BENTLY 1-536067-4 Connector
Product Overview: BENTLY 1-536067-4
The BENTLY 1-536067-4 connector is a high-reliability industrial connectivity solution designed for seamless integration in Bently Nevada’s 3300 Series Machinery Health Monitoring System. Engineered to establish robust electrical connections between vibration proximity probes, extension cables, and monitoring modules, this connector ensures precise signal transmission in mission-critical machinery health applications. As a critical component of the 3300 Series ecosystem, the 1-536067-4 plays a pivotal role in maintaining measurement accuracy and system reliability across harsh industrial environments.
Featuring a 18-pin configuration and rugged stainless-steel construction, the 1-536067-4 withstands mechanical stress, corrosion, and electromagnetic interference (EMI), making it suitable for use in power plants, refineries, and manufacturing facilities. The connector’s IP65 protection rating and -50°C to +177°C operating temperature range ensure consistent performance in extreme conditions, while its precision-machined contacts deliver low resistance and high signal integrity. Designed for compatibility with Bently Nevada’s proximity probes (e.g., 106M1081-01) and extension cables (e.g., 135489-03), the 1-536067-4 simplifies system installation and maintenance, reducing downtime and enhancing overall monitoring efficiency.
In automation systems, the 1-536067-4 serves as a foundational element for vibration monitoring setups, enabling reliable data transmission between field sensors and control racks. Its role in preserving measurement fidelity is critical for early fault detection in rotating machinery, supporting predictive maintenance strategies that minimize unplanned downtime and optimize operational efficiency.
Technical Specifications: BENTLY 1-536067-4
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 1-536067-4 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Industrial Connector |
| Pin Configuration | 18-pin (male/female) |
| Contact Material | Gold-plated copper |
| Operating Temperature | -50°C to +177°C |
| Storage Temperature | -50°C to +200°C |
| Protection Rating | IP65 |
| Mechanical Life | 500+ mating cycles |
| Insertion Force | ≤50 N |
| Withdrawal Force | ≤80 N |
| Physical Dimensions | 40 mm (L) × 30 mm (W) × 25 mm (H) |
| Weight | 0.15 kg |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 1-536067-4
Rugged Industrial Design: The 1-536067-4 features a stainless-steel housing and gold-plated contacts, resisting corrosion, abrasion, and EMI to maintain signal integrity in harsh environments. This durability reduces maintenance needs and extends service life in high-vibration or chemically aggressive settings.
Precision Signal Transmission: Engineered for minimal contact resistance and capacitance, the connector preserves the high sensitivity of Bently Nevada probes, ensuring accurate vibration measurements. Its low-impedance design minimizes signal loss, critical for early detection of machinery anomalies.
Wide Environmental Tolerance: With an operating range spanning -50°C to +177°C and an IP65 rating, the 1-536067-4 withstands extreme temperatures, dust, and water jets, making it suitable for demanding industrial applications from arctic oil fields to high-temperature furnace areas.
Seamless System Integration: Designed specifically for Bently Nevada’s 3300 Series, the connector ensures plug-and-play compatibility with proximity probes, extension cables, and Proximitor modules (e.g., 3300/40M 173343-01). This standardization simplifies system setup and reduces compatibility risks.
Easy Installation and Maintenance: The connector’s intuitive design allows quick mating and unmating, while its rugged construction requires minimal upkeep. Regular visual inspections for wear or corrosion ensure long-term reliability, supporting efficient maintenance workflows.
Application Areas: BENTLY 1-536067-4
The BENTLY 1-536067-4 connector is essential for industries relying on precise machinery health monitoring:
- Power Generation: Connects vibration probes to monitoring systems in steam turbines, generators, and auxiliary equipment, enabling real-time health assessment in power plants. Its high-temperature tolerance suits installations near hot turbine components.
- Oil and Gas: Deployed in offshore platforms and refineries to link compressors, pumps, and motors with vibration monitoring systems. The connector’s corrosion resistance makes it ideal for saltwater and chemically active environments.
- Manufacturing: Used in CNC machines, presses, and robotic arms to ensure reliable vibration data transmission, supporting quality control and predictive maintenance in high-speed production lines.
- Water Treatment: Integrates vibration sensors with control systems in pump stations and wastewater treatment plants, maintaining continuous operation and regulatory compliance.
- Aerospace and Defense: Supports condition monitoring of aircraft engines and military machinery, where reliable connectivity is critical for mission safety and readiness.
Related Products: BENTLY 1-536067-4
- BENTLY 106M1081-01 Vibration Proximity Probe: A 配套使用 probe that connects via the 1-536067-4 to measure shaft vibration and displacement.
- BENTLY 135489-03 Extension Cable: An extension cable that interfaces with the 1-536067-4 to extend probe reach in monitoring setups.
- BENTLY 3300/40M Proximitor Module (173343-01): Processes signals from the probe via the 1-536067-4, converting mechanical movements into electrical outputs.
- BENTLY 3300/32 Keyphasor Module (125712-01): Provides phase reference signals through the 1-536067-4 for precise vibration analysis.
- BENTLY 1-536068-2 Connector (20-pin): A variant with additional pins for expanded connectivity in complex monitoring systems.
- BENTLY 133488-02 Connector Repair Kit: Includes replacement contacts and seals for the 1-536067-4, enabling on-site maintenance.
Installation and Maintenance: BENTLY 1-536067-4
Pre-installation Preparations:
Before installing the 1-536067-4, inspect the connector for physical damage and ensure pins are free of debris or corrosion. Verify compatibility with connected components (e.g., probe 106M1081-01 and cable 135489-03). Align the connector’s keying features to prevent mis mating, then engage the latch mechanism until it clicks securely. Tighten any retaining screws to the specified torque (1.0–1.5 N·m) to prevent vibration-induced loosening.
Before installing the 1-536067-4, inspect the connector for physical damage and ensure pins are free of debris or corrosion. Verify compatibility with connected components (e.g., probe 106M1081-01 and cable 135489-03). Align the connector’s keying features to prevent mis mating, then engage the latch mechanism until it clicks securely. Tighten any retaining screws to the specified torque (1.0–1.5 N·m) to prevent vibration-induced loosening.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for bent pins, cracked housings, or corrosion on contact surfaces. Use a magnifying glass to inspect for minute debris that could affect connectivity.
- Cleaning: Annually clean contacts with isopropyl alcohol to remove oxidation, using a non-abrasive cloth. Avoid harsh chemicals that could damage the housing or plating.
- Environmental Monitoring: Regularly assess the connector’s operating environment for extreme temperatures or moisture, adding protective covers or rerouting cables if conditions exceed specifications.
- Spare Parts Management: Keep a spare 1-536067-4 and repair kits on hand to facilitate quick replacement. Leverage our global supply chain for urgent orders of discontinued components.
Product Guarantee: BENTLY 1-536067-4
Our company provides a 12-month quality warranty for the BENTLY 1-536067-4 connector, covering hardware defects from non-human causes. During the warranty period, we will replace any connector with faulty pins, housing damage, or signal degradation at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we prioritize reliable products and exceptional service. The 1-536067-4 exemplifies our commitment to quality, offering the durability and connectivity required for critical machinery monitoring. Contact us today to enhance your vibration monitoring setup with this robust connector.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for Bently Nevada’s official technical manuals.
