GE IS210MACCH1AKH Communication Control Module
Product Overview: GE IS210MACCH1AKH
The GE IS210MACCH1AKH communication control module is a high-reliability industrial component designed for GE’s Mark VIe Turbine Control System, a flagship platform for steam and gas turbine automation. As a critical interface within this system, the IS210MACCH1AKH enables seamless data exchange between turbine control processors, I/O modules, and supervisory networks, ensuring real-time monitoring and control of power generation processes. Engineered for mission-critical applications, this module integrates advanced communication protocols and rugged hardware to support continuous operation in demanding industrial environments.
Featuring dual redundant Ethernet ports (10/100 Mbps) and support for protocols like Modbus TCP/IP and Profibus DP, the IS210MACCH1AKH facilitates high-speed data transmission between the turbine control system and external devices. Its hot-swappable design allows maintenance without system shutdown, while the -40°C to +70°C operating range and IP20 protection rating ensure reliability in harsh conditions, from power plant control rooms to offshore platforms. The module’s 32-bit microprocessor and 256 MB RAM enable rapid processing of complex control algorithms, making it an essential component for optimizing turbine performance and safety.
Within automation architectures, the IS210MACCH1AKH acts as a communication hub, translating control signals and monitoring data to support predictive maintenance and process optimization. Its compatibility with GE’s Mark VIe I/O modules (e.g., IS210MCCPH1A) and compliance with IEEE standards solidifies its role in critical power generation systems, where uninterrupted operation is non-negotiable.
Technical Specifications: GE IS210MACCH1AKH
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS210MACCH1AKH |
| Manufacturer | GE |
| Product Type | Communication Control Module |
| Communication Interfaces | 2 x Ethernet (10/100 Mbps), 1 x RS485 |
| Supported Protocols | Modbus TCP/IP, Profibus DP, IEEE 1588 |
| Power Supply | 24V DC (±10%) |
| Physical Dimensions | 150 mm (H) × 100 mm (W) × 50 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (Mark VIe system) |
| Compliance | IEEE 1131-2, IEC 61131-3 |
| Country of Origin | United States |
Main Features and Advantages: GE IS210MACCH1AKH
Redundant Communication Paths: The IS210MACCH1AKH features dual Ethernet ports for network redundancy, ensuring continuous data transmission even if one connection fails. This reliability is critical for preventing unplanned downtime in power generation systems.
High-Speed Data Processing: With a 32-bit microprocessor and robust memory, the module handles real-time data exchange for complex turbine control systems, supporting up to 1,000 I/O points for comprehensive monitoring.
Hot-Swappable Design: The module can be replaced without powering down the system, minimizing maintenance downtime and enhancing operational continuity in 24/7 environments.
Wide Environmental Tolerance: Built to withstand extreme temperatures and harsh conditions, the IS210MACCH1AKH performs reliably in industrial settings, from arctic power plants to tropical offshore platforms.
Protocol Flexibility: Support for multiple industrial protocols allows seamless integration with diverse automation systems, reducing the need for additional gateways and simplifying system architecture.
Application Areas: GE IS210MACCH1AKH
The GE IS210MACCH1AKH communication control module is essential for industries relying on precise turbine control and monitoring:
- Power Generation: Deployed in thermal, combined-cycle, and renewable energy plants to control steam and gas turbines, ensuring optimal power output and grid stability. The module’s real-time data transmission supports load balancing and safety interlocks.
- Oil and Gas: Used in offshore platforms and refineries to manage turbine-driven compressors and pumps, enabling remote monitoring of critical processes in harsh, corrosive environments.
- Industrial Manufacturing: Integrates with turbine-driven machinery in paper mills, chemical plants, and cement facilities, optimizing energy use and process efficiency.
- District Heating: Controls steam turbines in district heating systems, ensuring reliable heat distribution for commercial and residential applications.
Related Products: GE IS210MACCH1AKH
- GE IS210MCCPH1A I/O Module: Works alongside the IS210MACCH1AKH to process analog and digital signals for turbine control.
- GE IS200TCCPH1A Turbine Control Processor: A compatible CPU module that communicates with the IS210MACCH1AKH for comprehensive turbine management.
- GE IS210PARPH1A Power Supply Module: Provides redundant power to the IS210MACCH1AKH and other Mark VIe components.
- GE IS210MATBH1AA Communication Module: A variant with enhanced bandwidth for high-data-rate applications, suitable for complex turbine networks.
- GE IS210MADCH1AA Network Interface Module: Complements the IS210MACCH1AKH by supporting additional communication protocols for legacy systems.
Installation and Maintenance: GE IS210MACCH1AKH
Pre-installation Preparations:
Before installing the IS210MACCH1AKH, verify the control rack is properly grounded and the power supply (24V DC) matches specifications. Clean the rack slot and secure the module using the provided brackets, ensuring proper alignment with backplane connectors. Connect Ethernet cables to the dual ports and terminate power wires at the terminal block, following GE’s wiring diagrams to avoid polarity errors. Configure network settings (IP address, subnet mask) via the module’s front-panel interface or remote software.
Before installing the IS210MACCH1AKH, verify the control rack is properly grounded and the power supply (24V DC) matches specifications. Clean the rack slot and secure the module using the provided brackets, ensuring proper alignment with backplane connectors. Connect Ethernet cables to the dual ports and terminate power wires at the terminal block, following GE’s wiring diagrams to avoid polarity errors. Configure network settings (IP address, subnet mask) via the module’s front-panel interface or remote software.
Maintenance Recommendations:
- Routine Inspections: Monthly checks for loose connections, overheating, or abnormal LED indicators. Clean the module’s vents with compressed air to prevent dust accumulation.
- Firmware Updates: Annually update firmware using GE’s official software to access new features and security patches, ensuring compatibility with evolving system requirements.
- Redundancy Testing: Quarterly simulate network failures to verify dual-port failover functionality, maintaining system reliability.
- Spare Parts Management: Keep a spare IS210MACCH1AKH on hand, leveraging our global supply chain for rapid replacement of discontinued or urgent components.
Product Guarantee: GE IS210MACCH1AKH
Our company provides a 12-month quality warranty for the GE IS210MACCH1AKH communication control module, covering non-human-induced hardware defects. During the warranty period, we will replace any module with communication failures, power supply issues, or physical damage at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to delivering reliable products and exceptional service. The IS210MACCH1AKH exemplifies our dedication to quality, offering robust communication capabilities for critical turbine control systems. Contact us today to optimize your automation infrastructure with this advanced module.
