BENTLY 330101-00-25-20-12-05 3300 XL Proximity Probe
Product Overview
The BENTLY 330101-00-25-20-12-05 is a high-precision 3300 XL Proximity Probe engineered for continuous monitoring of shaft displacement and vibration in critical rotating machinery. As a core component of Bently Nevada’s 3300 Series Machinery Protection System, this probe converts mechanical movements into electrical signals, enabling real-time analysis of shaft position, vibration amplitude, and dynamic behavior in turbines, compressors, and generators. The 330101-00-25-20-12-05 integrates seamlessly with 3300 Series monitors (e.g., 3300/42M) and 3500 Series rack systems, delivering reliable measurements to support predictive maintenance across industries such as oil & gas, power generation, and manufacturing.
Featuring a rugged stainless-steel construction, the BENTLY 330101-00-25-20-12-05 includes an 8 mm diameter probe tip designed for harsh industrial environments. The probe offers a measurement range of 0–250 mils (0–6.35 mm) with ±0.5% linearity, ensuring precise detection of shaft movements. Its hermetically sealed enclosure (IP65-rated) and corrosion-resistant materials protect against dust, moisture, and chemical exposure, while the wide temperature range (-40°C to +177°C) makes it suitable for high-temperature applications. The probe supports standard 2-wire installations, simplifying integration with existing monitoring networks and reducing installation complexity.
In automation ecosystems, the 330101-00-25-20-12-05 serves as a front-end sensor for machinery protection systems, feeding real-time displacement data to monitoring modules for trend analysis and alarm activation. Its compatibility with industry standards (e.g., API 670) ensures compliance with safety regulations, while low-output impedance minimizes electromagnetic interference. By providing actionable insights into shaft health, this probe helps reduce unplanned downtime and extend equipment lifespan in mission-critical operations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 330101-00-25-20-12-05 |
| Manufacturer | Bently Nevada |
| Product Type | Proximity Probe |
| Series | 3300 XL |
| Probe Tip Diameter | 8 mm |
| Measurement Range | 0–250 mils (0–6.35 mm) |
| Linearity | ±0.5% of full scale |
| Output Signal | Proportional to displacement (via companion monitor) |
| Excitation | 24 V DC (supplied by monitor) |
| Physical Dimensions | 8 mm (diameter) × 50 mm (length) |
| Weight | 0.15 kg |
| Operating Temperature | -40°C to +177°C |
| Mounting | Threaded (1/2-20 UNF or M14×1.5) |
| Environmental Rating | IP65, NEMA 4X |
Key Features and Advantages
High-Accuracy Displacement Sensing: The 330101-00-25-20-12-05 provides precise shaft displacement measurements with ±0.5% linearity, enabling early detection of misalignment, bearing wear, or shaft rubs. Its 0–250 mils range accommodates both minor and significant movements, supporting comprehensive machinery health analysis.
Rugged Industrial Design: Built with stainless steel and an IP65-rated enclosure, the probe withstands harsh conditions, including water jets, dust, and corrosive gases. The high-temperature tolerance (up to +177°C) allows direct mounting on hot surfaces like turbine casings without additional cooling.
Seamless System Integration: Compatible with BENTLY’s 3300 and 3500 Series monitoring systems, the probe ensures easy integration with existing infrastructure. Its standard threaded mounting and industry-compatible signal output simplify installation in diverse industrial setups.
Reliable Signal Integrity: The probe’s low-output impedance and shielded design minimize electromagnetic interference, ensuring clean displacement signals. The non-contact sensing principle eliminates wear, enhancing long-term reliability and reducing maintenance needs.
Application Flexibility: Suitable for radial vibration and axial displacement monitoring, the 330101-00-25-20-12-05 supports various machinery types, from small motors to large turbines. Its modular design allows flexible installation in tight spaces or remote locations.
Application Areas
The BENTLY 330101-00-25-20-12-05 is essential for machinery health monitoring in critical industries:
- Oil & Gas: Monitors shaft displacement in compressors, pumps, and turbines at refineries and offshore platforms to detect misalignment or bearing degradation, preventing costly shutdowns.
- Power Generation: Installed on steam turbines and generators to ensure safe operation and grid stability, providing real-time data on shaft position and vibration.
- Manufacturing: Used in high-speed rotating equipment (e.g., motors, fans) in automotive and chemical plants to maintain production continuity and product quality.
- Aerospace & Defense: Deployed on test stands and propulsion systems to analyze shaft dynamics, ensuring compliance with performance standards.
Specific applications include:
- Radial Vibration Analysis: Measures shaft vibration to identify imbalance or misalignment issues before they escalate.
- Axial Displacement Monitoring: Tracks thrust bearing wear in turbines, triggering alarms when clearances exceed safe limits.
- Shaft Position Sensing: Monitors rotor movement in critical processes to prevent metal-to-metal contact and equipment damage.
Related Products
- BENTLY 330101-00-30-20-12-05: A variant with a longer probe length (30 mm), suitable for deeper mounting applications.
- BENTLY 330102 Proximity Probe: A 5 mm tip model for smaller machinery, offering similar functionality with a reduced measurement range.
- BENTLY 330103 Probe Housing: Mounting accessory for the 330101-00-25-20-12-05, ensuring secure installation.
- BENTLY 3300/42M Vibration Monitor: Processes probe signals for real-time vibration analysis and alarm outputs.
- BENTLY 3500/42M Proximitor Monitor: Integrates with the probe in 3500 Series racks for advanced machinery protection.
- BENTLY 330903 Extension Cable: Extends the probe system for remote mounting, available in various lengths.
Installation and Maintenance
Pre-installation Preparations:
Before installing the BENTLY 330101-00-25-20-12-05, verify the mounting surface is flat and free of debris. Use a torque wrench to secure the probe (recommended torque: 11–14 N·m) and route shielded cables away from high-voltage lines to minimize interference. Connect the probe to a compatible monitor (e.g., 3300/42M) and calibrate the system with a known displacement source to validate accuracy. Ensure proper grounding to reduce noise and signal distortion.
Before installing the BENTLY 330101-00-25-20-12-05, verify the mounting surface is flat and free of debris. Use a torque wrench to secure the probe (recommended torque: 11–14 N·m) and route shielded cables away from high-voltage lines to minimize interference. Connect the probe to a compatible monitor (e.g., 3300/42M) and calibrate the system with a known displacement source to validate accuracy. Ensure proper grounding to reduce noise and signal distortion.
Maintenance Suggestions:
- Routine Inspections: Quarterly checks for loose connections, cable wear, or corrosion on the probe. Use a handheld device to compare probe readings with reference sensors for calibration verification.
- Cleaning: Remove dust and debris from the probe tip using a dry cloth or compressed air, especially in dusty environments. Avoid solvents that may damage the protective coating.
- Periodic Calibration: Annually calibrate the probe using a precision displacement shaker to maintain measurement accuracy. Document results for compliance.
- Spare Parts Management: Store spare 330101-00-25-20-12-05 probes in a temperature-controlled environment (10–30°C) with low humidity. Test spares periodically to ensure functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the BENTLY 330101-00-25-20-12-05, covering hardware defects under normal use. In the event of performance issues, we offer prompt replacement services to minimize downtime. For legacy or urgent needs, our global supply chain ensures rapid delivery of the probe and related spares. Our technical support team assists with installation, calibration, and troubleshooting, ensuring reliable operation to safeguard your industrial systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
