Product Overview
The ABB 500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C power supply module is a high-reliability industrial-grade solution designed to deliver stable and efficient power to critical automation systems. As part of ABB’s 500 Series for modular control platforms, this module ensures consistent power distribution, making it an essential component for maintaining uninterrupted operation in complex industrial environments.
Engineered to meet the demanding requirements of modern automation, the 500PSM02 features a dual-input design (100–240V AC/24–36V DC) and provides a regulated 24V DC output with a maximum current capacity of 10A. Its advanced voltage regulation technology minimizes ripple and noise, protecting sensitive control modules and I/O devices from power fluctuations. The module’s compact form factor and DIN rail mounting capability facilitate easy integration into control cabinets, while its rugged construction ensures durability in harsh conditions.Whatsapp:+86 18859254943.
Within industrial automation systems, the 500PSM02 serves as a foundational power backbone, supporting components such as PLCs, DCS modules, and HMI panels. Its compatibility with ABB’s AC500 PLC series and 800xA DCS platform enables seamless integration into both legacy and modern setups. By combining high efficiency with robust protection features, the 500PSM02 enhances system reliability, reduces downtime, and optimizes energy consumption, making it a strategic choice for industries where continuous operation is non-negotiable.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C |
| Manufacturer | ABB |
| Product Type | Industrial Power Supply Module |
| Input Voltage Range | 100–240V AC (50/60Hz) or 24–36V DC |
| Output Voltage | 24V DC (±1% regulation) |
| Output Current | 0–10A (continuous), 12A (peak for 30 seconds) |
| Efficiency | Up to 92% at full load |
| Power Factor | ≥0.95 (230V AC input) |
| Physical Dimensions | 125mm (H) × 90mm (W) × 120mm (D) |
| Weight | 0.8kg |
| Operating Temperature | -20°C to +60°C (derating above +50°C) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Protection Features | Over-voltage, over-current, short-circuit protection |
| Mounting Type | DIN rail (EN 60715) or panel mounting |
500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C
Key Features and Advantages
Dual Input Flexibility: The 500PSM02 accepts both AC and DC inputs, eliminating the need for separate power supply units in mixed systems. This versatility makes it ideal for retrofitting legacy equipment or deploying in new installations with varying power requirements.
Precision Voltage Regulation: With ±1% output voltage stability, the module ensures sensitive control components receive clean, consistent power, reducing the risk of data corruption or hardware damage caused by voltage fluctuations.
High Power Density: Despite its compact size, the 500PSM02 delivers up to 10A continuous current, maximizing space efficiency in control cabinets. Its lightweight design (0.8kg) also simplifies handling and installation.
Rugged Industrial Design: Built with reinforced circuitry and a metal housing, the module withstands vibration, dust, and temperature extremes, making it suitable for harsh environments such as manufacturing plants, oil rigs, and mining sites.
Intelligent Protection: Integrated over-voltage, over-current, and short-circuit protection mechanisms safeguard both the module and connected devices, minimizing downtime and maintenance costs. The module’s automatic recovery feature ensures quick restart after fault conditions.Whatsapp:+86 18859254943.
Easy Integration: The DIN rail mounting and standardized terminal blocks enable fast installation, while the wide operating temperature range and compatibility with global voltage standards (100–240V AC) facilitate deployment in international projects.
500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C
Application Areas
The ABB 500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C power supply module excels in industries where reliable power is critical to operational continuity:
- Manufacturing Automation: Powers PLCs, motor drives, and robotic systems in assembly lines, ensuring precise control and reducing downtime caused by power interruptions. For example, in a automotive production facility, the 500PSM02 maintains stable power to robotic arms, enabling consistent quality in welding and painting processes.
- Process Control: Supports DCS and SCADA systems in chemical plants and refineries, ensuring uninterrupted monitoring and regulation of critical processes such as distillation, mixing, and pressure control.
- Power Generation: Provides reliable power to turbine control systems, switchgear, and monitoring devices in thermal, hydro, and wind power plants, contributing to stable energy production.
- Transportation Systems: Used in railway signaling, tunnel ventilation, and airport baggage handling systems, where consistent power is essential for safety and efficiency.
- Smart Infrastructure: Powers IoT sensors, control panels, and security systems in smart factories and intelligent buildings, enabling seamless connectivity and data transmission.
Related Products
- ABB 500PSM01: A lower-power variant (5A output) for smaller automation setups, ideal for applications with minimal power requirements.
- ABB 500PSM03: A higher-power model (15A output) designed for large-scale systems requiring increased current capacity.
- ABB 800xA Power Distribution Unit: A sets with component for ABB’s 800xA DCS platform, enabling centralized power management and monitoring.
- ABB AC500-ECO PLC Power Supply: Specifically engineered for ABB’s AC500-ECO PLC series, ensuring optimal compatibility and performance.
- ABB TB50 Terminal Block: A DIN rail-mounted terminal block for secure power cable connections with the 500PSM02.
- ABB PS500-RF Surge Protector: An optional accessory that enhances surge protection for the power supply module in lightning-prone environments.
- ABB 500PSM02-R: A redundant power supply kit including two 500PSM02 modules and a failover controller, ensuring zero downtime in critical applications.
- ABB 501PSM01: A legacy replacement model with similar specifications, suitable for retrofitting older automation systems.
Installation and Maintenance
Installation Preparation:
Before installing the 500PSM02, verify that the input voltage matches the module’s specifications (100–240V AC or 24–36V DC). Clean the DIN rail or mounting surface to remove debris, then secure the module using the included mounting clips. Connect the input power cables to the labeled terminals (L/N for AC, +/– for DC) and ensure proper grounding to minimize electromagnetic interference. Finally, connect the output cables to the load, ensuring the total current does not exceed 10A.
Before installing the 500PSM02, verify that the input voltage matches the module’s specifications (100–240V AC or 24–36V DC). Clean the DIN rail or mounting surface to remove debris, then secure the module using the included mounting clips. Connect the input power cables to the labeled terminals (L/N for AC, +/– for DC) and ensure proper grounding to minimize electromagnetic interference. Finally, connect the output cables to the load, ensuring the total current does not exceed 10A.
Maintenance Recommendations:
- Routine Inspections: Check for loose connections, abnormal noise, or overheating during regular system shutdowns. Use a multimeter to verify output voltage stability (24V DC ±1%).
- Environmental Cleaning: Dust and debris can affect heat dissipation, so clean the module’s vents and surface quarterly using a dry brush or compressed air.
- Fault Handling: If the module’s fault LED activates, disconnect the load and inspect for short circuits or overcurrent conditions. Replace faulty components before restarting the system.
- Lifespan Management: Although the 500PSM02 is designed for long-term use, consider replacing it every 5–7 years in high-duty cycles to maintain optimal performance. Keep spare modules in stock to minimize downtime during replacements.
500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C
Product Warranty
We provide a 12-month quality warranty for the ABB 500PSM02 1MRB150015R1 AD-272.100.20-01 AZ:C power supply module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to secure a stable power foundation for your automation system with the 500PSM02 power supply module.
