Description

BENTLY 3500/92 136188-01 Product Specification

Product Overview

The BENTLY 3500/92 136188-01 is a high-performance communication gateway module designed for the BENTLY 3500 Series Machinery Protection System. As a critical component in industrial automation, this module bridges the gap between BENTLY’s 3500 rack-mounted monitoring systems and higher-level control platforms, enabling seamless data exchange and remote diagnostics. The BENTLY 3500/92 136188-01 supports multiple communication protocols, including Modbus RTU and PROFIBUS DP, making it compatible with a wide range of PLCs, HMIs, and SCADA systems. Its rugged design and advanced networking capabilities make it ideal for mission-critical applications in industries such as oil and gas, power generation, and manufacturing.



Engineered to integrate with BENTLY’s 3500 Series modules (e.g., vibration monitors, power supplies), the BENTLY 3500/92 136188-01 ensures real-time transmission of machinery health data, including vibration analysis, temperature readings, and operational status. Its dual-port Ethernet interface allows for redundant communication paths, enhancing system reliability in harsh industrial environments. The module’s compact form factor (210 mm × 150 mm × 100 mm) and lightweight construction (2 kg) simplify installation in 19″ racks, while its IP23-rated enclosure protects against dust and moisture.



In automation systems, the BENTLY 3500/92 136188-01 acts as a central hub for predictive maintenance strategies. By aggregating data from multiple sensors and modules, it enables engineers to monitor equipment performance in real time, detect anomalies, and schedule maintenance proactively. This reduces downtime, extends equipment lifespan, and minimizes operational costs. With its combination of robust connectivity and advanced diagnostic capabilities, the BENTLY 3500/92 136188-01 is a cornerstone of modern industrial asset management.

Technical Specifications

Parameter Name Parameter Value
Product Model BENTLY 3500/92 136188-01
Manufacturer BENTLY NEVADA
Product Type Communication Gateway Module
Communication Protocols Modbus RTU, PROFIBUS DP
Interfaces Dual-port Ethernet, RS-485
Input Voltage 24 VDC ±10%
Power Consumption <2 W
Physical Dimensions 210 mm (W) × 150 mm (H) × 100 mm (D)
Weight 2 kg
Enclosure Protection IP23
Operating Temperature -25°C to +60°C
Country of Origin United States
Certifications CE, UL
3500/92 136188-01

3500/92 136188-01

Main Features and Advantages

Multi-Protocol Connectivity: The BENTLY 3500/92 136188-01 supports Modbus RTU and PROFIBUS DP, allowing seamless integration with diverse control systems. This flexibility eliminates the need for additional protocol converters, simplifying system design and reducing hardware costs.



Redundant Communication: Its dual-port Ethernet interface ensures continuous data transmission even if one port fails, enhancing system resilience in mission-critical applications. This redundancy is particularly valuable in industries where downtime is costly, such as oil refineries and power plants.



Real-Time Data Aggregation: The module aggregates data from BENTLY’s 3500 Series modules (e.g., vibration monitors, temperature sensors) and transmits it to higher-level systems for analysis. This enables real-time decision-making, such as adjusting equipment parameters or triggering alarms based on predefined thresholds.



Rugged Industrial Design: Constructed with an IP23-rated enclosure and conformal-coated PCBs, the BENTLY 3500/92 136188-01 resists environmental contaminants and electromagnetic interference (EMI). Its wide operating temperature range ensures reliable performance in extreme conditions, from offshore platforms to high-temperature industrial settings.



User-Friendly Configuration: BENTLY’s proprietary software allows users to configure communication parameters (e.g., baud rate, parity) and monitor module health remotely. This reduces setup time and enables quick troubleshooting, minimizing operational disruptions.

3500/92 136188-01

3500/92 136188-01

Application Areas

The BENTLY 3500/92 136188-01 is widely used in industries where machinery reliability and remote monitoring are critical:



  1. Oil and Gas:
    • Integrates with offshore platform control systems to transmit vibration and temperature data from pumps, compressors, and turbines.
    • Supports emergency shutdown systems (ESD) by providing real-time status updates to central control rooms.
  2. Power Generation:
    • Enables remote monitoring of steam turbine performance in power plants, optimizing energy output and preventing costly outages.
    • Transmits generator health data to SCADA systems for predictive maintenance planning.
  3. Manufacturing:
    • Connects robotic arms and conveyor belt drives to PLCs, ensuring precise motion control and reducing downtime in automotive plants.
    • Aggregates data from quality control sensors to enable real-time adjustments in production lines.
  4. Water/Wastewater Treatment:
    • Monitors pump station performance and chemical dosing systems, ensuring consistent water flow and treatment efficiency.
    • Integrates with distributed SCADA systems for remote management of water treatment facilities.

Related Products

  • BENTLY 3500/15 125840-02: A low-voltage AC power input module that provides stable power to the BENTLY 3500/92 136188-01 and other 3500 series modules.
  • BENTLY 3500/22M 146031-01: A vibration monitoring module that interfaces with the BENTLY 3500/92 136188-01 to transmit shaft vibration data for predictive maintenance.
  • BENTLY 3500/32 129407-01: A dual-channel speed/torque monitor that works in tandem with the BENTLY 3500/92 136188-01 to provide rotational speed data for turbines.
  • BENTLY 3500/42 129408-01: A temperature monitor module that relies on the BENTLY 3500/92 136188-01 for data transmission to higher-level systems.
  • BENTLY 3500/95 129411-01: A redundant power supply module that ensures continuous operation of the BENTLY 3500/92 136188-01 in mission-critical applications.
    3500/92 136188-01

    3500/92 136188-01

Installation and Maintenance

Pre-installation Preparation:
Before installing the BENTLY 3500/92 136188-01, ensure the following:



  • Verify the input voltage matches the module’s requirements (24 VDC ±10%) and that the rack is properly grounded to prevent electrostatic discharge (ESD) damage.
  • Use BENTLY’s configuration software to set communication parameters (e.g., baud rate, protocol type) for Modbus RTU or PROFIBUS DP.
  • Secure the module in a 19″ rack using the provided mounting brackets, allowing at least 50 mm of clearance for airflow.



Maintenance Recommendations:



  • Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Communication” indicators). Clean dust from vents quarterly to maintain optimal cooling.
  • Firmware Updates: Periodically update the module’s firmware via BENTLY’s dedicated software to access new features and security patches.
  • Redundancy Testing: Test the dual-port Ethernet interface biannually to ensure failover functionality in redundant communication setups.
  • Protocol Compliance: Validate Modbus RTU and PROFIBUS DP communication protocols annually using certified test equipment to ensure accuracy.

Product Warranty

Our company provides a one-year quality warranty for the BENTLY 3500/92 136188-01, covering hardware malfunctions not caused by human factors. During the warranty period, if the product exhibits abnormal performance or functional failure, we will provide replacement services. For discontinued models like the BENTLY 3500/92 136188-01, our global inventory of legacy industrial control parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services through our network of certified technicians, ensuring your critical systems remain operational long after the warranty expires.



Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com



Note: This document is based on technical data derived from BENTLY’s official specifications and industry applications. For detailed operational guidelines, refer to the BENTLY 3500/92 136188-01 user manual or contact our technical support team for personalized assistance.
