ABB 5SHY4045L0006 / 3BHB030310R0001 / 3BHE039203R0101 / GVC736CE101 – High-Performance Industrial Automation Module

1. Product Overview

The ABB 5SHY4045L0006 module, along with its associated part numbers 3BHB030310R0001, 3BHE039203R0101, and GVC736CE101, is a precision-engineered component designed for high-reliability performance in industrial automation systems. Engineered to meet the rigorous demands of continuous operation in harsh environments, this module ensures seamless integration with ABB drive systems, distributed control systems (DCS), and other mission-critical applications. It combines robust construction with advanced thermal management, ensuring optimal performance under high electrical and mechanical stress.

With ABB’s proven expertise in power electronics, this product delivers exceptional stability, low failure rates, and minimal maintenance requirements, making it the preferred choice for industries such as power generation, petrochemical, metallurgy, and manufacturing.

2. Technical Specifications

Parameter	Description
Manufacturer	ABB
Main Model Number	5SHY4045L0006
Related Part Numbers	3BHB030310R0001, 3BHE039203R0101, GVC736CE101
Product Type	High-power thyristor/IGBT module
Application Category	Industrial drive systems, power electronics, and DCS integration
Rated Voltage	4500 V
Rated Current	3000 A
Switching Technology	Phase-control / gate turn-off compatible
Cooling Method	Liquid cooling / forced-air cooling
Operating Temperature Range	-40°C to +85°C
Insulation Voltage	10 kV AC
Package Type	Press-pack module with high mechanical strength
Weight	Approx. 3.5 kg
Compliance Standards	IEC 60747, CE certified
Typical Lifespan	> 100,000 operating hours
Maintenance Requirement	Low – periodic inspection recommended

5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101

3. Key Features & Benefits

• Exceptional Power Handling – Capable of operating at extremely high voltages and currents for heavy-duty applications.

• Enhanced Reliability – Rugged press-pack design provides superior resistance to vibration, thermal cycling, and electrical overstress.

• Long Service Life – Engineered for continuous 24/7 operation with minimal degradation over time.

• High Thermal Efficiency – Advanced cooling technology ensures stable operation even under peak loads.

• Seamless System Integration – Fully compatible with ABB industrial drives, converters, and control systems.

• Reduced Downtime – Low failure rate and easy maintenance contribute to improved plant availability.

4. Application Scenarios

• Power Generation Plants – Turbine control, excitation systems, and generator drives.

• Petrochemical Industry – High-power pump drives, compressor systems, and process automation.

• Metallurgical Operations – Rolling mill drives, arc furnaces, and smelting operations.

• Heavy Manufacturing – Conveyor drives, presses, and industrial mixers.

• Marine & Offshore – Propulsion drives and high-load auxiliary systems.



  5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101

5. Related Products

• ABB 5SNA2400E170300 – High-current IGBT module for inverter and drive systems, optimized for low conduction losses.

• ABB 5STP40H2801 – High-voltage thyristor module designed for phase-controlled rectifier applications in heavy industry.

• ABB 5SDF10F4511 – Fast-switching diode module for power conversion and high-frequency operation.

• ABB 3BHB013088R0001 – Drive control unit module compatible with ABB ACS drive series for precision control applications.

6. Installation & Maintenance Guidelines

1. Preparation – Ensure all mounting surfaces are clean and free from dust or conductive debris.

2. Mounting – Apply uniform torque to all fixing bolts to avoid mechanical stress.

3. Cooling System – Connect liquid or air cooling lines according to ABB installation diagrams.

4. Electrical Connections – Use appropriately rated cables and secure all terminations to prevent arcing.

5. Inspection Interval – Recommended visual inspection every 6 months; check for signs of overheating or mechanical wear.

6. Replacement – Always use genuine ABB replacement parts to ensure system compatibility and reliability.
