GE IS215UCVEM01A / IS215UCVEH2AF / VMIVME+7614-133 350-017614-133 E Product Specification
Product Overview
The GE IS215UCVEM01A, IS215UCVEH2AF, and VMIVME+7614-133 (350-017614-133 E) are high-performance Single Slot VME CPU Controller Cards designed as the computational core of GE’s Mark VI Speedtronic Turbine Control System. Engineered for mission-critical industrial automation, these modules execute complex control algorithms, manage safety protocols, and integrate with field devices to ensure precise operation of gas and steam turbines in power generation, oil and gas, and heavy manufacturing. As part of GE’s Mark VI series, they combine rugged hardware with advanced processing capabilities to thrive in harsh environments, from offshore platforms to thermal power plants.
The GE IS215UCVEM01A/IS215UCVEH2AF features a 300 MHz Intel Celeron processor paired with 32 MB DRAM and 16 MB compact flash memory, enabling real-time control of turbine speed, load balancing, and emergency shutdown sequences. The VMIVME+7614-133 variant, compatible with VMIC’s VME architecture, enhances connectivity with dual Ethernet ports (10/100BaseTX), an IS Bus, and serial interfaces. Their front panels include status LEDs (OK, Active, Ethernet) for system health monitoring, while metal enclosures and conformal-coated PCBs protect against dust, moisture, and EMI. Operating from -30°C to +65°C, these modules ensure reliable performance in extreme conditions.
In automation systems, these controllers act as the central hub, processing signals from proximity probes, pressure transmitters, and fuel valves. Their built-in diagnostics monitor voltage, thermal stress, and communication integrity, enabling proactive maintenance. Integration with GE’s Proficy software supports remote configuration and real-time data visualization, optimizing uptime in mission-critical applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Models | GE IS215UCVEM01A, IS215UCVEH2AF, VMIVME+7614-133 (350-017614-133 E) |
| Manufacturer | General Electric (GE) |
| Product Type | Single Slot VME CPU Controller Card |
| Processor | 300 MHz Intel Celeron |
| Memory | 32 MB DRAM, 16 MB Compact Flash |
| Communication Interfaces | 2 × 10/100BaseTX Ethernet, IS Bus, RS-232/485 |
| Supported Protocols | Ethernet Global Data (EGD), Modbus RTU, TCP/IP, UDP |
| Power Supply | +5 VDC (6 A typical, 8 A max), +12 VDC (auxiliary) |
| Physical Dimensions | 8.26 cm (H) × 4.19 cm (W) × 20.32 cm (D) |
| Weight | 0.9 kg (2 lbs) |
| Operating Temperature | -30°C to +65°C |
| Humidity | 5–95% non-condensing |
| Mounting | VME 64x rack (3U form factor) |
| Certifications | CE, UL, ISO 10105 |
Main Features and Advantages
Real-Time Control Processing: The 300 MHz processor ensures deterministic execution of control algorithms, maintaining turbine speed stability within ±0.1% and enabling millisecond-level response to load changes. The QNX real-time OS supports concurrent processing of safety-critical tasks in power grid applications.
Enhanced Connectivity: The IS215UCVEM01A adds Profibus DP support for legacy devices, while VMIVME+7614-133 offers dual Ethernet ports for redundant network setups. This flexibility allows integration with GE’s Mark VI I/O modules (e.g., IS200TBCBH1AAA) and modern SCADA systems.
Rugged Industrial Design: Metal enclosures and conformal coating protect against vibration (50 G peak), shock, and EMI, making these modules suitable for offshore and heavy manufacturing. Hot-swappable design enables maintenance without system shutdowns, reducing MTTR.
Advanced Diagnostics: Front-panel LEDs and built-in self-tests monitor voltage, temperature, and communication health. The modules log fault data for post-event analysis, supporting predictive maintenance to prevent unplanned downtime.
Scalable Redundancy: Support for simplex, duplex, or triple modular redundancy (TMR) enhances reliability in safety-critical applications like emergency shutdown systems. Non-volatile flash memory retains settings during power outages.
Application Areas
-
Power Generation:
- Controls steam turbine governors to maintain grid frequency (50/60 Hz) and voltage stability in thermal plants.
- Manages gas turbine fuel systems in combined cycle plants, optimizing energy efficiency and emissions control.
- Integrates with generator excitation systems for seamless synchronization during start-up.
-
Oil and Gas:
- Regulates compressor motors in refineries and pipeline pumping stations, preventing overpressure and thermal overload.
- Drives emergency shutdown sequences in offshore platforms to ensure safety during leaks or fires.
-
Industrial Manufacturing:
- Controls high-speed conveyor systems and robotic arms in automotive plants for precise motion control.
- Manages steam turbine-driven pumps in chemical facilities to maintain process temperatures.
-
Water/Wastewater:
- Optimizes pump motor speeds in water treatment plants for efficient filtration.
- Monitors aeration systems in wastewater facilities to maintain biological process effectiveness.
Related Products
- GE IS215UCVEH2AE: Predecessor model with single Ethernet port, suitable for simpler setups.
- GE IS210MACCH2AEG: Motor control module for integrated turbine drive systems.
- GE IS210PPROH1B: Redundant power supply ensuring stable 24 VDC.
- GE IS200MCCA: Communication adapter for expanded network connectivity.
- VMIC VMIVME-7610: Compatible VME backplane for system expansion.
- GE IS215ACLEH1BB: Application control layer module for higher-level logic.
Installation and Maintenance
Pre-installation Preparation:
Before installing GE IS215UCVEM01A/IS215UCVEH2AF/VMIVME+7614-133:
Before installing GE IS215UCVEM01A/IS215UCVEH2AF/VMIVME+7614-133:
- Ensure the VME rack is ESD-grounded; use an anti-static wrist strap during handling.
- Verify ambient temperature (-30°C to +65°C) and humidity (≤95% non-condensing).
- Use GE’s Proficy Machine Edition to load control applications, set IP addresses, and configure EGD multicast groups.
- Secure the module in the VME rack with anti-vibration brackets, leaving 50 mm clearance for airflow.
Maintenance Recommendations:
- Monthly Checks: Inspect front-panel LEDs (green=normal, red=fault) and clean dust from ventilation slots with compressed air.
- Annual Calibration: Use a signal generator to verify analog I/O accuracy (±0.5% of full scale).
- Firmware Updates: Periodically update via Proficy to access bug fixes and security patches.
- Thermal Management: Replace CPU thermal compound every 2 years to maintain heat dissipation.
Product Warranty
Our company provides a one-year quality warranty for the GE IS215UCVEM01A, IS215UCVEH2AF, and VMIVME+7614-133, covering hardware defects not caused by misuse. During the warranty period, we offer free replacement for modules with abnormal performance. For discontinued models, our global inventory ensures quick delivery of scarce spare parts within 24–48 hours. Post-warranty, our certified technicians provide repair services and technical support to keep your systems operational.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document combines GE’s official specifications with industry applications. For detailed guides, refer to the Mark VI Speedtronic System Manual or contact our technical team.
