Product Overview ：ABB AC900F PM904F 3BDH001002R0001
The ABB AC900F PM904F 3BDH001002R0001 is a high – end CPU module in the Freelance AC 900F controller family, designed for industrial process control applications2. It serves as the central processing unit, playing a crucial role in handling complex control tasks and ensuring the stable and reliable operation of the entire automation system.
This module features a powerful 800 – MHz CPU, which, combined with its 48 – MB controller memory (16 MB battery – buffered SRAM and 32 MB DRAM), allows it to efficiently manage a large number of control algorithms and data processing1. With four Ethernet interfaces, the ABB AC900F PM904F 3BDH001002R0001 supports protocols such as Modbus TCP and IEC 60870 – 5 – 104, facilitating seamless integration with other devices in the automation system1. It also offers excellent scalability, supporting up to 1500 I/O points, enabling flexible system expansion to meet different application requirements1. Additionally, its redundant design and built – in SD card for data backup and firmware upgrades enhance system reliability and maintainability.
Technical Specifications ：ABB AC900F PM904F 3BDH001002R0001
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PM904F |
| Order Number | 3BDH001002R0001 |
| Manufacturer | ABB |
| Product Type | CPU Module |
| Redundancy | Yes |
| Clock Frequency | 800 MHz |
| Processor Type | PowerQUICC II Pro |
| Switching Time | 500 ms |
| Operating Temperature | – 20 °C ~ + 70 °C |
| Storage Temperature | – 40 °C ~ + 85 °C |
| Dimensions | 285 mm x 152 mm x 95 mm |
| Controller Memory | 48 MB (16 MB SRAM, 32 MB DRAM) |
AC900F PM904F 3BDH001002R0001
Main Features and Advantages ：ABB AC900F PM904F 3BDH001002R0001
High Performance: The ABB AC900F PM904F 3BDH001002R0001 is equipped with a high – speed CPU and large – capacity memory, which can handle complex control tasks with ease, ensuring the high – speed and stable operation of the system. It is suitable for applications that require high – performance processing, such as power generation, oil and gas production, and chemical processing.
Rich Interfaces: With four Ethernet interfaces, this module supports multiple advanced Ethernet protocols, providing powerful connectivity. It can be easily integrated with various devices in the industrial automation network, such as sensors, actuators, and other controllers, to achieve seamless data exchange and system integration.
Scalability and Redundancy: The module supports a large number of I/O points, allowing the system to be flexibly expanded according to actual needs. Its redundant design ensures continuous operation even in the event of a component failure, improving the reliability and availability of the entire system. The built – in SD card also provides convenient data backup and firmware upgrade functions, reducing system maintenance costs and downtime.
Enhanced Security: The ABB AC900F PM904F 3BDH001002R0001 complies with G3 standards and offers optional LCD and controller locking functions to enhance system security1. This helps protect the control system from unauthorized access and malicious attacks, ensuring the safe operation of industrial processes.
AC900F PM904F 3BDH001002R0001
Application Areas ：ABB AC900F PM904F 3BDH001002R0001
The ABB AC900F PM904F 3BDH001002R0001 is widely used in various industrial automation fields.
Power Generation: In power plants, it is used to monitor and control the operation of generators, boilers, and turbines. It can precisely control the power generation process, optimize the operating parameters of the equipment, and ensure the stable output of electricity.
Oil and Gas Production: In the oil and gas industry, this module is applied to the control systems of oil wells, gas fields, and oil refineries. It can monitor and control the extraction, transportation, and refining processes, improving production efficiency and ensuring the safety of production operations.
Chemical Processing: In chemical plants, the ABB AC900F PM904F 3BDH001002R0001 is used to control chemical reaction processes, monitor the quality of products, and ensure the safe and stable operation of chemical production lines. It can handle complex control tasks such as temperature, pressure, and flow control, helping to improve product quality and reduce production costs.
Water Treatment: In water treatment plants, this module is used to control the water purification process, including the treatment of raw water, the disinfection of tap water, and the treatment of sewage. It can monitor and control the operation of various water treatment equipment to ensure the quality of treated water meets the required standards.
Pulp and Paper Production: In the pulp and paper industry, the ABB AC900F PM904F 3BDH001002R0001 is applied to the control systems of pulp production, paper making, and paper processing. It can control the process parameters such as pulp concentration, paper thickness, and drying temperature, improving the quality and production efficiency of paper products.
AC900F PM904F 3BDH001002R0001
Related Products ：ABB AC900F PM904F 3BDH001002R0001
- PM901F: It is a basic – level CPU module in the AC900F series, with lower performance and fewer interfaces than the PM904F, suitable for applications with relatively simple control requirements.
- PM902F: This is an intermediate – level CPU module, offering moderate performance and functionality. It has some differences in memory size and I/O point support compared to the PM904F, suitable for applications that do not require extremely high – performance processing.
- AI810F: An analog input module that works with the ABB AC900F PM904F 3BDH001002R0001 to collect analog signals from sensors and transmit them to the CPU module for processing.
- AO810F: An analog output module that receives control signals from the PM904F and converts them into analog voltages or currents to control the operation of actuators such as valves and motors.
- DI810F: A digital input module used to receive digital signals from switches, relays, and other devices and send them to the PM904F for processing.
- DO810F: A digital output module that receives digital control signals from the PM904F and controls the on – off states of digital devices such as relays and solenoid valves.
- AC800M: A controller in the ABB AC800 series, which has some similarities with the AC900F series in terms of functionality and application scenarios, but has different hardware architectures and performance characteristics. It can be considered as an alternative or complementary product to the ABB AC900F PM904F 3BDH001002R0001 in some cases.
Installation and Maintenance ：ABB AC900F PM904F 3BDH001002R0001
Installation pre – preparation: Before installing the ABB AC900F PM904F 3BDH001002R0001, make sure the installation environment meets the requirements, including appropriate temperature, humidity, and dust – free conditions. Check the power supply voltage and ensure it is within the specified range. Carefully read the installation manual and prepare the necessary tools and equipment. When installing, pay attention to the correct installation position and connection method to ensure reliable connection of all interfaces.
Maintenance suggestions: Regularly check the operating status of the ABB AC900F PM904F 3BDH001002R0001, including the indicator lights on the module and the temperature of the components. Clean the module regularly to remove dust and dirt. Backup the system data regularly to the SD card to prevent data loss in case of a failure. When firmware upgrades are available, update the firmware in a timely manner to improve the performance and functionality of the module. If a problem occurs, contact professional technical support in a timely manner for troubleshooting and repair.
AC900F PM904F 3BDH001002R0001
Product Guarantee ：ABB AC900F PM904F 3BDH001002R0001
Our company provides a one – year quality warranty service for the product. This warranty covers hardware failures caused by non – human factors. During the warranty period, if the product experiences abnormal performance or functional failure, we will provide a replacement service. In addition, for discontinued models or emergency needs, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, helping industrial systems to operate continuously and stably with reliable services.
