GE IS200WETAH1AGC Turbine Control Interface Module
Product Overview: GE IS200WETAH1AGC
The GE IS200WETAH1AGC Turbine Control Interface Module is a critical component of GE’s Mark VI Speedtronic™ turbine control system, designed to facilitate high-speed data exchange and precise control in gas and steam turbine applications. As part of the VMIVME series, this module serves as a bridge between turbine sensors, actuators, and the main control processor, ensuring seamless integration of real-time operational data into the broader automation network. Engineered for rugged reliability, the IS200WETAH1AGC supports advanced control algorithms and diagnostics, making it indispensable for mission-critical environments in power generation, oil and gas, and industrial manufacturing.
Featuring 24 isolated analog input channels and 16 digital output channels, the IS200WETAH1AGC processes signals from thermocouples, pressure transducers, and speed probes, converting them into actionable commands for turbine governors and protection systems. Its dual redundant communication buses (VMEbus and IONet) enable fail-safe data transmission, while the -40°C to +85°C operating range and IP65-rated enclosure ensure resilience in extreme temperatures, humidity, and vibration. The module’s hot-swappable design allows maintenance without system shutdown, minimizing downtime in 24/7 operations.
Within the Mark VI ecosystem, the IS200WETAH1AGC acts as a frontline interface, translating raw sensor data into control signals that optimize turbine efficiency and safety. Its compatibility with GE’s Proficy™ software enables remote configuration and predictive maintenance, reducing lifecycle costs and enhancing operational agility.
Technical Specifications: GE IS200WETAH1AGC
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200WETAH1AGC |
| Manufacturer | GE |
| Product Type | Turbine Control Interface Module |
| Series | Mark VI Speedtronic™, VMIVME Series |
| Input/Output Channels | 24 analog inputs, 16 digital outputs |
| Communication Protocols | VMEbus, IONet, Modbus RTU |
| Power Supply | 125 V DC (±10%) |
| Physical Dimensions | 30.48 cm (H) × 22.86 cm (W) × 7.62 cm (D) |
| Weight | 1.8 kg |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (VMEbus compatible) |
| Compliance | IEEE 1131-2, IEC 61131-3, CE, UL |
| Country of Origin | United States |
Main Features and Advantages: GE IS200WETAH1AGC
High-Density I/O Capability: The IS200WETAH1AGC integrates 24 analog inputs for precise monitoring of turbine parameters like temperature, pressure, and speed, alongside 16 digital outputs for controlling solenoids, relays, and other actuators. This density reduces the need for additional modules, simplifying system architecture and lowering costs.
Redundant Communication: With dual VMEbus and IONet interfaces, the module ensures continuous data flow even if one communication path fails. This redundancy is critical for maintaining control in applications where downtime risks catastrophic equipment damage or safety incidents.
Industrial-Grade Durability: The module’s IP65-rated metal enclosure and wide temperature tolerance make it suitable for harsh environments, including offshore platforms, power plants, and refineries. It resists corrosion, dust, and electromagnetic interference, ensuring reliable performance in extreme conditions.
Real-Time Diagnostics: Built-in self-test features and LED indicators provide instant feedback on module health, enabling rapid troubleshooting. The Proficy™ software integration allows remote diagnostics and firmware updates, enhancing maintenance efficiency.
Flexible Configuration: The IS200WETAH1AGC supports configurable input/output scaling and signal conditioning, adapting to diverse sensor types and control requirements. This flexibility makes it suitable for both legacy and modern turbine systems.
Application Areas: GE IS200WETAH1AGC
The GE IS200WETAH1AGC is engineered for industries requiring precise turbine control and data integration:
- Power Generation: Monitors steam and gas turbines in thermal, combined-cycle, and nuclear power plants, ensuring optimal energy output and grid stability. Its high-speed data processing supports real-time load balancing and compliance with environmental regulations.
- Oil and Gas: Integrates with turbines in offshore platforms and refineries to manage compressor and pump operations. The module’s rugged design withstands corrosive saltwater environments and high vibration, critical for remote offshore installations.
- Industrial Manufacturing: Used in chemical plants and paper mills to control energy-intensive processes. The IS200WETAH1AGC interfaces with variable-speed drives and process control systems, optimizing energy efficiency and production output.
- Marine Propulsion: Safeguards shipboard turbines by providing real-time monitoring and control, ensuring reliable operation in harsh marine conditions.
Related Products: GE IS200WETAH1AGC
- GE IS215WETAH1BB Daughterboard: A companion board that expands the IS200WETAH1AGC’s I/O capabilities, supporting additional analog and digital channels for complex turbine systems.
- GE IS200VCMIH2BCC VMEbus Communication Module: Enhances network connectivity by enabling integration with SCADA systems and enterprise-level networks, complementing the IS200WETAH1AGC’s I/O functions.
- GE IS215UCVEM10A VMEbus SBC: A single-board computer that works with the IS200WETAH1AGC to form a complete turbine control system, providing processing power for advanced algorithms.
- GE IS200VPROH1BD Emergency Turbine Protection Module: Functions alongside the IS200WETAH1AGC to ensure fail-safe shutdowns in overspeed or fault conditions, enhancing system safety.
- GE IS215ACLEH1B Application Control Layer Module: Improves data management in large-scale installations by coordinating communication between the IS200WETAH1AGC and other Mark VI modules.
Installation and Maintenance: GE IS200WETAH1AGC
Pre-installation Preparations:
Before installing the IS200WETAH1AGC, verify the VMEbus rack is grounded and powered (125 V DC). Align the module with the backplane connectors, securing it with the provided brackets. Connect analog and digital cables to the designated terminals, following GE’s wiring diagrams to avoid signal interference. Configure I/O parameters and communication settings via GE’s Proficy™ software, ensuring compatibility with connected sensors and actuators.
Before installing the IS200WETAH1AGC, verify the VMEbus rack is grounded and powered (125 V DC). Align the module with the backplane connectors, securing it with the provided brackets. Connect analog and digital cables to the designated terminals, following GE’s wiring diagrams to avoid signal interference. Configure I/O parameters and communication settings via GE’s Proficy™ software, ensuring compatibility with connected sensors and actuators.
Maintenance Recommendations:
- Monthly Inspections: Check LED indicators for faults and verify cable connections. Use compressed air to clean dust from ventilation slots, preventing overheating in high-dust environments.
- Annual Updates: Update firmware to the latest version to access new features and security patches. Perform functional tests to validate I/O channel responsiveness and communication integrity.
- Spare Parts Management: Maintain a spare IS200WETAH1AGC in inventory, leveraging our global supply chain for rapid replacement. Regularly test spare modules to ensure operational readiness.
- Environmental Monitoring: Quarterly assess ambient temperature and humidity levels around the module, ensuring they remain within specified ranges to avoid performance degradation.
Product Guarantee: GE IS200WETAH1AGC
Our company provides a 12-month quality warranty for the GE IS200WETAH1AGC, covering hardware defects not caused by misuse or improper installation. During the warranty period, we offer free replacement for faulty modules and prioritize urgent orders through our extensive inventory and logistics network. With 17 years of industry experience, we ensure reliable support for your critical turbine control needs, even for discontinued or rare components.
Note: All product names, logos, and brands are property of their respective owners. This document is informational and does not substitute for GE’s official technical manuals.
