IBA SM128V VMEBUS High-Performance Data Acquisition Module
Product Overview: IBA SM128V VMEBUS
The IBA SM128V VMEBUS high-performance data acquisition module is a robust industrial component designed for precise measurement and real-time control in complex automation systems. As part of IBA’s VMEBUS product family, this module serves as a critical link between field sensors and control systems, enabling seamless integration of analog and digital signals in mission-critical applications. Engineered for reliability and scalability, the SM128V VMEBUS is ideal for industries requiring high-speed data acquisition, such as manufacturing, energy production, and research laboratories.
The SM128V VMEBUS features 16 differential analog input channels with a 12-bit resolution, allowing it to capture detailed signals from transducers, sensors, and other field devices. Its VMEbus interface ensures compatibility with legacy and modern industrial computers, making it a versatile choice for retrofitting existing systems or building new automation architectures. The module supports software-configurable input ranges (-10V to +10V, 0-5V, etc.), enabling users to adapt to diverse measurement requirements without hardware modifications.
In automation systems, the SM128V VMEBUS plays a pivotal role in converting raw sensor data into actionable insights. By providing accurate and timely information to controllers and monitoring software, it enhances process efficiency, reduces downtime, and improves product quality. Its rugged design and wide operating temperature range (-40°C to +85°C) ensure reliable performance in harsh industrial environments, while its compact form factor (160mm x 100mm x 40mm) facilitates installation in space-constrained control cabinets.
Technical Specifications: IBA SM128V VMEBUS
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SM128V VMEBUS |
| Manufacturer | IBA |
| Product Type | Data Acquisition Module |
| Input Channels | 16 differential analog, 8 digital I/O |
| Resolution | 12-bit analog, 1-bit digital |
| Input Voltage Range | -10V to +10V, 0-5V (software-configurable) |
| Sampling Rate | Up to 100 kS/s (per channel) |
| Communication Interface | VMEbus (32-bit, 33 MHz) |
| Physical Dimensions | 160mm x 100mm x 40mm |
| Weight | 0.6 kg |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | VMEbus slot mounting |
| Country of Origin | Germany |
IBA SM128V
Key Features and Advantages: IBA SM128V VMEBUS
High-Precision Data Acquisition: The SM128V VMEBUS offers 16 differential analog channels with a 12-bit resolution, ensuring accurate capture of subtle signal variations in industrial processes. This precision is critical for applications such as vibration analysis, temperature profiling, and pressure monitoring, where small deviations can impact system performance.
Flexible Input Configuration: Users can configure input ranges and signal types (voltage, current) via software, eliminating the need for hardware reconfiguration. This adaptability makes the module suitable for diverse applications, from simple sensor monitoring to complex multi-channel control systems.
Rugged Industrial Design: Built to withstand harsh environments, the SM128V VMEBUS features a metal enclosure and extended temperature range, making it suitable for use in factories, power plants, and outdoor installations. Its VMEbus interface provides robust data transfer, minimizing signal interference and ensuring reliable operation.
Seamless System Integration: As a VMEbus-compatible device, the module works seamlessly with IBA’s range of industrial computers and third-party VME-based systems. This compatibility allows for easy integration into existing automation frameworks, reducing development time and costs.
Real-Time Data Processing: With a sampling rate of up to 100 kS/s per channel, the SM128V VMEBUS supports real-time data processing and feedback control, enabling immediate response to process changes. This feature is essential for applications requiring rapid adjustment, such as robotics and high-speed manufacturing.
IBA SM128V
Application Areas: IBA SM128V VMEBUS
The IBA SM128V VMEBUS data acquisition module is widely used in industries that demand precise data collection and control:
- Manufacturing Automation: Integrates with CNC machines, robotic arms, and conveyor systems to monitor performance metrics (e.g., motor speed, torque, position). By providing real-time data to PLCs and SCADA systems, it helps optimize production lines and reduce waste.
- Energy Production: Monitors sensors in gas turbines, steam generators, and wind turbines to track parameters like vibration, temperature, and pressure. This enables predictive maintenance, improving equipment reliability and reducing downtime in power plants and renewable energy facilities.
