BENTLY 128277-01 Product Specification
Product Overview
The BENTLY 128277-01 is a high-precision vibration monitoring module designed for BENTLY’s 3500 Series Machinery Protection System, a cornerstone of industrial asset management in critical infrastructure. Engineered to deliver real-time vibration analysis for rotating equipment, this module supports dual-channel input for simultaneous monitoring of shaft displacement and velocity in turbines, compressors, and generators. As part of the 3500 Series, the BENTLY 128277-01 integrates seamlessly with other system components to form a comprehensive machinery health monitoring solution, ensuring early detection of anomalies that could lead to costly downtime.
Featuring advanced signal conditioning and a 16-bit analog-to-digital converter, the BENTLY 128277-01 processes inputs from proximity probes and accelerometers with micron-level accuracy. Its software-configurable design allows users to customize alarm thresholds, filter settings, and data logging parameters via BENTLY’s proprietary interface, adapting to diverse operational requirements. The module’s rugged IP23-rated enclosure and conformal-coated PCBs ensure reliable performance in harsh environments, while its compact form factor (210 mm × 150 mm × 100 mm) and 2 kg weight simplify installation in 19″ control racks.
In automation systems, the BENTLY 128277-01 acts as a frontline diagnostic tool, converting vibration data into actionable insights for predictive maintenance. Its RS-485 communication interface enables real-time data transmission to PLCs, HMIs, and supervisory systems, supporting remote monitoring and proactive equipment care. By combining high-precision measurement with robust durability, the BENTLY 128277-01 empowers industries to optimize machinery reliability and extend asset lifespan.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | BENTLY |
| Manufacturer | BENTLY NEVADA |
| Product Type | Vibration Monitoring Module |
| Input Channels | 2 channels (proximity probes/accelerometers) |
| Frequency Range | 0–10 kHz |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 210 mm (W) × 150 mm (H) × 100 mm (D) |
| Weight | 2 kg |
| Communication Interface | RS-485 |
| Operating Temperature | -25°C to +60°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL |
Main Features and Advantages
Dual-Channel Precision Monitoring: The BENTLY 128277-01 supports simultaneous analysis of two vibration channels, enabling comprehensive assessment of shaft dynamics of machinery. This capability allows early detection of imbalances, misalignments, or bearing wear, reducing the risk of unexpected failures in critical equipment.
Adaptive Signal Processing: With configurable filter settings (low-pass, band-pass) and alarm thresholds, the module adapts to unique machinery profiles. Engineers can tailor parameters via BENTLY’s software to prioritize specific frequency ranges or vibration severity levels, enhancing diagnostic accuracy for applications like turbine blade monitoring or compressor shaft analysis.
Rugged Industrial Design: Encased in an IP23-rated stainless-steel housing, the BENTLY 128277-01 withstands harsh conditions, including dust, moisture, and electromagnetic interference (EMI). Its wide temperature range (-25°C to +60°C) makes it suitable for offshore platforms, power plants, and manufacturing floors with extreme environmental demands.
Seamless System Integration: As part of the 3500 Series, the module connects directly to BENTLY’s 3500/22M vibration monitors and 3500/92 communication gateways, forming a unified protection system. This integration eliminates compatibility issues and streamlines data aggregation for centralized machinery health management.
Real-Time Diagnostics: Built-in self-test functions and front-panel LED indicators provide instant status updates, while diagnostic logs track historical performance trends. This proactive approach reduces mean time to repair (MTTR) by identifying potential issues before they escalate.
Application Areas
The BENTLY 128277-01 is critical in industries where machinery reliability directly impacts operational continuity:
-
Power Generation:
- Monitors steam turbine shaft vibration in combined cycle power plants, adjusting for thermal expansion and load fluctuations to maintain grid stability.
- Integrates with generator systems to prevent stator-rotor contact by measuring radial and axial displacement in real time.
-
Oil and Gas:
- Controls compressor vibration in refinery processing units, ensuring optimal flow rates and preventing catastrophic failures in distillation columns.
- Installed in offshore platforms to monitor drilling equipment under high-pressure, high-temperature conditions, supporting safe extraction operations.
-
Manufacturing:
- Maintains precision in automotive engine test stands by analyzing crankshaft vibration during performance evaluations.
- Monitors paper mill roll alignment to prevent sheet defects in high-speed production lines, improving yield and reducing waste.
-
Water/Wastewater Treatment:
- Ensures reliable operation of wastewater pumps by detecting cavitation-induced vibration, preventing premature seal failure.
- Integrates with SCADA systems to remotely monitor treatment plant equipment, enabling data-driven maintenance scheduling.
Related Products
- BENTLY 3500/22M 146031-01: A 4-channel vibration module offering higher channel density for complex machinery setups, often used alongside the BENTLY 128277-01 in multi-probe configurations.
- BENTLY 3500/15 125840-02: A power input module providing stable 24 VDC to the BENTLY 128277-01 and other 3500 Series components, ensuring uninterrupted operation.
- BENTLY 3500/32 129407-01: A speed/torque monitor that synchronizes vibration data with rotational speed, essential for analyzing resonance in high-speed turbines.
- BENTLY 3500/42 129408-01: A temperature monitor complementing vibration analysis by identifying thermal stress factors that contribute to equipment degradation.
- BENTLY 330102-00-05-10-02-00: A 5 mm proximity probe paired with the BENTLY 128277-01 for precise shaft displacement measurement in tight installation spaces.
Installation and Maintenance
Pre-installation Preparation:
Before installing the BENTLY 128277-01, verify the following:
Before installing the BENTLY 128277-01, verify the following:
- Ensure the control rack is grounded to prevent electrostatic discharge (ESD) and the power supply matches 24 VDC ±10%. Use BENTLY’s configuration software to define input types (proximity probe or accelerometer) and set initial alarm thresholds based on machinery specifications.
- Mount the module in a 19″ rack with 50 mm clearance for airflow, avoiding adjacent high-heat components. Route sensor cables separately from high-voltage wiring to minimize EMI interference.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks of front-panel LEDs (green for normal, red for faults) and cleaning dust from ventilation slots. Annually calibrate input channels using a BENTLY 3300 System Calibrator to maintain measurement accuracy.
- Firmware Management: Periodically update firmware via BENTLY’s software to access new diagnostic features and compatibility with emerging industry standards.
- Environmental Monitoring: Regularly assess ambient conditions to ensure temperature (-25°C to +60°C) and humidity (5–95%) remain within limits, replacing seals or ventilation filters as needed.
Product Warranty
Our company provides a one-year quality warranty for the BENTLY 128277-01, covering hardware failures from non-human causes. During the warranty period, we replace any module with abnormal performance or functional defects. For discontinued models like the BENTLY 128277-01, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services, leveraging certified technicians to maintain your system’s reliability over its lifecycle.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This description is based on BENTLY’s official specifications and industry applications. For detailed installation guides, refer to the BENTLY 128277-01 user manual or contact our technical support team.
