ABB DO810 3BSE008510R1 | Digital Output Module

Description

Product Overview
The ABB DO810 3BSE008510R1 is a high-performance 16-channel 24 V DC digital output module designed for use within the ABB AC 800M control system. As a crucial component in distributed control systems (DCS), the DO810 delivers reliable and precise signal transmission to actuators, solenoids, and other output devices in industrial automation environments. Engineered for demanding applications, it provides consistent switching performance, low power dissipation, and seamless integration with ABB’s extensive range of process controllers. Its robust design ensures stability under high electromagnetic interference (EMI) conditions, making it an ideal choice for process industries such as oil & gas, petrochemicals, power generation, water treatment, and manufacturing automation.

The DO810 module helps plant operators achieve higher productivity, reduced downtime, and more efficient system control. By utilizing ABB’s proven hardware design, this module delivers exceptional durability and long service life in harsh industrial environments.

Technical Specifications

Parameter	Value
Model Number	DO810 3BSE008510R1
Product Type	Digital Output Module
Number of Channels	16
Signal Type	24 V DC, Source
Output Current per Channel	0.5 A (max)
Total Output Current	8 A (max)
Isolation	Optical isolation between channels and system
Power Consumption	5 W (typical)
Output Delay Time	< 0.5 ms
Load Type	Resistive and inductive loads
Diagnostic Functions	Channel status indication, error detection
Operating Temperature Range	0°C to +55°C
Storage Temperature Range	-40°C to +70°C
Humidity	5% to 95% non-condensing
Dimensions (H × W × D)	119 × 45 × 104 mm
Weight	0.25 kg
Mounting	DIN-rail or module carrier
Compliance & Certifications	CE, RoHS
Compatible Systems	ABB AC 800M, S800 I/O Series

DO810 3BSE008510R1

Key Features and Benefits

• High Channel Density – 16 individually isolated channels in a compact form factor for space efficiency.

• Fast Switching – Output delay of less than 0.5 ms ensures rapid response in time-critical processes.

• Robust Electrical Design – Handles both resistive and inductive loads with reliable protection features.

• Integrated Diagnostics – Built-in channel status LEDs and error detection functions for easy maintenance.

• Flexible Installation – DIN-rail or module carrier mounting options allow quick integration into existing systems.

• Industrial-Grade Reliability – Designed to withstand vibration, shock, and EMI for continuous operation in harsh conditions.

• Seamless System Integration – Fully compatible with ABB AC 800M controllers and S800 I/O Series for plug-and-play configuration.

Application Scenarios

• Oil & Gas Processing Plants – Controls actuators, pumps, and valves in hazardous zones with precise output control.

• Power Generation Facilities – Manages turbine control outputs, breaker commands, and auxiliary equipment operation.

• Water & Wastewater Treatment – Drives pumps, aeration systems, and gate actuators for continuous process control.

• Chemical & Petrochemical Plants – Coordinates chemical dosing systems and reactor output devices.

• Manufacturing Automation – Operates conveyor motors, robotic systems, and assembly line actuators.



  DO810 3BSE008510R1

Related Products

• ABB DI810 – 16-channel 24 V DC digital input module for high-speed signal acquisition.

• ABB AI810 – Analog input module for accurate process variable measurement in AC 800M systems.

• ABB AO810 – Analog output module for controlling variable speed drives and process actuators.

• ABB CI854A – Communication interface module for PROFINET network connectivity.

• ABB PM865 – High-performance processor module for AC 800M with expanded memory and redundancy support.

Installation and Maintenance Guidelines

1. Pre-Installation Checks – Verify that the DO810 module matches the required specification for the system and that all connections comply with ABB wiring standards.

2. Mounting – Install the module securely onto a DIN-rail or designated module carrier, ensuring proper grounding to minimize electrical noise.

3. Wiring – Use shielded cables where necessary, and ensure polarity is correct when connecting output loads.

4. Power Supply – Provide stable 24 V DC power to avoid fluctuations that could impact output performance.

5. Commissioning – Test each output channel individually using the controller’s diagnostic tools before system startup.

6. Routine Maintenance – Inspect wiring, output status LEDs, and environmental conditions periodically to ensure optimal operation.

7. Module Replacement – If replacement is necessary, power down the system before removing the module to prevent damage.



   DO810 3BSE008510R1

Product Warranty
This ABB DO810 3BSE008510R1 module is covered by a 12-month warranty provided exclusively by our company, not by ABB. The warranty covers defects in materials and workmanship under normal operating conditions. We offer repair or replacement services for faulty units, ensuring minimal downtime for your operations.
