ABB GFD563A101 3BHE046836R0101 Technical Specifications | Excitation Control Processor Parameters

$134,500.00

Brand model：ABB GFD563A101 3BHE046836R0101
Product Name:Technical Specifications
Warranty: 1 year
Origin:Switzerland
HS code：85389000.00
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month
Warranty: 365 days
Payment method: T/T
Payment terms: 50% advance payment for futures; Full payment in cash for the stock

Category: Modules Brand: ABB

Description

ABB GFD563A101 3BHE046836R0101 Technical Specifications | Excitation Control Processor Parameters

Product Parameter Table

Parameter	Specification
Model Designation	GFD563A101
Ordering Code	3BHE046836R0101
Product Type	Excitation Control Processor / High-Speed Controller Module
System Platform	ABB AC 800PEC / Unitrol 5000 Excitation System
Processor Architecture	Dual-core ARM Cortex-A9 (800 MHz), separate high-speed (100 µs) and low-speed (1 ms) control cores
Memory	1 GB DDR3 RAM, 8 GB eMMC Flash
Control Cycle	100 µs (high-speed core for current regulation), 1 ms (low-speed core)
Operating Voltage	24 VDC ±10% (redundant inputs), typical consumption 25 W
Communication Interfaces	2 × Ethernet (TCP/IP, Modbus TCP, IEC 61850-8-1); 1 × PROFIBUS DP-V1 (up to 12 Mbps); 1 × Fiber Optic I/O Link (100 Mbps); 1 × RS-232 service port
Isolation Rating	2500 VAC (communication ports to backplane); 5000 VAC (power to signal)
Operating Temperature	−20°C to +60°C
Storage Temperature	−40°C to +85°C
Relative Humidity	5% to 95%, non-condensing
Vibration Resistance	Up to 2 g (10–500 Hz, IEC 60068-2-6)
Protection Rating	IP20 (cabinet mounting)
Dimensions (W×H×D)	220 mm × 100 mm × 300 mm (rack mount)
Weight	Approx. 1.2 kg
