BENTLY 125760-01 Product Specification
Product Overview
The BENTLY 125760-01 is a high-reliability power supply module engineered for BENTLY NEVADA’s 3500 Series Machinery Protection System. As a critical component in industrial automation setups, this module delivers stable DC power to monitoring and control devices, ensuring continuous operation of rotating machinery in harsh environments. The BENTLY 125760-01 is part of BENTLY’s advanced 3500 platform, renowned for its precision and durability in mission-critical applications across industries such as oil and gas, power generation, and manufacturing.
Designed with a wide input voltage range (85–264 VAC), the BENTLY 125760-01 adapts to diverse power sources while maintaining a regulated 24 VDC output. Its compact form factor (210 mm × 150 mm × 100 mm) and lightweight design (2 kg) facilitate easy integration into 19″ racks, while the rugged metal enclosure protects against dust, moisture, and electromagnetic interference (EMI). The module supports hot-swappable installation, enabling maintenance without system shutdowns, a critical feature for 24/7 industrial operations.
In automation systems, the BENTLY 125760-01 acts as a foundational power source for modules like vibration monitors, proximity probes, and communication interfaces within the 3500 Series. Its built-in diagnostic capabilities monitor voltage stability and thermal conditions, providing real-time feedback via front-panel LEDs. By combining reliable power delivery with advanced protection features, the module enhances system availability and reduces downtime in critical machinery applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | BENTLY 125760-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Power Supply Module |
| Input Voltage | 85–264 VAC (universal input) |
| Output Voltage | 24 VDC ±10% |
| Output Current | 5 A maximum |
| Efficiency | 85% typical |
| Physical Dimensions | 210 mm (W) × 150 mm (H) × 100 mm (D) |
| Weight | 2 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +85°C |
| Enclosure Rating | IP23 |
| Certifications | CE, UL, CSA |
Main Features and Advantages
Universal Power Adaptability: The BENTLY 125760-01 supports a broad input voltage range (85–264 VAC), eliminating the need for region-specific power converters. This versatility makes it suitable for global deployments in diverse industrial settings, from onshore plants to offshore platforms.
Reliable Power Regulation: With a stable 24 VDC output, the module ensures consistent power delivery to critical monitoring components, preventing voltage fluctuations that could lead to false alarms or equipment malfunction. Its built-in overcurrent and overvoltage protection safeguards connected modules from damage.
Hot-Swap Capability: The module’s hot-swappable design allows replacement without powering down the 3500 Series rack, minimizing downtime during maintenance. This feature is invaluable in continuous operation environments where system availability is non-negotiable.
Advanced Diagnostics: Front-panel LED indicators provide real-time status updates (power on, fault, overload), enabling quick troubleshooting. The module also integrates with BENTLY’s diagnostic software to log power performance data, supporting proactive maintenance strategies.
Rugged Industrial Design: Constructed with a metal enclosure and conformal-coated PCBs, the BENTLY 125760-01 resists harsh conditions, including vibration, dust, and humidity. Its wide operating temperature range ensures reliability in extreme industrial environments.
Application Areas
The BENTLY 125760-01 is essential in industries requiring stable power for machinery protection systems:
-
Oil and Gas:
- Powers vibration monitoring systems in refineries, pipeline compressor stations, and offshore platforms, ensuring continuous operation of critical equipment.
- Supports emergency shutdown (ESD) systems by maintaining power to sensors and actuators during voltage fluctuations.
-
Power Generation:
- Supplies stable DC power to turbine monitoring modules in power plants, enabling real-time vibration analysis and preventing catastrophic failures.
- Integrates with generator control systems to maintain grid stability and optimize energy production.
-
Manufacturing:
- Powers robotic arms, conveyor drives, and quality control sensors in automotive and pharmaceutical plants, reducing production interruptions.
- Maintains consistent power to high-speed rotating machinery, improving product quality and equipment lifespan.
-
Water/Wastewater Treatment:
- Controls pump stations and treatment process sensors, ensuring consistent water flow and quality.
- Supports SCADA systems for remote monitoring of distributed water facilities.
Related Products
- BENTLY 125840-02 (3500/15): A low-voltage AC power input module compatible with the BENTLY 125760-01, offering redundant power configurations for enhanced reliability.
- BENTLY 146031-01 (3500/22M): A vibration monitoring module that relies on the BENTLY 125760-01 for power, enabling precise shaft vibration analysis.
- BENTLY 129408-01 (3500/42): A temperature monitor module paired with the BENTLY 125760-01 to support comprehensive machinery health tracking.
- BENTLY 129410-01 (3500/92): A communication gateway module that integrates with the BENTLY 125760-01 for data transmission to higher-level control systems.
- BENTLY 129411-01 (3500/95): A redundant power supply module for fault-tolerant setups, complementing the BENTLY 125760-01 in mission-critical applications.
Installation and Maintenance
Pre-installation Preparation:
Before installing the BENTLY 125760-01, ensure the following:
Before installing the BENTLY 125760-01, ensure the following:
- Verify the input voltage matches the module’s range (85–264 VAC) and that the control rack is properly grounded to prevent electrostatic discharge (ESD).
- Use BENTLY’s installation guidelines to secure the module in a 19″ rack, allowing at least 50 mm of clearance for airflow.
- Connect the output terminals to the 3500 Series backplane, ensuring proper polarity to avoid damage.
Maintenance Recommendations:
- Routine Inspections: Monthly checks of front-panel LEDs to confirm normal operation (green for power, red for faults). Clean dust from ventilation slots to maintain optimal cooling.
- Load Testing: Quarterly verification of output voltage and current using a multimeter to ensure specifications are met, especially in high-load applications.
- Environmental Monitoring: Regularly assess ambient temperature and humidity to prevent overheating or moisture damage, particularly in harsh environments.
- Spare Parts Management: Keep a spare BENTLY 125760-01 on hand for quick replacement, leveraging its hot-swappable design to minimize downtime.
Product Warranty
Our company provides a one-year quality warranty for the BENTLY 125760-01, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits voltage instability or functional defects. For discontinued models like the BENTLY 125760-01, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services, ensuring your machinery protection system remains powered and reliable over the long term.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This description is based on BENTLY NEVADA’s technical specifications and industry applications. For detailed installation guides, refer to the BENTLY 125760-01 user manual or contact our technical support team.
