GE IS200VPWRH1AHD Product Specification
Product Overview
The GE IS200VPWRH1AHD is a high-reliability power supply module engineered for GE’s Mark VIe Turbine Control System, a cornerstone of industrial automation in power generation and heavy machinery applications. As a critical component of the Speedtronic Mark VIe platform, this module delivers stable DC power to control electronics, ensuring seamless operation of gas and steam turbines, compressors, and other rotating equipment. The GE IS200VPWRH1AHD integrates advanced power regulation technology with rugged industrial design, making it essential for industries requiring uninterrupted operation, such as power plants, oil and gas facilities, and manufacturing complexes.
Designed to convert 120/240 VAC input to a regulated 24 VDC output, the GE IS200VPWRH1AHD features a redundant design that supports hot-swappable replacement, minimizing downtime in mission-critical systems. Its compact form factor (178 mm × 102 mm × 254 mm) and lightweight construction (3.2 kg) facilitate easy integration into control cabinets, while the IP23-rated enclosure protects against dust and moisture. The module’s built-in overcurrent and thermal protection mechanisms enhance system longevity, making it suitable for harsh environments with temperature fluctuations or vibration.
In automation systems, the GE IS200VPWRH1AHD acts as a stable power backbone for the Mark VIe control system, enabling precise regulation of turbine speed, load, and emissions. Its high-efficiency power conversion (up to 90%) reduces energy consumption, while diagnostic LEDs provide real-time status monitoring. By ensuring consistent power delivery to control modules and sensors, the GE IS200VPWRH1AHD supports predictive maintenance strategies and helps maintain compliance with industry safety standards.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS200VPWRH1AHD |
| Manufacturer | General Electric (GE) |
| Product Type | Power Supply Module (Mark VIe System) |
| Input Voltage | 120/240 VAC ±10% (auto-ranging) |
| Output Voltage | 24 VDC ±0.5% |
| Output Current | 10 A continuous |
| Efficiency | Up to 90% |
| Physical Dimensions | 178 mm (W) × 102 mm (H) × 254 mm (D) |
| Weight | 3.2 kg |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Enclosure Rating | IP23 |
| Certifications | CE, UL, CSA |
Main Features and Advantages
Redundant Power Design: The GE IS200VPWRH1AHD supports parallel operation with other power modules, enabling redundant configurations that eliminate single points of failure. This feature is critical for 24/7 industrial applications where uninterrupted power is non-negotiable, such as turbine control systems in power plants.
Hot-Swap Capability: The module’s hot-swappable design allows replacement without powering down the control system, reducing maintenance downtime. This is particularly valuable in scenarios where system shutdowns would result in significant operational losses, such as during turbine maintenance cycles.
Advanced Protection Mechanisms: Built-in overvoltage, overcurrent, and thermal protection safeguards the module and connected components from damage, extending system lifespan. The thermal shutdown feature automatically resets once conditions normalize, minimizing manual intervention.
High-Efficiency Power Conversion: With up to 90% efficiency, the GE IS200VPWRH1AHD reduces energy waste and heat generation, making it suitable for high-density control cabinets. This efficiency also contributes to lower operational costs in large-scale installations.
Comprehensive Diagnostics: Front-panel LEDs indicate power status, overload conditions, and thermal warnings, enabling quick fault identification. The module’s self-diagnostic capabilities support proactive maintenance, reducing the risk of unexpected failures.
Application Areas
The GE IS200VPWRH1AHD is widely deployed in industries requiring reliable power for critical control systems:
-
Power Generation:
- Powers GE Mark VIe turbine control systems in natural gas combined-cycle power plants, ensuring stable operation of generators and grid synchronization.
- Supports emergency shutdown systems (ESD) in steam turbine applications, maintaining safety during abnormal operating conditions.
-
Oil and Gas:
- Supplies power to compressor control systems in pipeline networks, enabling precise flow regulation and pressure monitoring.
- Integrates with gas turbine-driven compressors in refineries, supporting efficient hydrocarbon processing.
-
Manufacturing:
- Powers robotic arm control systems in automotive plants, ensuring precise motion control and reducing production errors.
- Supports high-speed packaging machinery in food and beverage facilities, maintaining consistent operation during peak production periods.
-
Marine and Aerospace:
- Powers propulsion system controls in naval vessels, ensuring reliable operation in harsh marine environments.
- Supports testing facilities for aircraft engine control systems, where stable power is critical for performance evaluation.
Related Products
- GE IS200VPWRA1A: A legacy power supply module for Mark VIe systems, offering similar functionality but with a lower output current (5 A) compared to the GE IS200VPWRH1AHD.
- GE IS200VPWRC1A: A redundant power supply controller that pairs with the GE IS200VPWRH1AHD to manage parallel operation and fault switching in redundant configurations.
- GE IS200DSPXH1B: A digital signal processing module for Mark VIe systems, relying on the GE IS200VPWRH1AHD for stable power during high-speed data processing.
- GE IS200TBPSH1A: A terminal block power supply adapter that interfaces with the GE IS200VPWRH1AHD to distribute power to multiple control modules.
- GE IS200VSPSH1A: A voltage sensor power supply module that works alongside the GE IS200VPWRH1AHD to monitor and regulate input voltage stability.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IS200VPWRH1AHD, ensure the following:
Before installing the GE IS200VPWRH1AHD, ensure the following:
- Verify the input voltage (120/240 VAC) matches the module’s specifications and that the control cabinet is properly grounded to prevent electrostatic discharge (ESD). Use a multimeter to confirm voltage stability and phase configuration.
- If deploying in a redundant setup, install the GE IS200VPWRC1A controller first and configure parallel operation settings using GE’s Proficy software.
- Mount the module in a 19″ rack with at least 50 mm of clearance for airflow, securing it with the provided brackets to minimize vibration-induced displacement.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks of front-panel LEDs (green for normal operation, red for faults) and cleaning of dust from ventilation slots using a non-conductive brush.
- Load Testing: Quarterly verification of output voltage and current using a calibrated multimeter to ensure performance within specifications.
- Thermal Management: Annual inspection of cooling fans for debris or wear, replacing them if abnormal noise or reduced airflow is detected.
- Firmware Updates: Periodically update the module’s firmware via GE’s dedicated software to access compatibility improvements with newer Mark VIe system versions.
Product Warranty
Our company provides a one-year quality warranty for the GE IS200VPWRH1AHD, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits abnormal power output or functional defects. For discontinued models like the GE IS200VPWRH1AHD, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services, leveraging our 17 years of expertise in industrial control distribution to maintain your system’s reliability.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on technical data from GE’s official specifications and industry applications. For detailed installation guidelines, refer to the GE IS200VPWRH1AHD user manual or contact our technical support team.
