BENTLY 330101-00-08-20-12-05 3300 XL Proximity Probe
Product Overview
The BENTLY 330101-00-08-20-12-05 is a high-precision 3300 XL Proximity Probe designed for continuous monitoring of shaft displacement and vibration in critical rotating machinery. As a core component of Bently Nevada’s 3300 Series Machinery Protection System, this probe converts mechanical movements into electrical signals, enabling real-time analysis of shaft position, vibration amplitude, and dynamic behavior in turbines, compressors, and generators. The 330101-00-08-20-12-05 integrates seamlessly with 3300 Series monitors (e.g., 3300/42M) and 3500 Series rack systems, delivering reliable measurements to support predictive maintenance across industries such as oil & gas, power generation, and manufacturing.
Featuring a rugged stainless-steel construction, the BENTLY 330101-00-08-20-12-05 includes an 8 mm diameter probe tip, 20 ft (6.1 m) extension cable, and integral temperature compensation for consistent performance. The probe provides a measurement range of 0–250 mils (0–6.35 mm) with ±0.5% linearity, ensuring precise detection of shaft movements. Its hermetically sealed enclosure (IP65-rated) and corrosion-resistant materials protect against dust, moisture, and chemical exposure, while the wide temperature range (-40°C to +177°C) makes it suitable for high-temperature applications. The probe supports standard 2-wire installations, simplifying integration with existing monitoring networks.
In automation ecosystems, the 330101-00-08-20-12-05 serves as a front-end sensor for machinery protection systems, feeding real-time displacement data to monitoring modules for trend analysis and alarm activation. Its compatibility with industry standards (e.g., API 670) ensures safety compliance, while low-output impedance minimizes electromagnetic interference. By providing actionable insights into shaft health, this probe helps reduce unplanned downtime and extend equipment lifespan.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 330101-00-08-20-12-05 |
| Manufacturer | Bently Nevada |
| Product Type | Proximity Probe |
| Series | 3300 XL |
| Probe Tip Diameter | 8 mm |
| Measurement Range | 0–250 mils (0–6.35 mm) |
| Linearity | ±0.5% of full scale |
| Output Signal | Proportional to displacement (via compatible monitor) |
| Excitation Voltage | 24 V DC (supplied by monitor) |
| Cable Length | 20 ft (6.1 m) |
| Physical Dimensions | Probe: 8 mm (diameter) × 50 mm (length); Cable: 6.1 m |
| Weight | 0.25 kg |
| Operating Temperature | -40°C to +177°C |
| Mounting | Threaded (1/2-20 UNF or M14×1.5) |
| Environmental Rating | IP65, NEMA 4X |
Key Features and Advantages
High-Accuracy Displacement Measurement: The 330101-00-08-20-12-05 provides precise shaft displacement readings with ±0.5% linearity, enabling early detection of misalignment or bearing wear. Its wide measurement range accommodates both minor and significant machinery movements, supporting comprehensive health analysis.
Rugged Industrial Design: The probe’s stainless-steel housing and IP65 rating protect against harsh conditions, including water jets, dust, and corrosive gases. The high-temperature tolerance (up to +177°C) allows direct mounting on hot surfaces like turbine casings without additional cooling.
Seamless System Integration: Compatible with BENTLY’s 3300 and 3500 Series monitoring systems, the probe simplifies integration with existing infrastructure. The standard cable length (20 ft) and industry-standard interface reduce installation complexity and costs.
Reliable Signal Integrity: Built-in temperature compensation and shielded cabling minimize environmental interference, ensuring consistent signal quality. The probe’s non-contact sensing principle eliminates wear, enhancing long-term reliability.
Application Flexibility: Suitable for radial vibration and axial displacement monitoring, the 330101-00-08-20-12-05 supports diverse machinery types. Its modular design allows flexible installation in tight spaces or remote locations.
Application Areas
The BENTLY 330101-00-08-20-12-05 is essential for machinery health monitoring in critical industries:
- Oil & Gas: Monitors shaft displacement in compressors, pumps, and turbines at refineries and offshore platforms to detect misalignment or bearing degradation.
- Power Generation: Installed on steam turbines and generators to ensure safe operation and grid stability by tracking shaft vibrations and position.
- Manufacturing: Used in high-speed rotating machinery (e.g., motors, fans) in automotive and chemical plants to maintain production continuity.
- Aerospace & Defense: Deployed on test stands and propulsion systems to analyze shaft dynamics for performance validation.
Specific applications include:
- Radial Vibration Analysis: Measures shaft vibration to identify imbalance or misalignment issues before they escalate.
- Axial Displacement Monitoring: Tracks thrust bearing wear in turbines, triggering alarms when clearances exceed safe limits.
- Shaft Position Sensing: Monitors rotor position in critical processes to prevent metal-to-metal contact.
Related Products
- BENTLY 330101-00-05-20-12-05: 5 mm tip variant for smaller machinery, offering a reduced measurement range.
- BENTLY 330101-00-11-20-12-05: 11 mm tip model for large shafts, compatible in multi-probe setups.
- BENTLY 3300/42M Vibration Monitor: Processes probe signals for real-time analysis and alarm outputs.
- BENTLY 3500/42M Proximitor Monitor: Integrates with the probe in 3500 Series racks for advanced protection.
- BENTLY 330903-00-25-00-00-00: Extension cable (25 ft) for remote probe mounting.
- BENTLY 330103-00-08-20-12-05: Probe with built-in housing for simplified installation.
Installation and Maintenance
Pre-installation Preparations:
Before installing the 330101-00-08-20-12-05, verify the mounting surface is flat and free of debris. Use a torque wrench to secure the probe (recommended torque: 11–14 N·m) and route the extension cable away from high-voltage lines. Connect the probe to a compatible monitor (e.g., 3300/42M) and ensure proper grounding to reduce noise. Calibrate the system with a known displacement source to validate accuracy.
Before installing the 330101-00-08-20-12-05, verify the mounting surface is flat and free of debris. Use a torque wrench to secure the probe (recommended torque: 11–14 N·m) and route the extension cable away from high-voltage lines. Connect the probe to a compatible monitor (e.g., 3300/42M) and ensure proper grounding to reduce noise. Calibrate the system with a known displacement source to validate accuracy.
Maintenance Suggestions:
- Routine Inspections: Quarterly check for loose connections, cable wear, or corrosion. Use a handheld vibrometer to compare probe readings with reference sensors.
- Cleaning: Remove dust from the probe tip using a dry cloth or compressed air, especially in dusty environments.
- Periodic Calibration: Annually calibrate the probe with a precision displacement shaker to maintain accuracy. Document results for compliance.
- Spare Parts Management: Store spare probes in a temperature-controlled environment (10–30°C) and test them periodically to ensure functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the BENTLY 330101-00-08-20-12-05, covering hardware defects under normal use. In the event of performance issues, we offer prompt replacement services. For legacy or urgent needs, our global supply chain ensures rapid delivery of spare parts. Our technical support team assists with installation, calibration, and troubleshooting to maintain system reliability.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
