Name: COEN ISCAN DSF-2000-MB-UV 2653-213-06 | Flame Detection Module | SUNSHINE XIHE
Brand: 其他
Price: 2365.00 USD
Availability: InStock

Description

COEN ISCAN DSF-2000-MB-UV 2653-213-06 Flame Detection Module

Product Overview：COEN ISCAN DSF-2000-MB-UV 2653-213-06

The COEN ISCAN DSF-2000-MB-UV 2653-213-06 is a high-reliability Flame Detection Module designed for critical industrial combustion systems, providing real-time monitoring and safety control in hazardous environments. As a core component of COEN ISCAN’s DSF-2000 Series, this module specializes in detecting ultraviolet (UV) radiation emitted by flames, making it ideal for applications requiring precise and rapid flame verification, such as gas turbines, boilers, incinerators, and industrial furnaces. By integrating advanced photodiode sensor technology and intelligent signal processing, the DSF-2000-MB-UV 2653-213-06 ensures reliable detection of flame presence while minimizing false alarms, thereby enhancing the safety and operational efficiency of combustion processes.

Key functionalities of the COEN ISCAN DSF-2000-MB-UV 2653-213-06 include continuous flame signal analysis, fault diagnostics, and relay output for shutdown commands. The module supports a wide UV sensitivity range (185–260 nm), enabling it to detect various fuel types, including natural gas, propane, and hydrogen. Its rugged design, compliant with IP66 and NEMA 4X standards, ensures performance in harsh conditions with temperatures ranging from -40°C to +85°C and resistance to vibration, moisture, and electromagnetic interference. As part of a comprehensive flame safeguard system, the DSF-2000-MB-UV 2653-213-06 interfaces seamlessly with PLCs, DCS systems, and safety interlock devices, providing real-time data for process control and emergency shutdowns.

In industrial automation ecosystems, the DSF-2000-MB-UV 2653-213-06 serves as a critical safety component, preventing unplanned ignition failures and reducing the risk of explosions or equipment damage. Its modular design allows for easy integration into both new and retrofitted systems, while built-in self-diagnostic features (e.g., sensor drift detection, wiring fault alerts) simplify maintenance and compliance with safety standards like NFPA 85 and API 556. By delivering reliable flame detection and rapid response, this module ensures regulatory compliance and minimizes downtime in high-risk industrial operations.

Technical Specifications：COEN ISCAN DSF-2000-MB-UV 2653-213-06

Parameter Name	Parameter Value
Product Model	DSF-2000-MB-UV 2653-213-06
Manufacturer	COEN ISCAN
Product Type	Flame Detection Module
Sensing Range	UV: 185–260 nm
Input Voltage	24 V DC ±15%
Output Signals	Relay contacts (SPDT), 4–20 mA analog
Physical Dimensions	152 mm (H) × 102 mm (W) × 76 mm (D)
Weight	1.2 kg
Operating Temperature	-40°C to +85°C
Protection Rating	IP66, NEMA 4X
Certifications	CE, FM, CSA
Mounting	Panel-mounted or rack-mounted

DSF-2000-MB-UV 2653-213-06

Key Features and Advantages：COEN ISCAN DSF-2000-MB-UV 2653-213-06

Advanced UV Sensing Technology: The DSF-2000-MB-UV 2653-213-06 utilizes a high-sensitivity UV photodiode to detect flame emissions within milliseconds, ensuring rapid response to combustion events. Its narrow-bandwidth filter reduces interference from sunlight, arc welding, and other UV sources, enhancing detection accuracy in challenging environments.

Rugged Industrial Design: Built to withstand extreme temperatures, vibrations, and corrosive atmospheres, the module’s hermetically sealed enclosure and conformal-coated circuitry ensure long-term reliability in harsh industrial settings, such as offshore platforms and chemical plants.

Modular and Versatile: The plug-and-play design allows for easy installation and replacement, minimizing downtime during maintenance. The module supports multiple output configurations (relay and analog), enabling seamless integration with a wide range of control systems and safety devices.

Comprehensive Diagnostics: Real-time self-diagnostics monitor sensor performance, power supply stability, and signal integrity, with LED indicators providing visual feedback on operational status. This proactive approach to maintenance reduces troubleshooting time and ensures compliance with safety audits.

Compliance with Global Standards: Certified to CE, FM, and CSA standards, the DSF-2000-MB-UV 2653-213-06 meets rigorous safety requirements for use in regulated industries, providing peace of mind in applications where non-compliance could lead to severe consequences.

DSF-2000-MB-UV 2653-213-06

Application Areas：COEN ISCAN DSF-2000-MB-UV 2653-213-06

The COEN ISCAN DSF-2000-MB-UV 2653-213-06 is essential for industries where flame safety is non-negotiable:

Oil & Gas: Monitoring burners in refineries, production facilities, and offshore platforms to prevent gas leaks and ensure safe shutdown procedures during emergencies.
Power Generation: Safeguarding gas and coal-fired boilers, steam turbines, and combined-cycle power plants by detecting flame stability and preventing misfires.
Chemical & Petrochemical: Controlling combustion processes in reactors, incinerators, and distillation units, where precise flame detection is critical to avoid hazardous incidents.
Manufacturing: Optimizing furnace operations in steel mills, cement plants, and glass production lines, ensuring consistent heat output and reducing energy waste through reliable flame monitoring.

Specific applications include:

Flame Safety Systems: Providing primary or redundant flame detection in safety instrumented systems (SIS), triggering emergency shutdowns when flame loss is detected.
Burner Management Systems (BMS): Integrating with BMS to validate ignition sequences and monitor flame health during normal operation.
Emission Control Systems: Ensuring complete combustion in waste-to-energy plants, reducing emissions and improving environmental compliance.
DSF-2000-MB-UV 2653-213-06

Installation and Maintenance：COEN ISCAN DSF-2000-MB-UV 2653-213-06

Installation Preparation:
Before installing the COEN ISCAN DSF-2000-MB-UV 2653-213-06, ensure the mounting location provides a clear line of sight to the flame zone, free from obstructions or excessive heat. Use shielded cables to connect the module to power and control systems, maintaining a minimum distance of 30 cm from high-voltage wiring to avoid interference. Secure the module using the provided mounting brackets, ensuring proper grounding to comply with safety standards. Configure sensitivity settings and relay outputs using the module’s dip switches or remote configuration tool, depending on the application requirements.

Maintenance Recommendations:

Routine Inspections: Clean the optical lens quarterly with a lint-free cloth to remove dust or debris that could affect detection accuracy. Inspect wiring connections for signs of wear or corrosion, tightening as necessary.
Functional Testing: Perform monthly tests using the DSF-2000-TESTER to simulate flame signals and verify relay responses. Document test results to ensure compliance with regulatory requirements.
Component Replacement: Replace the UV sensor every five years or as recommended by the manufacturer to maintain optimal performance. Keep spare DSF-2000-MB-UV 2653-213-06 modules on hand to minimize downtime in case of failure.
Firmware Updates: Periodically check for firmware updates from COEN ISCAN to access new features or performance improvements, following the manufacturer’s guidelines for safe installation.
DSF-2000-MB-UV 2653-213-06

Product Warranty：COEN ISCAN DSF-2000-MB-UV 2653-213-06

Our company provides a 12-month quality warranty for the COEN ISCAN DSF-2000-MB-UV 2653-213-06, covering hardware defects under normal use. In the event of performance issues or functional failures, we offer prompt replacement services. For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of hard-to-find components, supporting continuous industrial operations. Our technical support team is available 24/7 to assist with installation, troubleshooting, and system optimization, ensuring seamless integration and long-term reliability.

For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
