BENTLY 135137-01 | Vibration Monitoring Module | 135462-01
BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 - Image 2
BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 - Image 3
BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 - Image 4
BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 - Image 5
BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 - Image 6

BENTLY 135137-01 | Vibration Monitoring Module | 135462-01 Bently Nevada

Original price was: $780.00.Current price is: $538.00.

Brand model:Bently Nevada
Product Name:135137-01
Warranty: 1 year
Size:102 mm (W) × 152 mm (H) × 203 mm (D)
Weight:1.5kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Get a Quote
Category: Brand:

Description

BENTLY 135137-01 Product Specification

Product Overview

The BENTLY 135137-01 is a high-precision vibration monitoring module designed for BENTLY’s 3500 Series Machinery Protection System, a cornerstone of industrial asset management in critical infrastructure. Engineered to deliver real-time vibration analysis for rotating equipment, this module supports two channels of proximity probe or accelerometer inputs, enabling continuous monitoring of shaft displacement, velocity, and acceleration in turbines, compressors, and generators. The BENTLY 135137-01 integrates advanced signal conditioning with rugged hardware, making it essential for industries such as oil and gas, power generation, and manufacturing where unexpected downtime poses significant risks.



As part of the 3500 Series, the BENTLY 135137-01 leverages BENTLY NEVADA’s decades of expertise in machinery health monitoring. Its software-configurable design allows users to customize alarm thresholds, filter settings, and data logging parameters via the 3500 Series Engineering Tool, ensuring optimal performance across diverse operational conditions. The module’s compact form factor (210 mm × 150 mm × 100 mm) and IP23-rated enclosure protect against dust, moisture, and electromagnetic interference, while its 2 kg weight simplifies installation in 19″ control racks.



In automation systems, the BENTLY 135137-01 acts as a frontline diagnostic tool, converting raw vibration data into actionable insights. Its high-frequency response (0–10 kHz) captures rapid shaft movements, while built-in diagnostics monitor channel health and alert operators to anomalies such as imbalance or bearing wear. By integrating with higher-level control systems via RS-485, the module supports predictive maintenance strategies, reducing unplanned outages and extending equipment lifespan.

Technical Specifications

Parameter Name Parameter Value
Product Model BENTLY 135137-01
Manufacturer BENTLY NEVADA
Product Type Vibration Monitoring Module
Input Channels 2 channels (proximity probes/accelerometers)
Frequency Range 0–10 kHz
Input Signal Range 0–10 VDC, 4–20 mA
Power Supply 24 VDC ±10%
Physical Dimensions 210 mm (W) × 150 mm (H) × 100 mm (D)
Weight 2.0 kg
Communication Interface RS-485 (Modbus RTU compatible)
Operating Temperature -25°C to +60°C
Humidity 5–95% non-condensing
Certifications CE, UL, ISO 10816

Main Features and Advantages

Dual-Channel Precision Monitoring: The BENTLY 135137-01 enables simultaneous analysis of two critical measurement points, such as horizontal and vertical shaft vibrations, providing comprehensive insights into machinery dynamics. This dual-channel design reduces installation complexity in multi-probe setups, eliminating the need for additional modules.



Adaptive Signal Processing: With configurable filters (low-pass, band-pass, high-pass), the module tailors data acquisition to specific machinery types—from slow-rotating turbines to high-speed compressors. Engineers can adjust sensitivity (up to 200 mV/mil) and linear range (0–2500 μm) via BENTLY’s proprietary software, optimizing performance for each application.



Rugged Industrial Design: The module’s stainless-steel housing and conformal-coated PCBs withstand harsh environments, including offshore platforms, power plant turbines, and manufacturing floors. Its vibration resistance (5–500 Hz, 2 g) and wide temperature range ensure reliable operation in extreme conditions without performance degradation.



