Product Overview：3BHE023784R2530 PPD113B01-25-111000
The ABB 3BHE023784R2530 PPD113B01-25-111000 process controller is a high-performance industrial automation component designed for mission-critical applications in power electronics and process control. As part of ABB’s AC 800PEC system, this controller integrates advanced control algorithms with modular architecture to deliver seamless integration of high-speed power electronics control and low-speed process automation tasks.
Engineered for precision and reliability, the 3BHE023784R2530 PPD113B01-25-111000 supports multi-protocol communication (e.g., Modbus TCP, PROFIBUS) and features dual redundant fiber-optic PowerLink interfaces for high-speed data transfer between controllers and I/O modules. Its 450mm x 100mm x 145mm compact design and IP20 protection rating make it suitable for both centralized control rooms and harsh industrial environments, while its -40°C to 70°C operating temperature range ensures resilience in extreme conditions.
In automation systems, the 3BHE023784R2530 PPD113B01-25-111000 acts as a central hub for real-time data processing and control, enabling applications such as DC power supply management in electrolytic processes, motor drive control, and industrial energy optimization. By combining high-speed control capabilities (e.g., 1ms processing cycles) with flexible I/O configurations, it empowers operators to achieve precise process control and predictive maintenance, reducing downtime and operational costs.
Technical Specifications：3BHE023784R2530 PPD113B01-25-111000
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3BHE023784R2530 PPD113B01-25-111000 |
| Manufacturer | ABB |
| Product Type | Process Controller |
| Input Voltage | 24V DC |
| Communication Protocols | Modbus TCP, PROFIBUS DP, Ethernet/IP |
| Interface Type | 2 x RS422, 1 x Modbus TCP, 36 x Fiber-optic |
| Redundancy | Dual redundant PowerLink channels |
| Physical Dimensions | 450mm x 100mm x 145mm |
| Weight | 2.59 kg |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Processing Cycle Time | 1 ms |
3BHE023784R2530 PPD113B01-25-111000
Key Features and Advantages：3BHE023784R2530 PPD113B01-25-111000
High-Speed Control Capability: The 3BHE023784R2530 PPD113B01-25-111000 delivers 1ms processing cycles, making it ideal for applications requiring real-time response, such as DC power supply control in electrolytic processes. Its dual redundant PowerLink interfaces ensure uninterrupted data transmission, critical for systems where downtime is costly.
Modular Architecture: The controller supports scalable I/O configurations via optional expansion modules (e.g., UFD128 digital I/O modules), allowing users to tailor the system to specific process requirements. This flexibility reduces upfront investment and simplifies future upgrades.
Multi-Protocol Compatibility: With native support for Modbus TCP, PROFIBUS DP, and Ethernet/IP, the controller seamlessly integrates with third-party devices, enabling interoperability in hybrid automation environments. This reduces the need for additional gateways, streamlining system design.
Rugged Design: Built with IP20-rated housing and a wide temperature range (-40°C to 70°C), the controller withstands harsh industrial conditions, including dust, vibrations, and extreme temperatures. Its 2.59 kg lightweight construction also facilitates easy installation and maintenance.
Advanced Diagnostics: The controller features real-time health monitoring via built-in LED indicators and self-diagnostic functions, enabling proactive maintenance and minimizing troubleshooting time. It also supports remote firmware updates, ensuring access to the latest features and bug fixes.
3BHE023784R2530 PPD113B01-25-111000
Application Areas：3BHE023784R2530 PPD113B01-25-111000
The ABB 3BHE023784R2530 PPD113B01-25-111000 process controller is widely used in industries requiring precise control and high reliability:
- Power Generation: Manages DC power supply systems in gas/steam turbine plants, ensuring stable energy output and grid synchronization. Supports predictive maintenance analytics to optimize equipment performance.
- Metallurgy: Enables IDC current step compensation and OLTC voltage regulation in copper/zinc smelters, minimizing process fluctuations and improving energy efficiency.
- Industrial Manufacturing: Controls motor drives and conveyor systems in smart factories, integrating with ERP/MES platforms for centralized production management.
- Energy Storage: Optimizes battery management systems in renewable energy projects, ensuring safe and efficient energy storage and discharge.
- Water Treatment: Manages pump and valve control in wastewater treatment plants, enhancing operational efficiency and regulatory compliance.
Related Products：3BHE023784R2530 PPD113B01-25-111000
- PCD235A101: A dual-channel analog input module sets with the 3BHE023784R2530 PPD113B01-25-111000 to expand system I/O capabilities for process monitoring.
- PCD530A102: A digital output module that interfaces with the controller to drive actuators and valves in industrial processes.
- 3BHE041343R0102: A fiber-optic communication module that enhances the controller’s network connectivity, supporting high-speed data transfer in distributed control systems.
- PM633: A Mark VIe I/O processor card that complements the controller for advanced analog and digital signal processing.
- PM802F: A high-performance controller that integrates with the 3BHE023784R2530 PPD113B01-25-111000 for complex control algorithms in power electronics applications.
- UFD128: A digital I/O module that provides additional input/output channels for system expansion.
- 3BHE028915R0101: A power supply module that ensures stable operation by providing redundant power to the controller and other AC 800PEC components.
3BHE023784R2530 PPD113B01-25-111000
Installation and Maintenance：3BHE023784R2530 PPD113B01-25-111000
Installation Preparation:
Before installing the 3BHE023784R2530 PPD113B01-25-111000, verify the 24V DC power supply and ensure proper grounding to minimize electromagnetic interference. Clean the DIN rail and align the controller with the mounting brackets, securing it using the provided clips. Connect the fiber-optic PowerLink cables to the designated ports, following ABB’s wiring guidelines to maintain signal integrity.
Before installing the 3BHE023784R2530 PPD113B01-25-111000, verify the 24V DC power supply and ensure proper grounding to minimize electromagnetic interference. Clean the DIN rail and align the controller with the mounting brackets, securing it using the provided clips. Connect the fiber-optic PowerLink cables to the designated ports, following ABB’s wiring guidelines to maintain signal integrity.
Maintenance Recommendations:
- Routine Inspections: Quarterly check for loose connections, damaged cables, or signs of overheating. Clean the controller’s surface to prevent dust accumulation.
- Firmware Updates: Periodically update the controller’s firmware using ABB’s Control Builder software to access new features and bug fixes.
- Redundancy Testing: Test the dual PowerLink channels bi-annually to confirm failover functionality. Replace faulty modules immediately to maintain system resilience.
- Fiber-Optic Care: Inspect fiber-optic connectors for corrosion or damage during annual maintenance. Re-seat connectors if necessary to ensure reliable data transmission.
3BHE023784R2530 PPD113B01-25-111000
Product Warranty：3BHE023784R2530 PPD113B01-25-111000
We provide a 12-month quality warranty for the ABB 3BHE023784R2530 PPD113B01-25-111000 process controller, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your automation system with the 3BHE023784R2530 PPD113B01-25-111000 process controller.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
