ABB PFSK152 3BSE018877R1 | Profinet IO Interface Module | PFSA240-A

Description

Product Overview：ABB PFSK152 3BSE018877R1

Technical Specifications：ABB PFSK152 3BSE018877R1

Parameter Name	Parameter Value
Product Model	ABB PFSK152 3BSE018877R1
Manufacturer	ABB
Product Type	Profinet IO Interface Module
Communication Protocol	Profinet IO (IEEE 802.3, TCP/IP, ISO-on-TCP)
Power Supply	24 VDC ±10% (power consumption: 12 W typical)
Physical Dimensions	127.5 mm (depth) x 186 mm (height) x 59 mm (width)
Weight	0.7 kg
Compatibility	AC 800M controller, System 800xA 6.1+
Redundancy Support	Dual Ethernet ports for network redundancy
Safety Integrity Level	SIL 2 (IEC 61508)
Operating Temperature	-25°C to +60°C (with derating above +50°C)
Humidity	5–95% non-condensing
Installation	DIN rail mounting with TP867 baseplate

ABB PFSK152 3BSE018877R1

Main Features and Advantages：ABB PFSK152 3BSE018877R1

Compact and Rugged Design: Despite its small footprint, the ABB PFSK152 3BSE018877R1 is built to withstand industrial harshness, including vibration (5–500 Hz, 2 g), shock (15 g), and extreme temperatures. This durability makes it suitable for deployments in challenging environments, such as offshore platforms, mining sites, or high-temperature processing facilities.

ABB PFSK152 3BSE018877R1

Application Areas：ABB PFSK152 3BSE018877R1

1. Oil and Gas Industry:
   • Deployed in upstream production (e.g., offshore rigs) to connect distributed sensors and valves to the central DCS, enabling real-time monitoring of wellhead pressures and flow rates.
   • Used in downstream refineries for integrating safety-critical devices into Profinet-based SIS, ensuring compliance with international safety standards.
2. Power Generation:
   • Connects steam turbine control systems to the plant’s supervisory control and data acquisition (SCADA) network, allowing precise adjustment of generator speeds based on grid demand.
   • Supports redundant communication in combined cycle power plants, where uninterrupted operation is essential for maintaining grid stability.
3. Manufacturing and Automotive:
   • Facilitates synchronization of conveyor belts, robotic arms, and quality control systems in smart factories, ensuring high throughput and minimal defect rates.
   • Enables predictive maintenance by transmitting real-time machine health data (e.g., vibration, temperature) to analytics platforms, reducing unplanned downtime.
4. Water and Wastewater Management:
   • Manages pump stations and treatment processes by integrating variable frequency drives (VFDs) and level sensors into a unified Profinet network, optimizing energy consumption and water quality.
   • Provides remote access for technicians to diagnose and reconfigure field devices without onsite visits, enhancing operational efficiency in decentralized water networks.

Related Products：ABB PFSK152 3BSE018877R1

• ABB CI871AK01 3BSE092693R1: A Profinet IO module with SIL 3 compliance, suitable for higher safety-critical applications, often used as an upgrade for systems requiring enhanced fault tolerance.
• ABB PFSK151 3BSE018876R1: A predecessor model supporting basic Profinet IO functionality, ideal for non-safety applications where cost optimization is a priority.
• ABB PM866AK01 3BSE042691R1: A high-performance CPU module for AC 800M systems, frequently paired with the ABB PFSK152 3BSE018877R1 in large-scale control systems to handle complex logic and data processing.
• ABB DI820 3BSE069053R1: A digital input module compatible with the S800 I/O family, used to expand the system’s capability to interface with discrete sensors and switches.
• ABB BAILEY INFI 90: A legacy DCS platform that can be integrated with the ABB PFSK152 3BSE018877R1 via gateways, enabling retrofits of older systems to modern Profinet networks.


  ABB PFSK152 3BSE018877R1

Installation and Maintenance：ABB PFSK152 3BSE018877R1

• Verify the power supply meets the module’s specifications (24 VDC ±10%) and is properly grounded to prevent electrical noise.
• Install the TP867 baseplate on a DIN rail, ensuring secure mechanical and electrical connection to the backplane.
• Use ABB’s System 800xA Engineering Tool to configure the module’s Profinet device name, IP address, and data exchange parameters before powering it up.

• Regularly inspect the module’s LED indicators to monitor status (e.g., power, communication, error signals). A steady green power LED and blinking communication LED indicate normal operation.
• Perform firmware updates quarterly using ABB’s dedicated software to access new features and security patches, especially in systems integrated with IT networks.
• In high-dust or humid environments, clean the module’s ventilation slots annually to prevent overheating. Use compressed air or a static-free cloth to avoid damage.
• For redundant systems, test the failover functionality periodically by simulating a network interruption to ensure the backup path activates within expected timeframes.


  ABB PFSK152 3BSE018877R1

Product Warranty：ABB PFSK152 3BSE018877R1
