ELAU MC-4/11/01/400 Product Specification
Product Overview ：ELAU MC-4/11/01/400
The ELAU MC-4/11/01/400 is a high-performance motion control module designed for advanced industrial automation systems. Engineered by ELAU (a subsidiary of Schneider Electric), a renowned leader in motion control and robotics solutions, this module belongs to the MC Series, celebrated for its precision, flexibility, and seamless integration with servo drives and programmable logic controllers (PLCs). The ELAU MC-4/11/01/400 serves as a core component in motion-centric applications, enabling precise coordination of multi-axis systems in industries such as packaging, textiles, automotive manufacturing, and robotics.
At its core, the ELAU MC-4/11/01/400 features a 32-bit RISC processor and dedicated motion control firmware, delivering real-time trajectory planning and servo control for up to 16 axes. It supports multiple communication protocols, including CANopen and Ethernet/IP, ensuring compatibility with a wide range of field devices and supervisory systems. The module’s compact design (120 mm x 100 mm x 50 mm) and DIN rail mounting make it suitable for space-constrained industrial environments, while its rugged construction ensures reliable operation in harsh conditions with temperature ranges from -10°C to +55°C.
In automation systems, the ELAU MC-4/11/01/400 acts as a centralized motion controller, translating high-level commands from PLCs or human-machine interfaces (HMIs) into precise motor movements. Its support for advanced motion profiles—such as linear, circular, and synchronized interpolations—makes it ideal for applications requiring complex path planning, such as pick-and-place robots or high-speed packaging lines. By combining real-time control with diagnostic capabilities, the module minimizes downtime and enhances operational efficiency, ensuring consistent performance in high-precision manufacturing processes.
Technical Specifications ：ELAU MC-4/11/01/400
| Parameter Name | Parameter Value |
|---|---|
| Product Model | ELAU MC-4/11/01/400 |
| Manufacturer | ELAU (Schneider Electric) |
| Product Type | Motion Control Module |
| Processor | 32-bit RISC |
| Axes Supported | Up to 16 axes |
| Communication Protocols | CANopen, Ethernet/IP, RS-232/485 |
| Power Supply | 24 VDC ±10% (10 W typical power consumption) |
| Physical Dimensions | 120 mm (W) × 100 mm (H) × 50 mm (D) |
| Weight | 0.3 kg |
| Operating Temperature | -10°C to +55°C |
| Humidity | 5% to 95% non-condensing |
| Installation | DIN rail mounting |
| Certifications | CE, UL, RoHS |
ELAU MC-41110400
Main Features and Advantages ：ELAU MC-4/11/01/400
Multi-Axis Precision Control: The ELAU MC-4/11/01/400 enables simultaneous control of up to 16 axes, supporting complex motion profiles such as linear, circular, and electronic gearing. This capability is critical for applications like robotic assembly lines, where precise coordination of multiple motors is essential to maintain product quality and throughput.
Flexible Communication Interfaces: With support for CANopen and Ethernet/IP, the module integrates seamlessly with both legacy and modern automation systems. The CANopen interface ensures real-time communication with servo drives and I/O modules, while Ethernet/IP enables connectivity to higher-level PLCs and SCADA systems for centralized monitoring and control.
Compact and Rugged Design: Despite its advanced functionality, the ELAU MC-4/11/01/400 maintains a compact form factor, making it suitable for retrofitting into existing machines or deploying in new installations with limited space. Its rugged enclosure protects against dust, moisture, and vibration, ensuring reliable operation in demanding industrial environments.
User-Friendly Programming: The module is programmed using ELAU’s EasyMotion Studio software, which provides a graphical interface for defining motion trajectories, configuring axes, and debugging. This intuitive tool reduces programming time and allows engineers to quickly adapt the system to changing production requirements.
Diagnostic and Maintenance Tools: Built-in diagnostics monitor motor health, communication status, and power supply stability, enabling proactive maintenance. Real-time error reporting and troubleshooting features minimize downtime, ensuring continuous operation in critical applications.
