting the continuous and stable operation of industrial systems.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on publicly available technical data and industry applications. For detailed specifications, consult the official Emerson datasheet or contact our technical support team.