- Research and Development: Used in laboratories for experimental data acquisition, such as material testing, fluid dynamics analysis, and sensor calibration. Its high precision and flexible configuration make it a preferred choice for academic and industrial R&D projects.
- Process Control: Supports real-time monitoring of chemical reactors, distillation columns, and other process equipment in oil refineries and chemical plants. By ensuring accurate data transmission to DCS systems, it helps maintain process safety and efficiency.
- Transportation Systems: Installed in railway signaling systems and traffic control networks to collect data from sensors (e.g., strain gauges, accelerometers), enabling proactive maintenance and system optimization.
Related Products: IBA SM128V VMEBUS
- IBA SM160V VMEBUS: A higher-resolution variant with 16-bit analog input, suitable for applications requiring ultra-precise measurements, such as metrology and aerospace testing.
- IBA DM32V VMEBUS: A digital-only module with 32 channels of digital I/O, complementing the SM128V VMEBUS in systems that require both analog and digital signal processing.
- IBA CP600 VMEBUS Controller: A VMEbus-based industrial computer that works alongside the SM128V VMEBUS to process and analyze data in real time, forming a complete automation solution.
- IBA AD400 VMEBUS Amplifier: An analog signal conditioner that enhances the module’s input capabilities, supporting low-level signals from transducers and improving overall measurement accuracy.
- IBA TM200 VMEBUS Thermocouple Module: Specialized in temperature measurement using thermocouples, ideal for applications where the SM128V VMEBUS needs to be paired with thermal sensors.
- IBA PS800 VMEBUS Power Supply: A redundant power module that ensures stable operation of the SM128V VMEBUS and other VMEbus components, critical for systems requiring continuous uptime.
IBA SM128V
Installation and Maintenance: IBA SM128V VMEBUS
Installation Preparation:
Before installing the SM128V VMEBUS, ensure the VMEbus backplane is powered off and grounded to prevent electrostatic discharge. Align the module with the VMEbus slot and gently push it into place until the connectors are fully engaged. Secure the module with the provided retention brackets to prevent during operation. Connect field sensors to the module’s terminal block, following the wiring diagram in the user manual to ensure correct polarity and signal routing. Finally, power on the system and verify module recognition via the host computer’s diagnostics software.
Before installing the SM128V VMEBUS, ensure the VMEbus backplane is powered off and grounded to prevent electrostatic discharge. Align the module with the VMEbus slot and gently push it into place until the connectors are fully engaged. Secure the module with the provided retention brackets to prevent during operation. Connect field sensors to the module’s terminal block, following the wiring diagram in the user manual to ensure correct polarity and signal routing. Finally, power on the system and verify module recognition via the host computer’s diagnostics software.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections or physical damage to the module and its wiring. Clean the enclosure with a dry cloth to remove dust and debris that could affect heat dissipation.
- Calibration Checks: Perform annual calibration using IBA’s dedicated software and certified reference equipment to maintain measurement accuracy. This is especially important for applications requiring traceable data.
- Firmware Updates: Periodically download and install firmware updates from IBA’s official website to access new features, bug fixes, and compatibility improvements.
- Environmental Monitoring: Monitor the operating temperature and humidity of the control cabinet to ensure they remain within the module’s specified range (-40°C to +85°C, 5–95% non-condensing).
IBA SM128V
Product Warranty: IBA SM128V VMEBUS
We provide a 12-month quality warranty for the IBA SM128V VMEBUS data acquisition module, covering hardware defects caused by non-human factors. During the warranty period, if the module exhibits abnormal performance or functional failure, we will promptly provide a replacement at no additional cost. For discontinued models or urgent requirements, our global supply chain network is equipped to source even the rarest industrial control parts, ensuring minimal downtime for your operations.
With 17 years of experience in industrial control distribution, we pride ourselves on delivering reliable products, competitive pricing, and expert technical support. Whether you need a single module or a custom solution, our team is committed to helping you maintain the efficiency and reliability of your automation systems. Contact us today to learn more about the SM128V VMEBUS and how it can elevate your industrial data acquisition capabilities.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and safety guidelines.
