Product Overview
The GE IS200JPDMG1ACC S1AT005 power distribution board is a critical component within GE’s Mark VI Speedtronic turbine control system, designed to provide reliable power management and distribution for industrial automation applications. As part of the IS200 series, this board ensures stable power supply to various sub-systems, enabling seamless operation of gas and steam turbines in power generation, oil & gas, and heavy industrial environments.
Engineered for high-performance environments, the IS200JPDMG1ACC S1AT005 features a robust design with redundant power paths to minimize downtime. It supports 28V DC input voltage and includes 12 integrated fuses for overload protection, ensuring safe and efficient power distribution across the control system. The board’s compact form factor (6.5 x 7 inches) and DIN rail mounting compatibility facilitate easy integration into existing control cabinets, reducing installation complexity.
In automation systems, the IS200JPDMG1ACC S1AT005 acts as a central hub for power distribution, connecting control modules, I/O devices, and auxiliary systems. Its dual 50-pin connectors (P1/P2) and DC62 female connector (JA1) enable flexible connectivity with other Mark VI components, such as IS200ADIIH1A dual-channel I/O modules and IS200ACLAH1A application control layers. By ensuring consistent power delivery, this board enhances the overall reliability and precision of turbine control processes, making it an essential asset for mission-critical operations.Whatsapp:+86 18859254943.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200JPDMG1ACC S1AT005 |
| Manufacturer | GE |
| Product Type | Power Distribution Board |
| Input Voltage | 28V DC |
| Output Voltage | 24V DC (regulated) |
| Fuse Rating | 12 x 5A |
| Connector Type | 2 x 50-pin (P1/P2), 1 x DC62 (JA1) |
| Physical Dimensions | 6.5 x 7 inches |
| Mounting Type | DIN rail |
| Weight | 1.2 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5–95% non-condensing |
| Protection Rating | IP20 |
IS200JPDMG1ACC S1AT005
Key Features and Advantages
Redundant Power Architecture: The IS200JPDMG1ACC S1AT005 incorporates dual power input channels, ensuring continuous operation even if one path fails. This redundancy is critical for applications where downtime is costly, such as power plants and petrochemical facilities.
Overload Protection: With 12 integrated fuses, the board safeguards against short circuits and overcurrent conditions, preventing damage to connected components. This feature extends the lifespan of the control system and reduces maintenance costs.Whatsapp:+86 18859254943.
Flexible Connectivity: The board’s multiple connectors (P1/P2, JA1) support seamless integration with a wide range of Mark VI modules, including I/O cards, communication interfaces, and control processors. This versatility allows for scalable system configurations tailored to specific operational needs.
Compact Design: The IS200JPDMG1ACC S1AT005’s compact size and DIN rail mounting simplify installation in space-constrained environments. Its lightweight construction (1.2 kg) also facilitates easy handling during maintenance.
High Reliability: Built with industrial-grade components and a rugged PCB coating, the board withstands harsh environmental conditions, including vibration, dust, and temperature fluctuations. This durability ensures consistent performance in demanding industrial settings.
Application Areas
The GE IS200JPDMG1ACC S1AT005 power distribution board is ideally suited for industries requiring precise turbine control and reliable power management:
- Power Generation: Integrates with GE’s Mark VI system to manage power distribution in gas and steam turbine generators, ensuring stable energy output and grid synchronization.
- Oil & Gas: Supports power distribution for compressor stations, refineries, and offshore platforms, where uninterrupted operation is essential for production continuity.
- Industrial Manufacturing: Powers control systems in heavy machinery, such as rolling mills and conveyor belts, optimizing efficiency and reducing downtime.
- Water Treatment: Provides stable power to pumps, valves, and monitoring equipment in wastewater treatment plants, ensuring compliance with environmental standards.
-
IS200JPDMG1ACC S1AT005
Mining: Reliably distributes power to ventilation systems, crushers, and conveyor belts in mining operations, enhancing safety and productivity.
Related Products
- IS200ADIIH1A: A dual-channel I/O module 配套使用 with the IS200JPDMG1ACC S1AT005 for analog and digital signal processing in turbine control systems.Whatsapp:+86 18859254943.
- IS200ACLAH1A: An application control layer module that interfaces with the power distribution board to execute control algorithms and monitor system health.
- IS200AEPCH1A: An alternative energy pitch center module compatible with the Mark VI system, expanding its functionality for wind turbine applications.
- IS200ATBAG1A: A terminal board that connects the IS200JPDMG1ACC S1AT005 to field devices, ensuring secure signal transmission.
- IS200BICLH1A: An IGBT drive/source bridge interface board that works alongside the power distribution board to manage high-power loads.
- IS200BPIBG1A: A phase logic module that enhances the board’s control capabilities for complex industrial processes.
- IS200AVSCG1A: An SCR control board that complements the IS200JPDMG1ACC S1AT005 in high-voltage applications.
- IS200BPIHH1A: A bridge personality interface board that enables customization of the power distribution system for specific turbine configurations.
Installation and Maintenance
Installation Preparation:
Before installing the IS200JPDMG1ACC S1AT005, verify the input voltage (28V DC) matches the power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the board with the rail and secure it using the provided mounting clips. Connect the power cables to the terminal blocks, ensuring torque specifications (35A max per terminal) are met. Finally, link the board to adjacent modules via the P1/P2 and JA1 connectors, following GE’s wiring guidelines.Whatsapp:+86 18859254943.
Before installing the IS200JPDMG1ACC S1AT005, verify the input voltage (28V DC) matches the power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the board with the rail and secure it using the provided mounting clips. Connect the power cables to the terminal blocks, ensuring torque specifications (35A max per terminal) are met. Finally, link the board to adjacent modules via the P1/P2 and JA1 connectors, following GE’s wiring guidelines.Whatsapp:+86 18859254943.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections, blown fuses, or signs of overheating. Clean the board’s surface quarterly to prevent dust accumulation.
- Fuse Replacement: Replace blown fuses with GE-certified 5A fuses to maintain overload protection. Avoid using higher-rated fuses, as this may compromise safety.
- Connector Checks: Inspect connectors for corrosion or damage during annual maintenance. Re-seat connectors if necessary to ensure reliable signal transmission.
- Firmware Updates: While the IS200JPDMG1ACC S1AT005 does not require firmware updates, consult GE’s technical documentation for any hardware revisions or compatibility notices.
IS200JPDMG1ACC S1AT005
Product Warranty
We provide a 12-month quality warranty for the GE IS200JPDMG1ACC S1AT005 power distribution board, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning board free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your turbine control system with the IS200JPDMG1ACC S1AT005 power distribution board.E-mail :sales@ygplc.com.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
