BENTLY 3500/94M 184826-01 Communication Gateway Module
Product Overview: BENTLY 3500/94M 184826-01
The BENTLY 3500/94M 184826-01 communication gateway module is a high-performance industrial networking component designed for Bently Nevada’s 3500 Series Machinery Health Monitoring System. As a critical link between field monitoring devices and supervisory control systems, this module enables seamless data integration and real-time diagnostics for rotating equipment in mission-critical applications. The 3500/94M 184826-01 serves as a gateway, translating vibration, displacement, and process data from 3500 Series modules into standard industrial protocols, facilitating remote monitoring and predictive maintenance.
Engineered for reliability in harsh environments, the 3500/94M 184826-01 supports multiple communication protocols, including Modbus TCP/IP, Ethernet/IP, and OPC UA, ensuring compatibility with diverse automation architectures. Its dual Ethernet ports (10/100 Mbps) enable redundant network configurations, while the built-in web server allows local configuration and data visualization without additional software. The module’s -40°C to +85°C operating range and IP20 protection rating make it suitable for industrial settings, from power plant turbines to offshore compressors.
Within automation systems, the 3500/94M 184826-01 acts as a bridge between machinery health data and enterprise-level networks, supporting real-time analytics and condition-based maintenance. Its compatibility with Bently Nevada’s 3500 Rack systems (e.g., 3500/05) and compliance with API 670 standards solidifies its role in critical infrastructure, where uninterrupted data transmission is essential for minimizing downtime and optimizing equipment lifespan.
Technical Specifications: BENTLY 3500/94M 184826-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3500/94M 184826-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Communication Gateway Module |
| Communication Protocols | Modbus TCP/IP, Ethernet/IP, OPC UA |
| Network Interfaces | 2 x Ethernet (10/100 Mbps, RJ45) |
| Data Transfer Rate | Up to 100 Mbps |
| Physical Dimensions | 160 mm (H) × 110 mm (W) × 250 mm (D) |
| Weight | 1.4 kg |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | 3500 Rack (slot-compatible) |
| Compliance | API 670, IEC 61000-6-2 |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 3500/94M 184826-01
Multi-Protocol Connectivity: The 3500/94M 184826-01 supports diverse industrial protocols, eliminating the need for multiple gateways and simplifying system integration. This versatility allows seamless data exchange with PLCs, SCADA systems, and cloud-based analytics platforms, enabling real-time decision-making.
Redundant Network Design: With dual Ethernet ports, the module supports network redundancy, ensuring continuous data transmission even if one connection fails. This feature is critical for industries where data loss could lead to unplanned downtime, such as power generation or oil refining.
Web-Based Configuration: The built-in web server enables intuitive configuration via a browser, reducing dependency on specialized software. Users can monitor real-time data, adjust settings, and generate reports locally, enhancing operational efficiency.
Industrial-Grade Durability: The module’s rugged construction and wide temperature range make it suitable for harsh environments. Its resistance to vibration, dust, and electromagnetic interference ensures reliable performance in challenging industrial settings.
Scalable Data Processing: Capable of handling high-volume machinery health data, the 3500/94M 184826-01 supports up to 1000 data points, making it ideal for large-scale monitoring systems in complex industrial setups.
Application Areas: BENTLY 3500/94M 184826-01
The BENTLY 3500/94M 184826-01 communication gateway module is essential for industries requiring real-time machinery health data integration:
- Power Generation: Connects turbine vibration monitoring systems to plant-wide SCADA networks, enabling remote analysis of generator health and proactive maintenance scheduling.
- Oil and Gas: Deploys in refineries and offshore platforms to transmit compressor vibration data to central control rooms, supporting safety interlocks and process optimization.
- Manufacturing: Integrates with CNC machines and robotic systems, providing actionable insights to prevent production line disruptions caused by mechanical failures.
- Water Treatment: Links pump and blower monitoring data to plant management systems, ensuring continuous operation and regulatory compliance.
- Aerospace and Defense: Supports condition monitoring of aircraft ground support equipment, enabling maintenance teams to address issues before mission-critical operations.
Related Products: BENTLY 3500/94M 184826-01
- 3500/05 Rack Enclosure: Houses the 3500/94M 184826-01 and other 3500 Series modules, providing power distribution and mechanical support.
- 3500/42M Vibration Monitoring Module: Collects vibration data for the 3500/94M 184826-01 to transmit, enabling comprehensive machinery analysis.
- 3500/15 Power Supply Module (127610-01): Supplies stable power to the 3500/94M 184826-01 and rack-mounted components.
- 3500/22M Proximitor Interface Module: Processes proximity probe signals, feeding data to the 3500/94M 184826-01 for remote transmission.
- 3500/32 Relay Module (125712-01): Triggers alarms based on data from the 3500/94M 184826-01, enhancing safety systems.
- 3500/92M Communication Gateway (136180-01): An earlier model with similar functionality, suitable for legacy system upgrades.
Installation and Maintenance: BENTLY 3500/94M 184826-01
Pre-installation Preparations:
Before installing the 3500/94M 184826-01, ensure the 3500 Rack is properly grounded and powered (24V DC). Clean the rack slot and align the module with the guides, securing it with retention brackets. Connect Ethernet cables to the dual ports, following Bently Nevada’s wiring guidelines for redundant network setups. Configure IP addresses and protocols via the built-in web interface, verifying connectivity with the host system before commissioning.
Before installing the 3500/94M 184826-01, ensure the 3500 Rack is properly grounded and powered (24V DC). Clean the rack slot and align the module with the guides, securing it with retention brackets. Connect Ethernet cables to the dual ports, following Bently Nevada’s wiring guidelines for redundant network setups. Configure IP addresses and protocols via the built-in web interface, verifying connectivity with the host system before commissioning.
Maintenance Recommendations:
- Routine Checks: Monthly visual inspections for loose connections, cable wear, or overheating. Use the module’s LED indicators to verify network status and data transmission.
- Firmware Updates: Periodically update firmware via the web interface to access new features and security patches, ensuring compatibility with evolving industrial protocols.
- Network Health Monitoring: Quarterly test network redundancy by simulating cable failures, ensuring failover functionality remains operational.
- Spare Parts Management: Keep a spare 3500/94M 184826-01 on hand, leveraging our global supply chain for quick replacement of discontinued or urgent components.
Product Guarantee: BENTLY 3500/94M 184826-01
Our company provides a 12-month quality warranty for the BENTLY 3500/94M 184826-01 communication gateway module, covering non-human-induced hardware defects. During the warranty period, we will replace any module with communication failures, hardware malfunctions, or physical damage at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable products and exceptional service. The 3500/94M 184826-01 exemplifies our dedication to quality, offering seamless data integration for critical machinery monitoring. Contact us today to optimize your industrial networking with this advanced communication gateway.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for Bently Nevada’s official technical manuals.
