BENTLY 125680-01 Product Specification
Product Overview
The BENTLY 125680-01 is a high-reliability power supply module designed for BENTLY NEVADA’s 3500 Series Machinery Protection System. Engineered to deliver stable DC power to critical monitoring components, this module serves as a foundational element in industrial automation setups, ensuring continuous operation of vibration monitors, proximity probes, and communication interfaces. The BENTLY 125680-01 integrates advanced power regulation technology with rugged construction, making it ideal for harsh environments in industries such as oil and gas, power generation, and manufacturing.
As part of the 3500 Series, the BENTLY 125680-01 supports redundant power configurations, minimizing downtime in mission-critical applications. It features a wide input voltage range (85–264 VAC) and converts it to a stable 24 VDC output, compatible with all 3500 Series modules. The module’s compact design (210 mm × 150 mm × 100 mm) and lightweight construction (2 kg) facilitate easy integration into 19″ racks, while its IP23-rated enclosure protects against dust and moisture.
In automation systems, the BENTLY 125680-01 acts as a fail-safe power source, monitoring input voltage fluctuations and providing real-time diagnostics via front-panel LEDs. Its hot-swappable design allows replacement without system shutdowns, a critical feature for 24/7 industrial operations. By combining robust power management with seamless compatibility, the module enhances the reliability of machinery protection systems, enabling predictive maintenance and reducing operational risks.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | BENTLY 125680-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Power Supply Module |
| Input Voltage | 85–264 VAC (50/60 Hz) |
| Output Voltage | 24 VDC ±1% |
| Output Current | 5 A maximum |
| Efficiency | 85% typical |
| Physical Dimensions | 210 mm (W) × 150 mm (H) × 100 mm (D) |
| Weight | 2 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Enclosure Protection | IP23 |
| Certifications | CE, UL, CSA |
Main Features and Advantages
Redundant Power Architecture: The BENTLY 125680-01 supports parallel installation with another power supply module, creating a redundant system that ensures continuous operation if one module fails. This feature is vital in critical applications where downtime is unacceptable.
Wide Input Voltage Range: Capable of handling 85–264 VAC, the module adapts to diverse power grids, eliminating the need for voltage converters. This flexibility simplifies installation in global industrial settings with varying electrical standards.
Advanced Thermal Management: Built-in temperature sensors and a quiet fan prevent overheating, ensuring stable performance even in high-temperature environments. The module’s thermal shutdown protection further safeguards against damage from extreme heat.
Hot-Swap Capability: The module can be replaced while the system remains powered, reducing maintenance downtime. This feature is particularly valuable in 24/7 operations like power plants or offshore platforms.
Comprehensive Diagnostics: Front-panel LED indicators display power status, overload conditions, and fault warnings, enabling quick troubleshooting. The module also communicates diagnostic data to the system’s HMI, supporting proactive maintenance.
Application Areas
The BENTLY 125680-01 is essential in industries requiring reliable power for machinery protection systems:
-
Oil and Gas:
- Powers vibration monitoring systems in offshore platforms and refineries, ensuring continuous operation of pumps and compressors.
- Supports emergency shutdown (ESD) systems by maintaining power to critical sensors and actuators.
-
Power Generation:
- Maintains stable power to turbine monitoring systems in power plants, enabling real-time vibration analysis and preventing costly failures.
- Integrates with generator control systems to ensure uninterrupted operation during load fluctuations.
-
Manufacturing:
- Powers robotic arms and high-speed conveyor systems in automotive plants, minimizing production downtime.
- Supports quality control equipment in pharmaceutical manufacturing, where precise monitoring is critical for compliance.
-
Water/Wastewater Treatment:
- Ensures reliable operation of pump stations and treatment process monitors, maintaining consistent water quality.
- Powers SCADA systems for remote monitoring of distributed water infrastructure.
Related Products
- BENTLY 125840-02: A low-voltage AC power input module compatible with the BENTLY 125680-01, often used in redundant power configurations.
- BENTLY 3500/15: A power supply module with similar specifications but designed for smaller rack setups, suitable for compact applications.
- BENTLY 3500/95: A redundant power supply system that pairs with the BENTLY 125680-01 to enhance system availability.
- BENTLY 3500/22M: A vibration monitoring module that relies on the BENTLY 125680-01 for stable power in rotating machinery applications.
- BENTLY 3500/42M: A temperature monitoring module compatible with the BENTLY 125680-01, enabling comprehensive machinery health analysis.
Installation and Maintenance
Pre-installation Preparation:
Before installing the BENTLY 125680-01, ensure the following:
Before installing the BENTLY 125680-01, ensure the following:
- Verify the input voltage matches the module’s range (85–264 VAC) and that the control rack is properly grounded to prevent electrical interference.
- Use BENTLY’s installation guidelines to secure the module in a 19″ rack, allowing at least 50 mm of clearance for airflow.
- If configuring redundancy, install a second BENTLY 125680-01 in parallel, following the wiring diagram provided in the user manual.
Maintenance Recommendations:
- Routine Checks: Monthly visual inspections of front-panel LEDs to confirm normal operation (green for power, amber for warnings). Clean dust from ventilation slots to maintain optimal cooling.
- Load Testing: Annually verify the module’s output voltage and current using a multimeter, ensuring it meets specifications under full load.
- Firmware Updates: Periodically check BENTLY’s website for firmware updates, which may include performance improvements or compatibility fixes.
- Redundancy Testing: Biannually simulate a power module failure to ensure the redundant system switches seamlessly, minimizing downtime risks.
Product Warranty
Our company provides a one-year quality warranty for the BENTLY 125680-01, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits abnormal power output or functional defects. For discontinued models like the BENTLY 125680-01, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services, ensuring your machinery protection system remains reliable over its lifecycle.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This description is based on BENTLY NEVADA’s technical specifications and industry applications. For detailed installation guides, refer to the BENTLY 125680-01 user manual or contact our technical support team.
