ABB SUE3000 1VCR007346 G0032 | Safety controller module | PSU100

Product Overview

Technical Specifications: ABB SUE3000 1VCR007346 G0032

Parameter Name	Parameter Value
Product Model	ABB SUE3000 1VCR007346 G0032
Manufacturer	ABB
Product Type	Safety Controller Module (TMR Architecture)
Safety Integrity Level	SIL 3 (IEC 61508/IEC 61511 compliant)
Processor Architecture	Triple Modular Redundant (TMR) with 3x 32-bit microprocessors
Physical Dimensions	220 mm (W) × 260 mm (H) × 150 mm (D)
Weight	3.2 kg
Power Supply	24 VDC ±20% (dual redundant inputs)
Communication Interfaces	2x Gigabit Ethernet (10/100/1000BaseT), RS-485 for serial expansion
I/O Capacity	Up to 1,024 points via SUE3000 I/O racks
Operating Temperature	-25°C to +60°C
Humidity	5% to 95% non-condensing
Certifications	CE, UL, CSA, IEC 61508, IEC 61511, ATEX (for hazardous areas)

ABB SUE3000 1VCR007346 G0032

Main Features and Advantages: ABB SUE3000 1VCR007346 G0032

Robust Environmental Performance: Designed to withstand harsh industrial conditions, the module features a rugged metal enclosure, conformal-coated PCBs, and resistance to vibration (5–50 Hz, 2 g) and electromagnetic interference (EMI). This ensures reliable operation in extreme temperatures and high-moisture environments without additional protective measures.

ABB SUE3000 1VCR007346 G0032

Application Areas: ABB SUE3000 1VCR007346 G0032

1. Oil and Gas:
   • Upstream and Downstream Operations: Manages ESD systems in offshore platforms, refineries, and pipeline networks, ensuring rapid response to leaks, overpressure, or fire incidents.
   • Compressor and Pump Control: Monitors machine health and activates safety interlocks to prevent mechanical failure or process upsets.
2. Chemical and Pharmaceutical Manufacturing:
   • Reactor Safety Systems: Executes emergency shutdown protocols in case of temperature/pressure deviations, preventing hazardous chemical reactions.
   • Batch Process Control: Ensures precise sequence execution and safety validation for high-value or volatile production lines.
3. Power Generation:
   • Turbine Safety Systems: Controls steam or gas turbine trips and bypass valves to protect equipment during abnormal operating conditions.
   • Substation Automation: Integrates with protective relays and circuit breakers to manage grid stability and prevent cascading failures.
4. Marine and Offshore:
   • Vessel Safety Systems: Manages fire and gas detection, ballast control, and engine shutdown systems in commercial ships and rigs.
   • Hazardous Area Applications: Complies with ATEX and IECEx standards for use in explosive atmospheres, ensuring safe operation in offshore environments.


     ABB SUE3000 1VCR007346 G0032

Related Products: ABB SUE3000 1VCR007346 G0032

• ABB SUE3000 1VCR007347 G0033: A dual-channel version of the ABB SUE3000 1VCR007346 G0032 designed for lower-risk applications, offering cost-effective SIL 2 compliance.
• ABB SUE3000 AI810 1VCR007201 G0001: An analog input module for connecting temperature, pressure, and flow sensors to the SUE3000 system, compatible with the ABB SUE3000 1VCR007346 G0032 for expanded I/O capacity.
• ABB SUE3000 DO810 1VCR007202 G0001: A digital output module for driving solenoid valves and contactors, often used in tandem with the ABB SUE3000 1VCR007346 G0032 for actuation control.
• ABB 800xA Safety Extension: A software suite that enhances the ABB SUE3000 1VCR007346 G0032 with advanced HMI visualization and alarm management, enabling seamless integration with ABB’s DCS platform.
• ABB SPC3000 1SAP230000R1001: A standalone safety PLC for smaller-scale applications, serving as a cost-effective alternative to the SUE3000 series for basic safety loops.

Installation and Maintenance: ABB SUE3000 1VCR007346 G0032

• Verify the power supply meets the module’s requirements (24 VDC ±20%) and that the control cabinet is properly grounded to mitigate EMI.
• Use ABB’s Safety Builder software to define safety logic, configure I/O mappings, and perform a thorough SIL verification of the application before deploying the module.
• Ensure the control rack provides adequate ventilation, as the module generates moderate heat during operation (thermal dissipation: 15 W).

• Regular Health Checks: Monitor the module’s status via the 800xA system or front-panel LED indicators (e.g., “Power,” “Sync,” “Fault”) to identify anomalies such as core mismatch or communication errors.
• Firmware Updates: Periodically update the module’s firmware using ABB’s dedicated toolchain to access security patches and compatibility improvements, ensuring alignment with evolving industry standards.
• Environmental Inspections: Clean dust and debris from the module’s vents quarterly, particularly in dusty environments, to maintain optimal thermal performance. Check for loose connections in terminal blocks during routine shutdowns.
• Functional Testing: Conduct annual proof testing of safety loops using simulated fault conditions to validate the module’s response time and logic accuracy, as required by IEC 61511.


  ABB SUE3000 1VCR007346 G0032

Product Warranty: ABB SUE3000 1VCR007346 G0032
