Product Overview
The FOXBORO FDC280 RH101FQ Field Device Controller is a high-performance industrial automation component designed for seamless integration of distributed control devices with EcoStruxure Foxboro DCS systems. As part of Schneider Electric’s FDC 280 series, this controller serves as a critical interface between PLCs, drives, and other field devices, enabling real-time data exchange and optimized control in mission-critical industrial environments.
Engineered for flexibility and reliability, the FDC280 RH101FQ supports Ethernet/IP, Modbus TCP, and serial communication protocols, ensuring compatibility with diverse industrial networks. Its dual-port Ethernet connectivity provides redundant communication paths, enhancing system resilience in harsh conditions. The controller’s 24V DC power input and IP65-rated enclosure allow for field mounting in challenging environments, including oil refineries, chemical plants, and power generation facilities. With a compact design (14.7 cm x 5.15 cm x 11.4 cm) and lightweight construction (0.6 kg), the FDC280 RH101FQ minimizes installation space while delivering robust performance.
Within automation systems, the FDC280 RH101FQ acts as a decentralized control hub, reducing reliance on centralized processing units. It executes complex control algorithms locally, enabling faster response times and reduced latency. The controller’s online image upgrade (OLUG) capability allows for firmware updates without process downtime, ensuring continuous operation. Its programmable logic controller (PLC) integration simplifies system configuration, making it ideal for retrofitting legacy systems or deploying new distributed control architectures.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | FDC280 RH101FQ |
| Manufacturer | FOXBORO (Schneider Electric) |
| Product Type | Field Device Controller |
| Input Voltage | 24V DC (redundant) |
| Power Consumption | ≤8.5W |
| Communication Protocols | Ethernet/IP, Modbus TCP, RS232/422/485 |
| Physical Dimensions | 14.7 cm x 5.15 cm x 11.4 cm |
| Weight | 0.6 kg |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5–95% non-condensing |
| Protection Rating | IP65 |
| Memory | 16 MB SDRAM, 32 MB Flash |
| Input/Output Channels | 8 digital inputs, 4 digital outputs |
| Redundancy Support | Optional dual-port configuration |
FDC280 RH101FQ
Key Features and Advantages
Multi-Protocol Connectivity: The FDC280 RH101FQ supports Ethernet/IP, Modbus TCP, and serial communication, allowing seamless integration with PLCs, drives, and third-party systems. This versatility reduces the need for additional gateways, simplifying system architecture and lowering costs.
Redundant Architecture: With dual-port Ethernet connectivity and optional redundant power supply inputs, the controller ensures continuous operation even in the event of network or power failures. This redundancy is critical for applications where downtime is costly, such as oil and gas production.
Localized Control: The controller executes IEC 61131-3-compliant ladder logic and function block diagrams, enabling real-time control decisions without relying on centralized DCS processors. This reduces latency and enhances system responsiveness.
Field-Mountable Design: The IP65-rated enclosure protects against dust, water, and corrosive chemicals, making the FDC280 RH101FQ suitable for deployment in harsh industrial environments. Its compact size facilitates installation in confined spaces, such as offshore platforms or manufacturing lines.
Remote Configuration: Using Schneider Electric’s Proficy Machine Edition software, operators can remotely configure the controller, monitor performance, and diagnose faults. This capability streamlines maintenance and reduces on-site labor requirements.
FDC280 RH101FQ
Application Areas
The FOXBORO FDC280 RH101FQ Field Device Controller is widely used in industries requiring distributed control and real-time data management:
- Oil & Gas: Deployed in offshore platforms and refineries to control pumps, compressors, and valves. The controller’s redundant communication ensures reliable operation in explosive atmospheres, while its localized control reduces dependency on central systems.
- Power Generation: Integrates with gas and steam turbines to monitor and adjust parameters like temperature and pressure, optimizing energy output and grid synchronization.
- Chemical Processing: Manages batch processes and continuous production lines by coordinating PLCs and drives, ensuring precise control of reaction sequences and material flow.
- Water Treatment: Controls pumps, filters, and disinfection systems in wastewater treatment plants, ensuring compliance with environmental standards through real-time data analysis.
- Metals & Mining: Supports conveyor belts, crushers, and ventilation systems by monitoring equipment health and adjusting operational parameters to enhance safety and productivity.
FDC280 RH101FQ
Related Products
- FOXBORO FCP280 Field Control Processor: A high-performance controller for complex process automation, offering advanced diagnostic features and compatibility with the FDC280 RH101FQ in distributed control systems.
- FOXBORO FBM230 Digital I/O Module: 配套使用 with the FDC280 RH101FQ to expand input/output capabilities, supporting up to 16 digital channels for monitoring switches and sensors.
- FOXBORO FBM242 Analog I/O Module: Enables connection to analog devices, such as pressure transmitters and flow meters, enhancing the controller’s data acquisition capabilities.
- FOXBORO FBM217 High-Speed Counter Module: Ideal for applications requiring precise speed or position control, such as conveyor belts or packaging machinery.
- FOXBORO FBM207 RTD Input Module: Supports resistance temperature detectors (RTDs) for temperature monitoring in critical processes, ensuring accurate environmental control.
- FOXBORO FBM218 TC Input Module: Connects thermocouples for high-temperature applications, commonly used in power generation and chemical processing.
- FOXBORO FBM219 AO Output Module: Provides analog output signals for controlling actuators and valves, complementing the FDC280 RH101FQ in closed-loop control systems.
Installation and Maintenance
Installation Preparation:
Before installing the FDC280 RH101FQ, verify the power supply matches the 24V DC input requirement. Clean the mounting surface and ensure proper grounding to minimize electromagnetic interference. The controller can be installed using a DIN rail or panel-mounting bracket, following FOXBORO’s mechanical guidelines. Connect Ethernet and serial cables to the respective ports, ensuring secure termination. Configure the controller’s IP address and communication protocols using Proficy Machine Edition, aligning settings with the existing DCS network.
Before installing the FDC280 RH101FQ, verify the power supply matches the 24V DC input requirement. Clean the mounting surface and ensure proper grounding to minimize electromagnetic interference. The controller can be installed using a DIN rail or panel-mounting bracket, following FOXBORO’s mechanical guidelines. Connect Ethernet and serial cables to the respective ports, ensuring secure termination. Configure the controller’s IP address and communication protocols using Proficy Machine Edition, aligning settings with the existing DCS network.
Maintenance Recommendations:
- Routine Inspections: Quarterly checks include verifying LED status indicators, inspecting connectors for corrosion, and cleaning the enclosure to prevent dust accumulation.
- Firmware Updates: Periodically update the controller’s firmware using Schneider Electric’s official software to access new features and security patches.
- Redundancy Testing: Semi-annually test the controller’s redundant power supply and network connections by disconnecting one path and verifying continuous operation.
- Sensor Calibration: Annually calibrate attached sensors (e.g., pressure transducers, temperature probes) to ensure accurate data acquisition.
FDC280 RH101FQ
Product Warranty
We provide a 12-month quality warranty for the FOXBORO FDC280 RH101FQ Field Device Controller, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning unit free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your distributed control system with the FDC280 RH101FQ Field Device Controller.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
