GE IS200WREAS1ADB Mark VIe Relay Output Module
Product Overview
The GE IS200WREAS1ADB is a high-reliability Relay Output Module designed as a critical component of GE’s Mark VIe distributed control system (DCS), catering to industrial automation and machinery protection applications. Engineered to convert digital control signals into electrical relay outputs, this module enables precise switching of external devices such as valves, motors, and alarms in power generation, oil & gas, and manufacturing environments. As part of the IS200 Series for Mark VIe systems, the IS200WREAS1ADB integrates seamlessly with other Mark VIe modules (e.g., CPU, analog input modules), forming a robust control ecosystem for mission-critical processes.
Featuring a rugged industrial design, the GE IS200WREAS1ADB supports 16 isolated relay output channels, each capable of switching 24 V DC or 120 V AC loads up to 5 A. Its hermetically sealed relays and transient suppression circuitry protect against voltage spikes, ensuring reliable operation in harsh environments with temperature ranges from -40°C to +85°C. The module’s LED indicators provide real-time status feedback for each channel, simplifying troubleshooting and maintenance. With hot-swappable functionality, the IS200WREAS1ADB allows module replacement without powering down the system, minimizing downtime in 24/7 industrial operations.
In automation systems, the IS200WREAS1ADB serves as the interface between the Mark VIe controller and field devices, translating control logic into physical actions. Its compatibility with GE’s Proficy software suite enables remote configuration and monitoring, while built-in diagnostic features enhance system visibility. By combining high-density relay outputs with advanced fault tolerance, this module ensures reliable control in applications where safety and efficiency are paramount, such as turbine shutdown systems, process interlocks, and emergency response mechanisms.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200WREAS1ADB |
| Manufacturer | GE |
| Product Type | Relay Output Module |
| Platform | Mark VIe |
| Output Channels | 16 isolated relays |
| Switching Capacity | 5 A @ 24 V DC / 5 A @ 120 V AC |
| Contact Type | SPST (Single Pole, Single Throw) |
| Isolation | 500 V RMS between channels |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in Mark VIe enclosure |
| Power Supply | 24 V DC (from Mark VIe rack) |
Key Features and Advantages
High-Density Relay Switching: The IS200WREAS1ADB supports 16 independent relay channels in a compact form factor, maximizing space efficiency in control panels. This density is ideal for applications requiring multiple discrete outputs, such as turbine control systems or complex process interlocks.
Robust Electrical Protection: Built-in transient suppression diodes and overcurrent protection safeguard the module and connected devices from voltage spikes and overloads, extending component lifespan and reducing maintenance costs. The hermetically sealed relays prevent contamination, ensuring reliable switching in dusty or humid environments.
Hot-Swap Capability: The module can be replaced while the system is operational, allowing maintenance without interrupting critical processes. This feature is essential for industries where downtime translates to significant losses, such as power generation or oil refining.
Real-Time Diagnostics: LED indicators for each channel provide instant visual feedback on relay status (energized/de-energized), while built-in diagnostic circuitry monitors for open circuits or contact wear. This proactive monitoring reduces troubleshooting time and enhances system availability.
Wide Environmental Tolerance: Engineered to withstand extreme temperatures, vibration, and electromagnetic interference, the IS200WREAS1ADB meets rigorous industrial standards (e.g., IEC 61131-2), making it suitable for harsh environments like offshore platforms or heavy manufacturing facilities.
Seamless System Integration: Compatible with GE’s Mark VIe platform and Proficy programming tools, the module ensures easy integration with existing control systems. Its standardized interface simplifies configuration and reduces engineering time for both new installations and retrofits.
Application Areas
The GE IS200WREAS1ADB is widely deployed in industries requiring reliable discrete control and safety interlocks:
- Power Generation: Controls turbine trip systems, generator circuit breakers, and auxiliary equipment in thermal, hydro, and renewable energy plants, ensuring safe shutdowns and grid stability.
- Oil & Gas: Manages valve actuators, emergency shutdown (ESD) systems, and fire & gas detection relays in refineries, pipelines, and offshore platforms, adhering to strict safety standards.
- Manufacturing: Operates pneumatic valves, conveyor controls, and safety interlocks in automotive, chemical, and food processing plants, maintaining production continuity and quality.
- Water/Wastewater Treatment: Controls pumps, clarifiers, and chemical dosing systems, adapting to fluctuating flow rates while ensuring regulatory compliance.
Specific applications include:
- Turbine Protection Systems: Triggers emergency shutdowns in response to overspeed, vibration, or loss of lubrication pressure, preventing catastrophic equipment failure.
- Process Interlocks: Manages sequential operations in chemical reactors, ensuring safe startup, shutdown, and mode transitions.
- Alarm and Notification Systems: Activates visual/audio alarms and remote notifications in response to process anomalies, enhancing operator safety.
Related Products
- IS200AASAH1ADB (Analog Input Module): Complements the IS200WREAS1ADB by providing analog data acquisition for mixed-signal control systems.
- IS200AADA (Digital Input Module): Captures discrete signals from sensors, integrating with the IS200WREAS1ADB for closed-loop control.
- IS200TCTGG1A (Turbine Control Module): Processes control logic for the IS200WREAS1ADB in turbine applications, enabling precise speed and load regulation.
- IS200PWR (Power Supply Module): Ensures redundant power for the IS200WREAS1ADB and other Mark VIe modules, enhancing system reliability.
- IS200COMM (Communication Module): Enables Ethernet connectivity for the IS200WREAS1ADB, supporting remote monitoring via SCADA systems.
- IS200TBCH (Terminal Block Module): Simplifies field wiring for the IS200WREAS1ADB, reducing installation time and errors.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS200WREAS1ADB, ensure the Mark VIe rack is properly grounded and ventilated. Verify the power supply (24 V DC) and install redundant power modules for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect field devices to the module’s terminal blocks, using shielded cables for signal lines and separate wiring for power circuits to minimize interference. Use GE’s Proficy software to configure channel addresses and enable diagnostic features.
Before installing the GE IS200WREAS1ADB, ensure the Mark VIe rack is properly grounded and ventilated. Verify the power supply (24 V DC) and install redundant power modules for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect field devices to the module’s terminal blocks, using shielded cables for signal lines and separate wiring for power circuits to minimize interference. Use GE’s Proficy software to configure channel addresses and enable diagnostic features.
Maintenance Suggestions:
- Routine Inspections: Monthly visual checks of LED indicators to verify relay status and secure connections. Use Proficy software to review diagnostic reports for contact wear or open circuits.
- Cleaning and Protection: Quarterly cleaning of the module’s enclosure to remove dust or debris, especially in dusty environments. Apply dielectric grease to terminal connections to prevent corrosion.
- Relay Life Testing: Annually test relay contact resistance using a multimeter to ensure switching performance. Replace relays or the entire module if contact resistance exceeds specifications.
- Spare Parts Management: Store spare IS200WREAS1ADB modules in a static-free environment at room temperature, rotating inventory to ensure viability. Test spares periodically to maintain functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS200WREAS1ADB, covering hardware defects under normal use. In the event of relay failure or signal irregularities, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS200WREAS1ADB and related spares. Our technical support team assists with installation, configuration, and troubleshooting, delivering reliable solutions to maintain your control system’s integrity.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
