ABB 216MB66 HESG324510M1 Product Specification
Product Overview：ABB 216MB66 HESG324510M1
The ABB 216MB66 HESG324510M1 is a high-performance modular equipment rack designed for industrial protection and control systems, specifically engineered as part of ABB’s REC216 protection platform. This rack serves as the backbone for distributed control and monitoring systems, providing a robust infrastructure for integrating power supply units, input/output (I/O) modules, and processing units in mission-critical environments. The ABB 216MB66 HESG324510M1 is widely used in power generation, oil and gas, and heavy industries where system reliability and scalability are paramount.
Constructed with a rugged metal enclosure, the ABB 216MB66 HESG324510M1 supports up to 18 slots for modular components, including redundant power supplies (e.g., 216NG61, 216NG62) and I/O modules (e.g., 216EA61 for analog input processing). Its DIN rail mounting design ensures easy integration into standard 19-inch racks, while the compact dimensions (178 mm width × 102 mm height × 254 mm depth) optimize space utilization in control rooms or field cabinets. The rack’s dual-voltage DC power input (24 VDC ±10%) and built-in surge protection safeguard against electrical disturbances, ensuring stable operation in harsh industrial settings.
In automation systems, the ABB 216MB66 HESG324510M1 acts as the physical and electrical foundation for ABB’s REC216 protection system, enabling real-time data acquisition, signal conditioning, and control logic execution. It supports hot-swappable modules, allowing maintenance without system downtime, and features a redundant bus architecture for high availability. By accommodating a mix of protection, control, and communication modules, the ABB 216MB66 HESG324510M1 empowers industries to implement scalable solutions for turbine control, generator protection, and process automation, ensuring compliance with international standards like IEC 61850 and IEEE C37.118.
Technical Specifications：ABB 216MB66 HESG324510M1
| Parameter Name | Parameter Value |
|---|---|
| Product Model | ABB 216MB66 HESG324510M1 |
| Manufacturer | ABB |
| Product Type | Modular Equipment Rack for Protection Systems |
| Physical Dimensions | 178 mm (W) × 102 mm (H) × 254 mm (D) |
| Weight | 1.8 kg |
| Power Supply | 24 VDC ±10% (dual redundant inputs) |
| Slot Capacity | 18 slots (15 for modules, 3 for power supplies) |
| Bus Architecture | Redundant B448C parallel bus for high availability |
| Operating Temperature | -25°C to +60°C |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN rail (TS35) or panel-mountable |
| Environmental Protection | IP30 (dust and solid particle protection) |
| Certifications | CE, UL, CSA, IEC 61850 |
ABB 216MB66 HESG324510M1
Main Features and Advantages：ABB 216MB66 HESG324510M1
Modular Scalability: The ABB 216MB66 HESG324510M1 supports a flexible configuration of up to 15 I/O, protection, and communication modules, allowing tailored solutions for small-scale applications or large industrial complexes. This modularity reduces upfront costs by enabling phased system expansion.
Redundant Power Architecture: With dual 24 VDC inputs and support for redundant power supply modules (e.g., 216NG61), the rack ensures continuous operation even during power fluctuations. This feature is critical for systems where downtime could lead to production losses or safety risks.
Hot-Swap Capability: Field-replaceable modules allow maintenance personnel to replace faulty components without powering down the system, minimizing mean time to repair (MTTR). This is particularly valuable in remote locations or 24/7 operational environments.
Rugged Industrial Design: The rack’s metal enclosure and conformal-coated PCBs resist dust, moisture, and electromagnetic interference (EMI), ensuring reliable performance in harsh conditions such as power plant control rooms or offshore platforms. Its wide temperature range eliminates the need for additional environmental conditioning.
Seamless Integration: Compatible with ABB’s REC216 protection system and System 800xA platform, the ABB 216MB66 HESG324510M1 supports seamless integration with legacy and modern control systems. It also interfaces with third-party devices via industry-standard protocols like Modbus and Profibus, enhancing interoperability.
ABB 216MB66 HESG324510M1
Application Areas：ABB 216MB66 HESG324510M1
The ABB 216MB66 HESG324510M1 is designed for applications requiring high reliability and scalability:
-
Power Generation:
- Turbine Control: Integrates with steam or gas turbine protection systems to monitor vibration, temperature, and speed, ensuring safe and efficient operation.
- Generator Protection: Supports differential protection, overcurrent relays, and voltage regulation modules for power plant generators.
-
Oil and Gas:
- Subsea Control: Provides a rugged platform for subsea wellhead monitoring systems, withstanding extreme pressure and saltwater exposure.
- Pipeline Automation: Manages distributed control systems for pipeline pressure regulation and leak detection.
-
Industrial Manufacturing:
- Process Automation: Hosts PLC and DCS modules for real-time control of production lines in automotive or pharmaceutical industries.
- Machine Safety: Supports safety relay modules and emergency shutdown systems in heavy machinery applications.
-
Water and Wastewater:
- Pump Station Control: Monitors flow rates and motor status in water treatment plants, ensuring consistent supply and regulatory compliance.
ABB 216MB66 HESG324510M1
- Pump Station Control: Monitors flow rates and motor status in water treatment plants, ensuring consistent supply and regulatory compliance.
Related Products：ABB 216MB66 HESG324510M1
- ABB 216NG61 HESG324013R1: A redundant 24 VDC power supply module compatible with the ABB 216MB66 HESG324510M1, ensuring uninterrupted operation during power outages.
- ABB 216EA61 HESG324510M1: An analog input module with 16-bit resolution for precise measurement of temperature, pressure, and flow signals.
- ABB 216VC62A HESG324510M1: A high-performance processing unit for executing protection algorithms and communication protocols.
- ABB 216GD61A HESG324510M1: A digital input/output module for discrete control signals, ideal for valve actuation or alarm triggering.
- ABB 216GW62 HESG324510M1: A gateway module enabling communication between the REC216 system and external networks via Ethernet/IP or Profibus DP.
Installation and Maintenance：ABB 216MB66 HESG324510M1
Pre-installation Preparation:
Before installing the ABB 216MB66 HESG324510M1, ensure the following:
Before installing the ABB 216MB66 HESG324510M1, ensure the following:
- Verify the DC power supply meets the module’s requirements (24 VDC ±10%) and that the control rack is properly grounded to prevent EMI interference.
- Use ABB’s TurboGear software to configure module parameters and network settings before mounting.
- Ensure adequate clearance around the rack for heat dissipation, especially in high-density configurations.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs monthly to confirm normal operation (e.g., green “Power” and “Health” indicators). Replace faulty modules immediately.
- Environmental Checks: Clean dust from the rack’s vents quarterly, particularly in dusty environments, to prevent overheating. Monitor ambient temperature and humidity levels.
- Firmware Updates: Periodically update the rack’s firmware via ABB’s Proficy software to address security patches or enhance compatibility with newer control system versions.
- Redundancy Testing: Conduct annual tests of redundant power supplies and bus architecture to ensure failover functionality.
ABB 216MB66 HESG324510M1
Product Warranty：ABB 216MB66 HESG324510M1
Our company provides a one-year quality warranty for the ABB 216MB66 HESG324510M1, covering hardware failures due to non-human factors. During the warranty period, we will replace the product if it exhibits performance anomalies or functional failures. For discontinued models like the ABB 216MB66 HESG324510M1, our global supply chain network ensures rapid response to scarce spare parts requests, supporting the continuous and stable operation of industrial systems.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on publicly available technical data and industry applications. For detailed specifications, consult the official ABB REC216 user manual or contact our technical support team.
