BENTLY 3500/40M 176449-01 Proximitor™ Vibration Monitoring Module
Product Overview: BENTLY 3500/40M 176449-01
The BENTLY 3500/40M 176449-01 Proximitor™ vibration monitoring module is a high-precision industrial component designed for real-time mechanical health assessment in critical rotating equipment. As a core component of Bently Nevada’s 3500 Series Machinery Health Monitoring System, this module converts proximity probe signals into standardized outputs for vibration analysis, enabling early detection of faults such as misalignment, bearing wear, or imbalance. The 3500/40M 176449-01 integrates advanced eddy current technology with rugged hardware to deliver reliable performance in harsh industrial environments, from power plant turbines to offshore compressors.
Engineered for accuracy and durability, the 3500/40M 176449-01 supports two independent channels for simultaneous monitoring of shaft vibration and displacement. Its 7.87 V/mm (200 mV/mil) sensitivity and 0–2 mm linear measurement range ensure precise data acquisition, while dual redundant power inputs (24V DC) and hot-swappable design minimize downtime during maintenance. The module’s -40°C to +85°C operating temperature range and IP20 protection rating make it suitable for demanding applications, while its Modbus RTU/TCP communication interface enables seamless integration with distributed control systems (DCS) and supervisory control networks.
Within automation ecosystems, the 3500/40M 176449-01 acts as a cornerstone of predictive maintenance strategies, providing critical data to support real-time diagnostics and proactive equipment care. Its compatibility with Bently Nevada’s 3500 Rack enclosures (e.g., 3500/05) and compliance with API 670 standards positions it as an essential tool for industries requiring uninterrupted operation and minimal unplanned downtime.
Technical Specifications: BENTLY 3500/40M 176449-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3500/40M 176449-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Vibration Monitoring Module |
| Input Channels | 2 channels (eddy current proximity probes) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Measurement Range | 0–2 mm (linear) |
| Output Signals | 4–20 mA, 0–10 V DC, relay contacts |
| Communication Protocol | Modbus RTU/TCP |
| Physical Dimensions | 177.8 mm (H) × 48.3 mm (W) × 254 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | 3500 Rack (slot-compatible) |
| Compliance | API 670, IEC 61000-6-2 |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 3500/40M 176449-01
High-Precision Vibration Analysis: The 3500/40M 176449-01 utilizes advanced eddy current technology to measure shaft displacement with micron-level accuracy, critical for detecting early-stage mechanical issues. Its dual-channel design allows simultaneous monitoring of multiple points, enhancing fault localization in complex machinery.
Redundant and Rugged Design: With dual redundant power inputs and a hot-swappable form factor, the module ensures continuous operation even during maintenance or power fluctuations. The rugged metal enclosure and wide temperature tolerance make it suitable for harsh environments, resisting vibration, dust, and electromagnetic interference.
Flexible System Integration: The module’s Modbus communication interface enables seamless integration with PLCs, SCADA systems, and cloud-based analytics platforms. This flexibility supports remote monitoring and data-driven decision-making, optimizing maintenance schedules and reducing operational costs.
Comprehensive Diagnostic Capabilities: Built-in LED indicators and self-diagnostic functions provide real-time feedback on module health, reducing troubleshooting time. The module’s compatibility with Bently Nevada’s System 1 software enables advanced spectral analysis and trend tracking for predictive maintenance.
API 670 Compliance: Designed to meet API 670 standards for machinery protection systems, the 3500/40M 176449-01 ensures compliance in critical applications, such as power generation and oil refining, where safety and reliability are non-negotiable.
Application Areas: BENTLY 3500/40M 176449-01
The BENTLY 3500/40M 176449-01 Proximitor™ module is essential for industries relying on precise machinery health monitoring:
- Power Generation: Monitors steam turbines, generators, and auxiliary equipment in thermal, hydro, and renewable energy plants, enabling early detection of rotor imbalances or bearing degradation to maintain uninterrupted power production.
- Oil and Gas: Deployed in refineries, pipelines, and offshore platforms to monitor compressors, pumps, and motors. The module’s durability supports operation in harsh, corrosive environments, ensuring continuous process safety.
- Manufacturing: Integrates with CNC machines, robotic arms, and conveyor systems in automotive and pharmaceutical production, minimizing unplanned downtime by detecting vibrations that could affect product quality.
- Water Treatment: Controls pumps and agitators in water/wastewater plants, ensuring regulatory compliance and efficient operation through real-time vibration analysis.
- Aerospace and Defense: Supports condition monitoring of aircraft engines and ground support equipment, where reliable data is critical for mission readiness and safety.
Related Products: BENTLY 3500/40M 176449-01
- 3500/05 Rack Enclosure: Houses the 3500/40M 176449-01 and other 3500 Series modules, providing mechanical support and power distribution.
- 3500/15 Power Supply Module (127610-01): Supplies redundant power to the 3500/40M 176449-01, ensuring stable operation in critical systems.
- 3500/32 Relay Module (125712-01): Triggers alarms and trips based on data from the 3500/40M 176449-01, enhancing safety and fault response.
- 106M1081-01 Vibration Proximity Probe: Connects to the 3500/40M 176449-01 to provide raw vibration data, forming a complete monitoring solution.
- 3500/92M Communication Gateway (136180-01): Enables Ethernet-based communication for the 3500/40M 176449-01, supporting remote diagnostics and cloud integration.
- 3500/53 Displacement Module: Complements the 3500/40M 176449-01 by monitoring shaft displacement, providing comprehensive mechanical health data.
Installation and Maintenance: BENTLY 3500/40M 176449-01
Pre-installation Preparations:
Before installing the 3500/40M 176449-01, verify the 3500 Rack is properly grounded and the power supply (24V DC) matches module requirements. Clean the rack slot and ensure no debris is present. Slide the module into the designated slot, securing it with retention brackets. Connect proximity probes (e.g., 106M1081-01) to the input terminals, ensuring shielded wiring to minimize EMI. Configure communication parameters via Bently Nevada’s configuration software, testing signal integrity before commissioning.
Before installing the 3500/40M 176449-01, verify the 3500 Rack is properly grounded and the power supply (24V DC) matches module requirements. Clean the rack slot and ensure no debris is present. Slide the module into the designated slot, securing it with retention brackets. Connect proximity probes (e.g., 106M1081-01) to the input terminals, ensuring shielded wiring to minimize EMI. Configure communication parameters via Bently Nevada’s configuration software, testing signal integrity before commissioning.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for loose connections, damaged cables, or overheating. Use the module’s LED indicators to verify operational status and identify fault conditions promptly.
- Calibration Verification: Annually calibrate the module using a certified vibration fixture to maintain measurement accuracy. Reference Bently Nevada’s procedures to ensure compliance with API 670 standards.
- Firmware Updates: Periodically update the module’s firmware to access new features and bug fixes, using the official ToolboxST software to maintain system compatibility.
- Spare Parts Management: Keep a spare 3500/40M 176449-01 on hand, leveraging our global supply chain for quick replacement of discontinued or urgent components.
Product Guarantee: BENTLY 3500/40M 176449-01
Our company provides a 12-month quality warranty for the BENTLY 3500/40M 176449-01 Proximitor™ module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with abnormal output, communication failures, or physical damage at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable products and exceptional service. The 3500/40M 176449-01 exemplifies our dedication to quality, offering the precision and durability required for critical machinery monitoring. Contact us today to enhance your predictive maintenance strategy with this advanced vibration monitoring module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for Bently Nevada’s official technical manuals.
