Product Overview
The ABB 500PSM03 1MRB 150038 R1 894-030375D 136-011100H is a high-performance power supply module designed to deliver stable and reliable DC power for industrial automation systems. As part of ABB’s S700 I/O series, this module is engineered to meet the demanding requirements of modern control cabinets, ensuring seamless operation of PLCs, DCS systems, HMIs, and other critical components.
With a 100W power output and 24V DC regulated output voltage, the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H provides consistent power to industrial equipment, minimizing downtime and optimizing system efficiency. Its 230V AC input voltage compatibility and 88% efficiency make it suitable for global applications, while the -20°C to +60°C operating temperature range ensures resilience in harsh environments. The module’s compact design (100mm x 50mm x 30mm) and DIN rail mounting capability facilitate easy integration into space-constrained control panels, reducing installation complexity.
In automation systems, the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H acts as a foundational component, ensuring stable power delivery to downstream devices such as ABB AC500 PLCs, drives, and sensors. Its overload protection and short-circuit safeguards enhance system reliability, while the IP20 protection rating shields against dust and solid particle ingress. By maintaining precise voltage regulation under varying load conditions, this module supports mission-critical processes in industries ranging from manufacturing to energy production.E-mail :sales@ygplc.com.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 500PSM03 1MRB 150038 R1 894-030375D 136-011100H |
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Input Voltage | 230V AC ±10% |
| Output Voltage | 24V DC (regulated) |
| Output Current | 4.2A |
| Power Output | 100W |
| Efficiency | 88% |
| Physical Dimensions | 100mm x 50mm x 30mm |
| Weight | 0.5 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
500PSM03 1MRB 150038 R1 894-030375D 136-011100H
Key Features and Advantages
High Reliability: The 500PSM03 1MRB 150038 R1 894-030375D 136-011100H incorporates robust circuitry and industrial-grade components to ensure long-term stability, even in high-vibration or temperature-fluctuating environments. Its overload protection and short-circuit detection mechanisms prevent damage to connected devices, reducing maintenance costs.E-mail :sales@ygplc.com.
Compact Design: Weighing just 0.5 kg and measuring 100mm x 50mm x 30mm, this module offers a space-efficient solution for control cabinets. Its DIN rail mounting allows for quick installation and easy replacement, streamlining system upgrades.
Wide Input Voltage Range: With support for 230V AC ±10%, the module adapts to varying power supply conditions, making it suitable for global applications. The 24V DC regulated output ensures consistent voltage delivery to sensitive equipment, such as PLCs and HMIs.
Energy Efficiency: The 88% efficiency minimizes power loss and heat generation, contributing to lower operational costs and improved sustainability. This efficiency rating aligns with ABB’s commitment to eco-friendly industrial solutions.
Extended Temperature Range: The module’s -20°C to +60°C operating temperature range enables reliable performance in extreme climates, from cold storage facilities to high-temperature manufacturing environments.
500PSM03 1MRB 150038 R1 894-030375D 136-011100H
Application Areas
The ABB 500PSM03 1MRB 150038 R1 894-030375D 136-011100H power supply module is ideally suited for diverse industrial sectors:E-mail :sales@ygplc.com.
- Manufacturing: Powers PLCs, robotics, and conveyor systems in automotive, food processing, and electronics production lines, ensuring seamless workflow automation.
- Energy Production: Supports power distribution in oil & gas platforms, wind turbines, and power plants, where stable power is critical for turbine control and monitoring systems.
- Water Treatment: Provides reliable power to pumps, valves, and analytical instruments in wastewater treatment plants, ensuring compliance with environmental standards.
- Transportation: Integrates with railway signaling systems and airport baggage handling equipment, delivering consistent power for safe and efficient operations.
- Process Control: Enables precise voltage regulation in chemical and pharmaceutical plants, supporting DCS systems and critical process monitoring.
Related Products
- 500PSM01: A lower-power variant (50W) for applications requiring basic power distribution, suitable for smaller control panels.
- 500PSM02: A 75W module with similar specifications, offering a balance between power output and compactness.
- ABB AC500 PLC: A complementary PLC system that integrates seamlessly with the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H to enable advanced automation and control.
- ABB ACS580 Drive: A variable-speed drive that pairs with the module to optimize motor performance in industrial machinery.
- ABB CP600 HMI: A human-machine interface that relies on the module’s stable power supply for real-time system monitoring and user interaction.
- 500PSM04: A higher-power version (150W) for applications with demanding power requirements, such as heavy machinery or large-scale process control systems.
- ABB S700 I/O Modules: A range of input/output modules that work alongside the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H to expand system functionality.
- ABB 3BSE032605R1 Redundancy Module: Enhances system reliability by providing redundant power supply capabilities for mission-critical applications.
500PSM03 1MRB 150038 R1 894-030375D 136-011100H
Installation and Maintenance
Installation Preparation:
Before installing the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H, verify the input voltage matches the 230V AC power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the module with the rail and secure it using the provided clips. Connect the AC input cables to the terminal block, ensuring torque specifications are met. Finally, link the DC output to downstream devices, following ABB’s wiring guidelines.
Before installing the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H, verify the input voltage matches the 230V AC power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the module with the rail and secure it using the provided clips. Connect the AC input cables to the terminal block, ensuring torque specifications are met. Finally, link the DC output to downstream devices, following ABB’s wiring guidelines.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections, signs of overheating, or dust accumulation. Clean the module’s surface quarterly to maintain optimal performance.
- Thermal Management: Ensure adequate ventilation around the module to prevent overheating, especially in high-temperature environments.
- Component Checks: Inspect the output voltage using a multimeter during annual maintenance to confirm stability. Replace any worn or damaged terminals immediately.
- Firmware Updates: While the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H does not require firmware updates, consult ABB’s technical documentation for hardware revisions or compatibility notices.Whatsapp:+86 18859254943.
Product Warranty
We provide a 12-month quality warranty for the ABB 500PSM03 1MRB 150038 R1 894-030375D 136-011100H power supply module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
500PSM03 1MRB 150038 R1 894-030375D 136-011100H
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your automation system with the 500PSM03 1MRB 150038 R1 894-030375D 136-011100H power supply module.