Seamless System Integration: As a 3500 Series component, the BENTLY 135137-01 interfaces directly with modules like the 3500/92 Communication Gateway, enabling real-time data transmission to SCADA systems. This integration supports remote monitoring via HMIs, allowing operators to visualize trends and trigger alarms from central control rooms.



Predictive Maintenance Capability: Built-in trend analysis and fault detection algorithms identify developing issues (e.g., increasing vibration amplitudes) before they escalate. The module stores historical data for post-fault analysis, helping maintenance teams implement proactive strategies to minimize downtime.

Application Areas

The BENTLY 135137-01 is strategically deployed in industries where machinery reliability is non-negotiable:



  1. Oil and Gas Upstream:
    • Monitors subsea pump vibrations in offshore platforms, detecting cavitation or seal wear before catastrophic failure.
    • Integrates with pipeline compressor stations to maintain optimal flow rates and prevent costly shutdowns.
  2. Power Generation:
    • Analyzes steam turbine shaft vibrations in combined cycle power plants, ensuring grid stability and maximizing energy efficiency.
    • Supports condition-based maintenance of generator rotors, reducing unplanned outages in utility-scale facilities.
  3. Heavy Manufacturing:
    • Controls vibrations in high-speed paper mill rollers to maintain product thickness consistency.
    • Monitors motor bearings in automotive assembly lines, preventing production delays due to equipment failure.
  4. Marine Propulsion:
    • Ensures safe operation of ship turbines by detecting alignment issues in propulsion systems.
    • Enables predictive maintenance of offshore drilling rig motors, minimizing downtime in remote locations.

Related Products

  • BENTLY 3500/22M 146031-01: A 4-channel vibration module for complex setups, offering double the channel density of the BENTLY 135137-01.
  • BENTLY 3500/15 125840-02: A power input module providing stable 24 VDC to the BENTLY 135137-01 and other 3500 Series components.
  • BENTLY 330102-00-05-10-02-00: A 5 mm proximity probe compatible with the BENTLY 135137-01, ideal for shaft displacement measurements.
  • BENTLY 3500/42 129408-01: A temperature monitor module complementing the BENTLY 135137-01 to create holistic machinery health profiles.
  • BENTLY 3500/95 129411-01: A redundant power supply ensuring continuous operation of the BENTLY 135137-01 in mission-critical applications.

Installation and Maintenance

Pre-installation Preparations:
Before installing the BENTLY 135137-01, verify the following:



  • The control rack is grounded to prevent electrostatic discharge, and the power supply matches 24 VDC ±10%.
  • Proximity probes (e.g., BENTLY 330102) are calibrated to 7.87 V/mm and mounted with a 1.5 mm initial gap from the target shaft.
  • RS-485 communication parameters (baud rate, parity) are configured via the 3500 Series Engineering Tool to match the host system.



Maintenance Suggestions:



  • Routine Checks: Monthly visual inspections of front-panel LEDs (green for normal operation, red for faults) and cable connections to prevent loose contacts.
  • Annual Calibration: Use a BENTLY 3500 System Calibrator to verify channel accuracy, adjusting for any drift in sensitivity or linearity.
  • Environmental Monitoring: Ensure ambient temperature remains below 60°C and humidity below 95% non-condensing, cleaning dust from ventilation slots quarterly.
  • Firmware Updates: Periodically update the module’s firmware to access new diagnostic features and compatibility with evolving 3500 Series software.

Product Warranty

Our company provides a one-year quality warranty for the BENTLY 135137-01, covering hardware defects arising from non-human factors. During the warranty period, we offer replacement services for modules with abnormal performance or functional failures. For discontinued models like the BENTLY 135137-01, our global supply chain ensures rapid fulfillment of urgent orders, supported by a network of certified technicians for post-warranty repairs. We are committed to maintaining your industrial systems’ reliability through responsive service and extensive legacy part inventory.



Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com



Note: This description is based on BENTLY NEVADA’s technical specifications and industry applications. For detailed installation procedures, refer to the BENTLY 135137-01 user manual or contact our technical support team.
