BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 2
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 3
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 4
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 5
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 6
BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 - Image 7

BENTLY 3500/53 133396-01 | Relay Output Module | 3500/60 163179-01 Bently Nevada

Original price was: $2,500.00.Current price is: $1,837.00.

Brand model:Bently Nevada
Product Name:3500/53 133396-01
Warranty: 1 year
Size:210 mm (W) × 150 mm (H) × 100 mm (D)
Weight:2.3kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Get a Quote
Category: Brand:

Description



BENTLY 3500/53 133396-01 Product Specification

Product Overview

The BENTLY 3500/53 133396-01 is a high-reliability relay output module designed for BENTLY’s 3500 Series Machinery Protection System. Engineered to convert digital signals into physical relay actions, this module serves as a critical interface in industrial automation systems, enabling alarm activation, shutdown sequences, and control commands for rotating machinery. The BENTLY 3500/53 133396-01 features 8 independent relay channels, each capable of switching high-current loads, making it essential for industries such as oil and gas, power generation, and manufacturing where precise control and safety interlocks are non-negotiable.



As part of BENTLY NEVADA’s 3500 platform, the BENTLY 3500/53 133396-01 integrates seamlessly with vibration monitors, temperature modules, and communication gateways to form a comprehensive machinery protection system. Its compact design (210 mm × 150 mm × 100 mm) and lightweight construction (2.3 kg) facilitate easy installation in 19″ racks, while the IP23-rated enclosure protects against dust and moisture. The module’s fail-safe design ensures reliable switching even in harsh environments, minimizing downtime and enhancing operational safety.



In automation architectures, the BENTLY 3500/53 133396-01 acts as a bridge between the control system and field devices, translating digital commands from the PLC into physical actions (e.g., valve activation, alarm sirens). Its built-in diagnostic capabilities monitor relay health and alert operators to contact wear or coil failures, enabling proactive maintenance. By combining robust switching performance with advanced signal processing, the module supports critical safety functions and ensures compliance with industry standards for machinery protection.

Technical Specifications

Parameter Name Parameter Value
Product Model BENTLY 3500/53 133396-01
Manufacturer BENTLY NEVADA
Product Type Relay Output Module
Relay Channels 8 channels (SPDT, 5 A/250 VAC, 5 A/30 VDC)
Input Voltage 24 VDC ±10%
Contact Rating 5 A maximum per channel
Mechanical Life 10 million operations
Electrical Life 500,000 operations at full load
Physical Dimensions 210 mm (W) × 150 mm (H) × 100 mm (D)
Weight 2.3 kg
Operating Temperature -25°C to +60°C
Humidity 5–95% non-condensing
Certifications CE, UL

Main Features and Advantages

Eight-Channel Relay Switching: The BENTLY 3500/53 133396-01 supports 8 independent SPDT relays, enabling simultaneous control of multiple field devices such as valves, alarms, and shutdown systems. This high channel density reduces the need for additional modules, simplifying system architecture.



High-Current Capability: Each relay channel can switch up to 5 A at 250 VAC or 30 VDC, making it suitable for direct control of heavy loads like motor starters and solenoid valves. This capability eliminates the need for intermediate relays, reducing installation costs.



Fail-Safe Design: The module features latching relays with manual override capability, ensuring critical safety functions remain active even during power interruptions. This design is vital for emergency shutdown systems in oil refineries and power plants.



Advanced Diagnostics: Built-in LED indicators and fault reporting via the 3500 Series communication bus allow real-time monitoring of relay status, contact wear, and coil health. This proactive approach to maintenance minimizes unplanned downtime.



Modular System Integration: As part of the 3500 Series, the BENTLY 3500/53 133396-01 integrates seamlessly with other modules (e.g., vibration monitors, power supplies), forming a cohesive protection system. Its hot-swappable design enables maintenance without system shutdowns.

Application Areas

The BENTLY 3500/53 133396-01 is critical in industries where reliable relay control is essential for safety and operational efficiency:



  1. Oil and Gas:
    • Triggers emergency shutdown (ESD) sequences in offshore platforms and refineries, isolating hazardous areas during process anomalies.
    • Controls valve actuators in pipeline networks, adjusting flow rates based on pressure and temperature inputs from 3500 Series monitors.
  2. Power Generation:
    • Activates alarm systems and shuts down turbines in power plants during abnormal vibration or temperature conditions.
    • Controls auxiliary equipment (e.g., cooling fans, lubrication pumps) based on machinery health data from 3500 Series modules.
  3. Manufacturing:
    • Triggers quality control stops in automotive plants when machinery vibrations exceed safe limits, preventing defective product production.
    • Controls conveyor systems and robotic arms in packaging facilities, ensuring precise synchronization with production cycles.
  4. Water/Wastewater Treatment:
    • Activates pumps and chemical dosing systems in water treatment plants based on sensor inputs from 3500 Series monitors.
    • Triggers alarms in wastewater facilities when equipment vibrations indicate potential failures.

Related Products

  • BENTLY 3500/50 133394-01: A 4-channel relay module, suitable for smaller setups, often used as a cost-effective alternative to the BENTLY 3500/53 133396-01 for limited-channel applications.
  • BENTLY 3500/22M 146031-01: A vibration monitoring module that pairs with the BENTLY 3500/53 133396-01 to trigger relays based on vibration amplitude thresholds.
  • BENTLY 3500/15 125840-02: A power input module that supplies stable 24 VDC to the BENTLY 3500/53 133396-01 and other 3500 Series components.
  • BENTLY 3500/92 129410-01: A communication gateway that enables the BENTLY 3500/53 133396-01 to interface with Ethernet/IP networks for remote relay control.
  • BENTLY 3500/42 129408-01: A temperature monitoring module that works with the BENTLY 3500/53 133396-01 to activate relays during overheating conditions.

Installation and Maintenance

Pre-installation Preparation:
Before installing the BENTLY 3500/53 133396-01, ensure the following:



  • Verify the power supply meets 24 VDC ±10% and that the control rack is properly grounded to prevent electrostatic discharge (ESD). Use a multimeter to confirm voltage stability.
  • Use BENTLY’s configuration software to map relay outputs to specific alarm conditions (e.g., high vibration, low pressure) based on machinery safety protocols.
  • Mount the module in a 19″ rack with at least 50 mm of clearance for airflow, securing it with the provided brackets to minimize vibration-induced displacement.



Maintenance Recommendations:



  • Routine Inspections: Monthly visual checks of front-panel LEDs (green for normal operation, red for faults) and physical relay contacts for signs of arcing or wear.
  • Contact Resistance Testing: Annual measurement of relay contact resistance using a multimeter to ensure reliable switching. Replace relays if resistance exceeds 100 mΩ.
  • Firmware Updates: Periodically update the module’s firmware via BENTLY’s software to access compatibility improvements with newer 3500 Series components.
  • Functional Testing: Biannual activation of each relay channel to verify switching performance, using a load bank to simulate real-world conditions.

Product Warranty

Our company provides a one-year quality warranty for the BENTLY 3500/53 133396-01, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits relay contact failures or functional defects. For discontinued models like the BENTLY 3500/53 133396-01, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services to maintain your system’s reliability over its lifecycle.



Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com



Note: This document is based on technical data derived from BENTLY’s official specifications and industry applications. For detailed installation guidelines, refer to the BENTLY 3500/53 133396-01 user manual or contact our technical support team for personalized assistance.
