Product Overview: ABB REF615 HBFDACADABCIANN2XE
In modern power distribution systems, reliable protection and precise control are non-negotiable. ABB, a global leader in power and automation technologies, introduces the ABB REF615 HBFDACADABCIANN2XE—a state-of-the-art numerical protective relay engineered to safeguard medium-voltage networks with unmatched accuracy and intelligence. Designed for both utility and industrial applications, this relay combines advanced protection algorithms, seamless communication, and intuitive operation to minimize downtime and maximize system reliability.
The ABB REF615 HBFDACADABCIANN2XE builds on ABB’s decades of expertise in power system protection, integrating cutting-edge microprocessor technology with field-proven protection logic. Whether deployed in distribution substations, industrial plants, or renewable energy facilities, it acts as a vigilant guardian—detecting faults, isolating issues, and providing real-time data to keep networks running smoothly. It’s not just a protective device; it’s a critical component in ensuring the resilience of modern power infrastructure.
Technical Specifications — ABB REF615 HBFDACADABCIANN2XE
| Specification | Details |
|---|---|
| Protection Functions | Overcurrent, earth fault, distance, directional overcurrent, thermal overload |
| Rated Voltage | 110/220 V DC; 100/240 V AC |
| Current Inputs | 4 x 1 A or 5 A (configurable) |
| Voltage Inputs | 3-phase, 100 V or 220 V (phase-to-phase) |
| Communication | IEC 61850, Modbus TCP/IP, DNP3.0; 2 x Ethernet ports (100 Mbps) |
| Operating Temperature | -25°C to +70°C (-13°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity Resistance | 5%–95% RH, non-condensing |
| Protection Rating | IP40 (front panel); IP20 (rear terminals) |
| Certifications | IEC 61850, IEC 60255, UL, CSA, CE |
| Dimensions (WxHxD) | 144 mm x 216 mm x 176 mm |
| Weight | 1.8 kg |
ABB REF615 HBFDACADABCIANN2XE
Main Features and Advantages: ABB REF615 HBFDACADABCIANN2XE
The ABB REF615 HBFDACADABCIANN2XE stands out in power protection with features tailored to modern network demands:
1. Comprehensive Protection
Equipped with a full suite of protection functions—including overcurrent, earth fault, and distance protection—it covers all critical fault scenarios in medium-voltage networks. Advanced algorithms ensure fast fault detection (as low as 10 ms) and selective tripping, minimizing damage and reducing outage times.
2. Smart Communication
Built-in IEC 61850 compliance enables seamless integration with digital substations and SCADA systems, supporting real-time data exchange and remote control. Modbus and DNP3.0 protocols ensure compatibility with legacy systems, making it easy to retrofit into existing networks.
3. User-Centric Design
The intuitive HMI with a backlit display and tactile buttons simplifies configuration and monitoring. ABB’s PCM600 software allows offline programming and data analysis, reducing on-site setup time. Customizable logic blocks let engineers adapt the relay to specific network requirements without complex coding.
4. Robust Reliability
Engineered to withstand harsh environments, the ABB REF615 HBFDACADABCIANN2XE operates reliably in extreme temperatures, high humidity, and electromagnetic interference. Its rugged construction and redundant power supply options ensure uninterrupted performance in critical applications.
5. Diagnostic Intelligence
Continuous self-monitoring detects internal faults, communication errors, and sensor issues, providing actionable alerts via front-panel indicators and communication channels. This proactive diagnostics reduce maintenance costs and prevent unexpected failures.
Installation and Maintenance: ABB REF615 HBFDACADABCIANN2XE
Installing and maintaining the ABB REF615 HBFDACADABCIANN2XE is designed to be efficient and straightforward:
Installation
- Mounting: The relay fits standard 19-inch racks or panel mounting, with clear alignment markers for quick positioning. Its compact design saves space in crowded switchgear.
- Wiring: Color-coded terminal blocks and detailed labeling simplify connection of current transformers, voltage transformers, and communication cables. A removable terminal cover protects connections during installation.
- Configuration: Use the front-panel HMI or PCM600 software to set protection parameters, communication protocols, and logic settings. Factory presets for common applications reduce setup time.
Maintenance
- Routine Checks: Periodic verification via PCM600 ensures protection settings remain accurate. The relay’s self-diagnostics eliminate the need for frequent manual testing.
- Firmware Updates: Easily update via Ethernet or USB, ensuring access to the latest protection algorithms and features without removing the relay from service.
- Troubleshooting: Detailed event logs and fault records (storing up to 1000 events) simplify root-cause analysis, reducing downtime during incidents.
ABB REF615 HBFDACADABCIANN2XE
Application Fields: ABB REF615 HBFDACADABCIANN2XE
The ABB REF615 HBFDACADABCIANN2XE excels in diverse power system environments:
Utility Distribution
In medium-voltage substations, it protects feeders, transformers, and capacitors, ensuring reliable power delivery to residential and commercial areas. Its IEC 61850 compliance supports smart grid integration.
Industrial Plants
Manufacturing facilities, mines, and chemical plants rely on it to protect motors, generators, and distribution lines, preventing costly production halts due to electrical faults.
Renewable Energy
Solar and wind farms use the ABB REF615 HBFDACADABCIANN2XE to protect inverters, collector systems, and grid connections, ensuring safe and efficient energy transfer to the main network.
Commercial Buildings
Hospitals, data centers, and airports depend on it for critical power distribution, where uninterrupted supply is essential for safety and operations.
ABB REF615 HBFDACADABCIANN2XE
Product Guarantee: ABB REF615 HBFDACADABCIANN2XE
ABB stands behind the performance and durability of the ABB REF615 HBFDACADABCIANN2XE with comprehensive support:
- Warranty: 5-year warranty covering manufacturing defects and component failures under normal operating conditions.
- Technical Support: 24/7 global assistance via phone, email, or WhatsApp +86 18859254943 for installation guidance and troubleshooting.
- Training: Online and on-site courses to help engineers master configuration and maintenance, ensuring optimal relay performance.
- Replacement Services: Fast delivery of spare parts and replacement units through ABB’s global logistics network, minimizing downtime.
For pricing, technical datasheets, or to request a quote for the ABB REF615 HBFDACADABCIANN2XE, visit https://www.ygplc.com/ or contact our team via WhatsApp +86 18859254943. Trust ABB to protect your power network with innovation you can rely on.
