BENTLY 3500/50 286566-02 Process Variable Module

Product Overview: BENTLY 3500/50 286566-02

The BENTLY 3500/50 286566-02 process variable module is a high-precision industrial component designed for real-time monitoring of critical process parameters within Bently Nevada’s 3500 Series Machinery Health Monitoring System. As a versatile solution for integrating process data with mechanical health diagnostics, the 3500/50 286566-02 enables seamless acquisition and processing of analog signals from sensors measuring pressure, temperature, flow, and level in mission-critical industrial applications. Engineered to support up to 8 channels of analog input, this module bridges the gap between process control and machinery protection systems, enhancing overall operational visibility and reliability.



Featuring a 16-bit analog-to-digital conversion and configurable input ranges (4–20 mA, 0–10 V DC), the 3500/50 286566-02 ensures precise measurement and signal conditioning for seamless integration with distributed control systems (DCS) and supervisory control networks. Its hot-swappable design allows module replacement without system shutdown, while built-in self-diagnostics and alarm functionality enable proactive identification of sensor failures or signal anomalies. The module’s -40°C to +85°C operating temperature range and IP20 protection rating make it suitable for harsh environments, from power plant turbines to offshore oil platforms.



Within automation ecosystems, the 3500/50 286566-02 plays a pivotal role in consolidating process and mechanical data, enabling operators to make informed decisions about equipment health and process efficiency. By integrating process variables with vibration and displacement measurements, this module supports comprehensive predictive maintenance strategies, reducing unplanned downtime and optimizing asset lifecycle management.

Technical Specifications: BENTLY 3500/50 286566-02

Parameter Name Parameter Value
Product Model 3500/50 286566-02
Manufacturer BENTLY NEVADA
Product Type Process Variable Module
Input Channels 8 channels (analog input)
Input Ranges 4–20 mA, 0–10 V DC, ±10 V DC
Resolution 16-bit ADC
Communication Protocol Proprietary to 3500 Series, Modbus RTU/TCP
Physical Dimensions 177.8 mm (H) × 48.3 mm (W) × 254 mm (D)
Weight 1.2 kg
Operating Temperature -40°C to +85°C
Humidity 5–95% non-condensing
Mounting Type 3500 Rack (slot-compatible)
Compliance API 670, IEC 61000-6-2
Country of Origin United States

Main Features and Advantages: BENTLY 3500/50 286566-02

Multi-Channel Precision Sensing: The 3500/50 286566-02 supports 8 channels of analog input, enabling simultaneous monitoring of multiple process parameters. Its 16-bit resolution ensures measurement accuracy within ±0.1% of full scale, critical for applications where minor deviations impact operational efficiency.



Flexible Input Configuration: Users can configure each channel for 4–20 mA or voltage inputs, adapting to diverse sensor types (pressure transducers, thermocouples, flow meters). This flexibility reduces the need for dedicated signal conditioners, simplifying system design and lowering costs.



Seamless System Integration: As part of the 3500 Series, the module interfaces directly with other 3500 components (e.g., vibration monitors, communication gateways), consolidating data into a unified health monitoring platform. Its Modbus compatibility allows integration with third-party SCADA systems for centralized analytics.



Rugged Industrial Design: Built to withstand harsh conditions, the module features a metal enclosure with IP20 protection, resisting dust and mechanical stress. Its wide temperature range ensures reliable operation in extreme environments, from arctic oil fields to high-temperature manufacturing zones.



Proactive Diagnostic Capabilities: Real-time self-diagnostics and alarm outputs (via relays or digital signals) alert operators to sensor faults, signal losses, or out-of-range conditions. This proactive approach minimizes troubleshooting time and supports predictive maintenance strategies.

Application Areas: BENTLY 3500/50 286566-02

The BENTLY 3500/50 286566-02 process variable module is essential for industries requiring integrated process and machinery health monitoring:



  • Power Generation: Monitors steam pressure, cooling water flow, and generator temperature in thermal, hydro, and nuclear power plants, enabling operators to optimize energy production while preventing equipment overload.
  • Oil and Gas: Deployed in refineries and offshore platforms to monitor pipeline pressure, tank levels, and process temperatures, supporting safe operation and compliance with environmental regulations.
  • Manufacturing: Integrates with CNC machines, extruders, and packaging lines to monitor process variables (e.g., hydraulic pressure, material flow), enhancing product quality and reducing waste.
  • Water Treatment: Manages pump station pressures, chemical dosing rates, and wastewater levels in treatment plants, ensuring continuous operation and regulatory compliance.
  • Aerospace and Defense: Used in testing facilities and ground support equipment to monitor fuel levels, hydraulic pressures, and environmental conditions for mission-critical assets.

Related Products: BENTLY 3500/50 286566-02

  1. 3500/42M Vibration Monitoring Module: Works alongside the 3500/50 286566-02 to integrate vibration data with process variables for comprehensive machinery health analysis.
  2. 3500/92M Communication Gateway: Enables Ethernet-based data transmission from the 3500/50 286566-02 to cloud-based analytics platforms or enterprise systems.
  3. 3500/32 Relay Module (125712-01): Triggers alarms or trips based on process variable thresholds monitored by the 3500/50 286566-02.
  4. 3500/22M Proximitor Interface Module: Supports proximity probe inputs for shaft displacement, complementing the 3500/50 286566-02 in multi-parameter monitoring setups.
  5. 3500/05 Rack Enclosure: Houses the 3500/50 286566-02 and other 3500 Series modules, providing power distribution and mechanical support.
  6. 3500/53 Displacement Module: Monitors shaft position and eccentricity, integrating with the 3500/50 286566-02 for holistic machinery diagnostics.

Installation and Maintenance: BENTLY 3500/50 286566-02

Pre-installation Preparations:
Before installing the 3500/50 286566-02, verify the 3500 Rack is properly grounded and powered (24V DC). Clean the rack slot and ensure no debris is present. Slide the module into the designated slot, securing it with retention brackets. Connect sensor cables to the terminal block, following Bently Nevada’s wiring diagram to ensure correct polarity and shielding. Configure input ranges via the module’s dip switches or software, and test signal integrity using a calibrated voltage or current source.



Maintenance Recommendations:



  • Routine Inspections: Monthly checks include verifying LED status indicators, tightening cable connections, and cleaning dust from ventilation slots. Use a multimeter to confirm input signals match sensor outputs.
  • Calibration Verification: Annually calibrate the module using a certified signal source to ensure measurement accuracy. Reference Bently Nevada’s calibration procedures for step-by-step guidance.
  • Firmware Updates: Periodically update the module’s firmware via the 3500 Rack Configuration Software to access new features or bug fixes.
  • Spare Parts Management: Keep a spare 3500/50 286566-02 on hand, leveraging our global supply chain for quick replacement of discontinued or urgent components.

Product Guarantee: BENTLY 3500/50 286566-02

Our company provides a 12-month quality warranty for the BENTLY 3500/50 286566-02 process variable module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with signal processing errors, communication failures, or physical damage at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.



With 17 years of expertise in industrial control distribution, we prioritize reliable products and exceptional service. The 3500/50 286566-02 exemplifies our commitment to quality, offering the precision and flexibility required for integrated process and machinery health monitoring. Contact us today to optimize your automation system with this robust module.