ELAU MC-41110400
Application Areas ：ELAU MC-4/11/01/400
The ELAU MC-4/11/01/400 is deployed across industries that demand precise motion control and flexibility:
-
Packaging Industry:
- Controls pick-and-place robots, conveyor systems, and labeling machines in food and beverage packaging lines.
- Enables high-speed, synchronized motion for tasks like carton forming, filling, and sealing, ensuring consistent production rates.
-
Textile Manufacturing:
- Drives multi-axis embroidery machines, weaving looms, and fabric cutting systems.
- Supports complex pattern generation and real-time adjustments to thread tension and speed, enhancing fabric quality and production efficiency.
-
Automotive Production:
- Manages robotic arms in assembly lines for tasks such as welding, painting, and component installation.
- Ensures precise synchronization between robots and conveyor belts, reducing cycle times and improving manufacturing accuracy.
-
Robotics and Automation:
- Powers collaborative robots (cobots) and autonomous guided vehicles (AGVs) in smart factories.
- Enables smooth, collision-free motion planning in dynamic environments, supporting flexible production layouts.
-
Printing and Paper Processing:
- Controls roll-to-roll systems, cutting machines, and inkjet printers.
- Maintains consistent tension and alignment in paper and film processing, minimizing waste and improving output quality.
Related Products ：ELAU MC-4/11/01/400
- ELAU MC-4/11/02/400: An upgraded version with expanded memory and support for 32 axes, suitable for large-scale motion control systems.
- ELAU PD100: A servo drive designed for seamless integration with the MC-4/11/01/400, offering high-power density and dynamic performance.
- ELAU AP100: A compact servo drive for smaller motors, ideal for applications requiring precise control in limited space.
- ELAU I/O-4/16: A digital I/O module that expands the system’s connectivity to sensors and actuators, enhancing its flexibility in hybrid control setups.
- ELAU MC-2/11/01/400: A cost-effective variant supporting up to 8 axes, suitable for entry-level motion control applications.
- ELAU EasyMotion Studio Software: The official programming suite for ELAU motion controllers, providing advanced simulation and debugging tools.
ELAU MC-41110400
Installation and Maintenance ：ELAU MC-4/11/01/400
Installation Preparation:
Before installing the ELAU MC-4/11/01/400, ensure the following:
Before installing the ELAU MC-4/11/01/400, ensure the following:
- Verify the power supply meets the module’s requirements (24 VDC ±10%) and is properly grounded to prevent electrical noise.
- Mount the module on a DIN rail in a well-ventilated control cabinet, allowing adequate space for heat dissipation.
- Connect the communication cables (CANopen or Ethernet/IP) to the respective ports, ensuring secure connections to the network and peripheral devices.
- Use ELAU’s EasyMotion Studio to configure the module’s parameters, such as axis mapping, communication protocols, and safety settings.
Maintenance Recommendations:
- Regularly inspect the module for loose connections or signs of physical damage, particularly in high-vibration environments.
- Monitor the operating temperature using the module’s built-in diagnostics, ensuring it remains within the specified range (-10°C to +55°C).
- Update the firmware periodically to access the latest features and performance improvements, following the procedures outlined in the user manual.
- Perform routine tests of the motion control functions, such as jogging axes and verifying trajectory accuracy, to identify potential issues early.
- Clean the control cabinet regularly to prevent dust accumulation, which can affect the module’s 散热 (heat dissipation) and overall reliability.
ELAU MC-41110400
Product Warranty ：ELAU MC-4/11/01/400
Our company provides a one-year quality warranty for the ELAU MC-4/11/01/400, covering hardware failures due to non-human factors. During the warranty period, we will replace the product if it exhibits performance anomalies or functional failures. For discontinued models or urgent needs, our global supply chain network ensures rapid response to scarce spare parts requests, supporting the continuous and stable operation of industrial systems. We stand behind the reliability of our products and offer dedicated technical support to assist with installation, configuration, and troubleshooting, ensuring your automation systems operate at peak efficiency.
Note: This product description is based on comprehensive research from ELAU’s technical documentation and industry applications. For detailed specifications or customization options, contact our sales team at sales@ygplc.com or via WhatsApp at +86 18859254943.
