The GE IS200TTURH1CCC S1DF00Z terminal turbine board is a critical component within GE’s Mark VI Speedtronic turbine control system, designed to provide reliable control and protection for industrial gas and steam turbines. As part of the IS200 series, this board serves as a central hub for managing turbine synchronization, overspeed protection, and trip logic execution, ensuring seamless operation in power generation, oil & gas, and heavy industrial environments .

Engineered for high-reliability applications, the IS200TTURH1CCC S1DF00Z features a rugged design with conformal PCB coating to resist environmental stressors such as dust, moisture, and vibration. It supports both simplex and TMR (Triple Modular Redundancy) configurations via jumper switches, offering flexibility for mission-critical systems where downtime is unacceptable . The board interfaces with the TRPG (Trip Relay Panel Group) through three 37-pin connectors (P1/P2/P3) and two terminal blocks (24+24 pins), enabling precise control of turbine protection functions, including generator breaker tripping and emergency shutdowns .Whatsapp:+86 18859254943.

In automation systems, the IS200TTURH1CCC S1DF00Z acts as a bridge between the turbine control processor and field devices, translating control signals into actionable commands. Its dual 28V DC power inputs ensure continuous operation even during transient voltage fluctuations, while integrated fuses protect against short circuits and overcurrent conditions. By maintaining synchronization between the turbine and generator, this board plays a pivotal role in optimizing energy output and preventing catastrophic failures in power plants and industrial facilities .

Technical Specifications

Parameter Name	Parameter Value
Product Model	IS200TTURH1CCC S1DF00Z
Manufacturer	GE
Product Type	Terminal Turbine Board
Input Voltage	28V DC (dual redundant)
Output Voltage	24V DC (regulated)
Connector Type	3 x 37-pin (P1/P2/P3), 2 x 24-pin terminal blocks
Physical Dimensions	6.5 x 7 inches
Mounting Type	DIN rail
Weight	1.2 kg
Operating Temperature	-20°C to +60°C
Humidity	5–95% non-condensing
Protection Rating	IP20
Redundancy Support	Simplex and TMR configurations
PCB Coating	Conformal coating for environmental protection

IS200TTURH1CCC S1DF00Z

Key Features and Advantages

High-Reliability Redundancy: The IS200TTURH1CCC S1DF00Z supports both simplex and TMR configurations, allowing users to tailor system redundancy based on operational needs. TMR mode ensures fault tolerance by voting on outputs from three independent channels, making it ideal for safety-critical applications .

Robust Environmental Protection: With a conformal PCB coating and IP20 rating, the board withstands harsh industrial conditions, including extreme temperatures, humidity, and vibration. This durability minimizes maintenance requirements and extends service life in demanding environments .

Flexible Connectivity: The board’s multiple connectors (37-pin and terminal blocks) enable seamless integration with other Mark VI components, such as IS200ADIIH1A dual-channel I/O modules and IS200ACLAH1A application control layers. This flexibility simplifies system expansion and retrofitting .

Precision Control: By interfacing with the TRPG board, the IS200TTURH1CCC S1DF00Z executes precise trip logic and synchronization commands, ensuring the turbine operates within safe parameters. Its high-speed processing capability reduces response times, enhancing overall system stability .Whatsapp:+86 18859254943.

Easy Configuration: The board’s jumper switches allow quick reconfiguration between simplex and TMR modes without requiring firmware changes. This simplicity streamlines setup and troubleshooting, reducing downtime during maintenance .

Application Areas

The GE IS200TTURH1CCC S1DF00Z terminal turbine board is widely used in industries where turbine control and protection are paramount:

Power Generation: Integrates with GE’s Mark VI system to manage synchronization and overspeed protection in gas and steam turbines, ensuring stable energy output and grid compliance.
Oil & Gas: Supports critical operations in offshore platforms and refineries, controlling turbine-driven compressors and pumps to maintain production continuity.
Industrial Manufacturing: Powers control systems in heavy machinery, such as rolling mills and conveyor belts, optimizing efficiency and reducing mechanical wear.
Water Treatment: Manages turbine-driven pumps in wastewater treatment plants, ensuring consistent flow rates and chemical dosing for regulatory compliance.
Mining: Reliably controls ventilation systems and crushers in mining operations, enhancing safety and productivity in harsh underground environments .
IS200TTURH1CCC S1DF00Z

Installation and Maintenance

Installation Preparation:
Before installing the IS200TTURH1CCC S1DF00Z, verify the input voltage (28V DC) matches the power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the board with the rail and secure it using mounting clips. Connect power cables to the terminal blocks, ensuring torque specifications (35A max per terminal) are met. Finally, link the board to adjacent modules via the P1/P2/P3 connectors and terminal blocks, following GE’s wiring guidelines. Use anti-static wristbands and packaging to prevent electrostatic discharge during handling .

Maintenance Recommendations:

Routine Inspections: Quarterly checks for loose connections, blown fuses, or signs of overheating. Clean the board’s surface to prevent dust accumulation.
Fuse Replacement: Replace blown fuses with GE-certified 5A fuses to maintain overload protection. Avoid using higher-rated fuses, as this may compromise safety.
Connector Checks: Inspect 37-pin connectors and terminal blocks annually for corrosion or damage. Re-seat connectors if necessary to ensure reliable signal transmission.
Firmware Updates: While the IS200TTURH1CCC S1DF00Z does not require firmware updates, consult GE’s technical documentation for any hardware revisions or compatibility notices .
IS200TTURH1CCC S1DF00Z

Product Warranty

We provide a 12-month quality warranty for the GE IS200TTURH1CCC S1DF00Z terminal turbine board, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning board free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.

With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your turbine control system with the IS200TTURH1CCC S1DF00Z terminal turbine board.
