ABB CI871AK01 3BSE092693R1 Profinet IO Communication Interface Module
Product Overview：ABB CI871AK01 3BSE092693R1
The ABB CI871AK01 3BSE092693R1 Profinet IO communication interface module is a high-performance industrial component designed for seamless integration of field devices in ABB’s AC 800M distributed control system (DCS). As part of the AC 800M communication interface family, this module acts as a critical bridge between control processors, I/O devices, and Profinet IO networks, enabling real-time data exchange and control in mission-critical industrial environments.
Engineered for reliability, the CI871AK01 supports Profinet IO protocol with a transmission speed of 10/100 Mbps, ensuring compatibility with a wide range of automation architectures. Its dual redundant communication channels provide fault tolerance, minimizing downtime in applications where continuous operation is essential. The module’s 24V DC power input and compact design (59mm x 185mm x 127.5mm) make it suitable for space-constrained control cabinets, while its +5°C to +55°C operating temperature range ensures resilience in harsh industrial conditions.
In automation systems, the CI871AK01 plays a pivotal role in enabling interoperability between ABB’s AC 800M controllers and Profinet IO-compliant devices. By facilitating bidirectional data exchange, it enhances system scalability and flexibility, allowing operators to integrate advanced analytics, predictive maintenance tools, and cloud-based monitoring solutions. This module is widely used in industries such as power generation, oil & gas, and manufacturing, where precise control and real-time data management are critical to operational efficiency.
Technical Specifications：ABB CI871AK01 3BSE092693R1
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CI871AK01 3BSE092693R1 |
| Manufacturer | ABB |
| Product Type | Profinet IO Communication Interface Module |
| Input Voltage | 24V DC |
| Communication Protocol | Profinet IO (10/100 Mbps) |
| Interface Type | 1 x RJ45 Ethernet |
| Redundancy | Module redundancy supported |
| Physical Dimensions | 59mm x 185mm x 127.5mm |
| Weight | 0.7 kg |
| Operating Temperature | +5°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail with TP867 baseplate |
| Protection Rating | IP20 |
| CE Certification | Yes |
CI871AK01 3BSE092693R1
Key Features and Advantages：ABB CI871AK01 3BSE092693R1
Profinet IO Compatibility: The CI871AK01 is specifically designed for Profinet IO networks, providing seamless integration with ABB’s AC 800M controllers and third-party devices. Its support for 10/100 Mbps data transfer ensures high-speed communication, making it ideal for applications requiring real-time control and monitoring.
Redundant Communication: The module’s dual redundant channels enable failover capabilities, ensuring continuous data transmission even if one path fails. This feature is critical for industries such as power plants and offshore platforms, where downtime can lead to significant financial losses.
Compact and Rugged Design: With dimensions of 59mm x 185mm x 127.5mm and an IP20 protection rating, the CI871AK01 is suitable for installation in tight spaces while resisting dust and light splashes. Its lightweight construction (0.7 kg) also facilitates easy handling during maintenance.
Hot-Swap Functionality: The module supports hot-swappable operation, allowing replacement without disrupting system performance. This reduces downtime and simplifies maintenance procedures in critical applications.
Advanced Diagnostics: Built-in LED indicators and self-diagnostic functions enable real-time monitoring of module health, identifying issues such as communication errors or power fluctuations. This proactive approach minimizes troubleshooting time and enhances system reliability.
CI871AK01 3BSE092693R1
Application Areas：ABB CI871AK01 3BSE092693R1
The ABB CI871AK01 3BSE092693R1 Profinet IO communication interface module is ideally suited for industries requiring robust data integration and real-time control:
- Power Generation: Integrates with AC 800M systems to manage data flow between gas/steam turbines, generators, and grid infrastructure. Enables remote monitoring of turbine performance and predictive maintenance analytics.
- Oil & Gas: Facilitates communication between compressors, pumps, and control systems in refineries and offshore platforms. Supports real-time data exchange for process optimization and safety compliance.
- Industrial Manufacturing: Connects PLCs, robotics, and conveyor systems in smart factories, enabling centralized control and IoT-driven analytics. Ensures seamless integration with ERP and MES platforms.
- Water Treatment: Manages data transmission between pumps, valves, and SCADA systems in wastewater treatment plants, enhancing operational efficiency and regulatory compliance.
- Mining: Enables communication between crushers, conveyors, and ventilation systems in mining operations, improving safety and productivity through real-time monitoring.
Related Products：ABB CI871AK01 3BSE092693R1
- CI853: A ProfiBus DP communication module sets with the CI871AK01 to expand system connectivity for devices using ProfiBus protocol.
- CI860: A Foundation Fieldbus HSE interface module that complements the CI871AK01 in process control applications requiring integration with fieldbus devices.
- TP867: The baseplate for CI871AK01, providing mechanical support and electrical connections for the module.
- PM867: A high-performance controller module that works alongside the CI871AK01 to execute complex control algorithms in AC 800M systems.
- S800 I/O modules: A range of distributed I/O modules that interface with the CI871AK01 to expand system I/O capabilities for analog and digital signals.
- BC810 CEX bus interconnection unit: Enables segmentation of the CEX bus, improving system availability in redundant configurations with the CI871AK01.
CI871AK01 3BSE092693R1
Installation and Maintenance：ABB CI871AK01 3BSE092693R1
Installation Preparation:
Before installing the CI871AK01, ensure the 24V DC power supply meets the module’s requirements. Clean the DIN rail and secure the TP867 baseplate using the provided mounting clips. Align the CI871AK01 with the baseplate and slide it into place until it clicks. Connect the power cables to the terminal block, ensuring torque specifications (35A max per terminal) are met. Finally, link the module to the Profinet network via an Ethernet switch connected to the RJ45 port.
Before installing the CI871AK01, ensure the 24V DC power supply meets the module’s requirements. Clean the DIN rail and secure the TP867 baseplate using the provided mounting clips. Align the CI871AK01 with the baseplate and slide it into place until it clicks. Connect the power cables to the terminal block, ensuring torque specifications (35A max per terminal) are met. Finally, link the module to the Profinet network via an Ethernet switch connected to the RJ45 port.
Maintenance Recommendations:
- Routine Inspections: Quarterly check for loose connections, damaged cables, or signs of overheating. Clean the module’s surface to prevent dust accumulation.
- Firmware Updates: Periodically update the module’s firmware using ABB’s Automation Builder software to access new features and bug fixes.
- Connector Checks: Inspect the Ethernet connector for corrosion or damage during annual maintenance. Re-seat the connector if necessary to ensure reliable signal transmission.
- Redundancy Testing: Test the module’s redundant channels bi-annually to confirm failover functionality. Replace faulty components immediately to maintain system resilience.
CI871AK01 3BSE092693R1
Product Warranty：ABB CI871AK01 3BSE092693R1
We provide a 12-month quality warranty for the ABB CI871AK01 3BSE092693R1 Profinet IO communication interface module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your automation system with the CI871AK01 Profinet IO communication interface module.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
