GE IS210BPPCH1AEC Mark VIe Power Supply Module
Product Overview
The GE IS210BPPCH1AEC is a high-reliability Power Supply Module designed as a critical component of GE’s Mark VIe distributed control system (DCS), catering to industrial automation and turbine control applications. Engineered to deliver stable 24 V DC power to Mark VIe racks and associated modules, this supply ensures continuous operation of critical systems in power generation, oil & gas, and manufacturing sectors. As part of the IS210 Series, the IS210BPPCH1AEC integrates seamlessly with other Mark VIe components, such as control modules and I/O cards, providing redundant power to prevent downtime in mission-critical operations.
Featuring a rugged industrial design, the GE IS210BPPCH1AEC supports hot-swappable installation, allowing replacement without powering down the system—a critical feature for 24/7 industrial environments. Its advanced power conditioning circuitry includes overvoltage, overcurrent, and thermal protection, safeguarding connected modules from electrical anomalies. The module’s wide input voltage range (85–264 V AC) adapts to diverse global power grids, while its high-efficiency design (up to 90%) minimizes energy loss and heat generation. With a wide operating temperature range (-40°C to +85°C) and compliance with industry standards like IEC 61131-2, the IS210BPPCH1AEC ensures reliable performance in harsh industrial settings, from offshore platforms to thermal power plants.
In automation ecosystems, the IS210BPPCH1AEC serves as the power backbone for Mark VIe systems, enabling stable operation of turbine control, process monitoring, and safety interlock functions. Its redundant configuration capability (when paired with another IS210BPPCH1AEC) eliminates single points of failure, enhancing system availability. By combining robust power delivery with intelligent diagnostic features, this module supports the continuous and efficient operation of industrial assets, making it indispensable for industries reliant on reliable control system power.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS210BPPCH1AEC |
| Manufacturer | GE |
| Product Type | Power Supply Module |
| Platform | Mark VIe |
| Input Voltage | 85–264 V AC, 50/60 Hz |
| Output Voltage | 24 V DC ±0.5% |
| Output Current | 10 A maximum |
| Efficiency | Up to 90% |
| Redundancy Support | Yes (parallel operation with identical modules) |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 2.1 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in Mark VIe enclosure |
| Certifications | CE, UL, cUL |
Key Features and Advantages
Hot-Swap Redundancy: The IS210BPPCH1AEC supports hot-swappable installation and parallel redundancy, allowing seamless replacement or expansion without system shutdown. This feature is critical for maintaining uptime in continuous operations, such as power plant turbine control.
Wide Input Voltage Range: With support for 85–264 V AC input, the module adapts to fluctuating power grids, reducing the need for region-specific adapters and enhancing installation flexibility in global industrial settings.
Comprehensive Protection Mechanisms: Built-in overvoltage, overcurrent, and thermal protection circuits safeguard connected modules from electrical faults, extending the lifespan of both the power supply and downstream components.
High-Efficiency Power Conversion: The module’s 90% efficiency minimizes energy loss and heat generation, reducing cooling requirements and operational costs in industrial control rooms.
Rugged Environmental Tolerance: Engineered to withstand extreme temperatures (-40°C to +85°C) and harsh conditions, the IS210BPPCH1AEC meets rigorous industrial standards, ensuring reliability in offshore, refinery, and manufacturing environments.
Intuitive Diagnostic Feedback: LED indicators provide real-time status feedback on power output, fault conditions, and thermal status, simplifying troubleshooting and maintenance.
Application Areas
The GE IS210BPPCH1AEC is essential for powering critical control systems in industries where reliability is non-negotiable:
- Power Generation: Powers turbine control systems in thermal, hydro, and combined cycle power plants, ensuring stable grid synchronization and efficient energy production.
- Oil & Gas: Supports control modules in refineries, pipeline compression stations, and offshore platforms, enabling safe and efficient operation of pumps, compressors, and safety interlocks.
- Manufacturing: Powers PLC and DCS systems in automotive, chemical, and food processing plants, maintaining production continuity and quality control.
- Water/Wastewater Treatment: Operates control systems for pumps, valves, and filtration equipment, adapting to fluctuating demand while ensuring regulatory compliance.
Specific applications include:
- Turbine Control Systems: Powers Mark VIe modules that manage steam turbine speed, load, and emergency shutdowns in power plants.
- Process Automation: Supplies stable power to I/O modules and controllers in chemical processing plants, enabling precise regulation of temperature, pressure, and flow.
- Safety Instrumented Systems (SIS): Supports redundant power for critical safety loops in oil & gas facilities, meeting SIL compliance requirements.
Related Products
- IS210BPPCH1BEC: An upgraded version with enhanced thermal management, compatible with the IS210BPPCH1AEC in redundant configurations.
- IS210MACCH1AKH: Mark VIe turbine control module that relies on the IS210BPPCH1AEC for stable power supply.
- IS210AAHAH2ADC: Analog input module for Mark VIe systems, powered by the IS210BPPCH1AEC for reliable data acquisition.
- IS210TCCVH1A: Turbine vibration monitoring module, integrated with the IS210BPPCH1AEC in machinery protection systems.
- IS210CBLCH1A: Communication cable for Mark VIe racks, ensuring reliable data transmission alongside the IS210BPPCH1AEC.
- IS210TRBDH1A: Terminal base module, compatible with the IS210BPPCH1AEC for structured field wiring.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS210BPPCH1AEC, ensure the Mark VIe rack is properly grounded and ventilated. Verify input voltage compatibility (85–264 V AC) and install redundant power cables for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect input power using shielded cables and terminate them in the rack’s power distribution block, following GE’s wiring guidelines to minimize electromagnetic interference. For redundant setups, install a second IS210BPPCH1AEC in parallel configuration using dedicated redundancy cables.
Before installing the GE IS210BPPCH1AEC, ensure the Mark VIe rack is properly grounded and ventilated. Verify input voltage compatibility (85–264 V AC) and install redundant power cables for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect input power using shielded cables and terminate them in the rack’s power distribution block, following GE’s wiring guidelines to minimize electromagnetic interference. For redundant setups, install a second IS210BPPCH1AEC in parallel configuration using dedicated redundancy cables.
Maintenance Suggestions:
- Routine Inspections: Monthly visual checks of LED indicators to verify power status and fault conditions. Use a multimeter to measure output voltage and current, comparing readings against specifications.
- Cleaning and Cooling: Quarterly cleaning of the module’s vents to prevent dust accumulation, especially in dusty environments. Ensure the rack’s cooling fans operate efficiently to maintain optimal temperatures.
- Redundancy Testing: Annually simulate a power supply failure to verify the redundant module switches on correctly, ensuring system reliability. Document test results for compliance.
- Spare Parts Management: Store spare IS210BPPCH1AEC modules in a controlled environment (10–30°C, <50% humidity) to ensure rapid replacement during failures. Test spares periodically to maintain functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS210BPPCH1AEC, covering hardware defects under normal use. In the event of power output anomalies or functional failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS210BPPCH1AEC and related spares. Our technical support team assists with installation, redundancy configuration, and troubleshooting, ensuring reliable power supply for your industrial control systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
