GE IS200TDBTH6ABC Terminal Board Module
Product Overview: GE IS200TDBTH6ABC
The GE IS200TDBTH6ABC terminal board module is a high-reliability industrial connectivity solution designed for GE’s Mark VIe Turbine Control System, a cornerstone of automation in power generation and heavy machinery applications. As a critical component of this advanced platform, the IS200TDBTH6ABC serves as a robust interface between field sensors, actuators, and control modules, enabling seamless signal transmission and power distribution in mission-critical systems. Engineered for durability and precision, this terminal board integrates seamlessly with GE’s Mark VIe architecture, supporting complex control strategies in gas turbines, steam turbines, and other rotating equipment.
Featuring a modular design and standardized terminal block configuration, the IS200TDBTH6ABC simplifies wiring and maintenance for industrial control setups. Its rugged metal enclosure and -40°C to +70°C operating range make it suitable for harsh environments, including power plants, oil refineries, and manufacturing facilities. The module’s high-density terminal layout accommodates multiple signal types (analog, digital, power), while its built-in surge protection safeguards connected components from electrical disturbances. As a key element in GE’s Mark VIe ecosystem, the IS200TDBTH6ABC enhances system reliability by providing a secure, organized platform for field wiring, reducing the risk of connection failures and minimizing downtime.
Technical Specifications: GE IS200TDBTH6ABC
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TDBTH6ABC |
| Manufacturer | GE |
| Product Type | Terminal Board Module |
| Terminal Count | 32 channels (16 input, 16 output) |
| Voltage Rating | 24V DC, 120V AC, 240V AC |
| Current Rating | 5A per terminal |
| Physical Dimensions | 200 mm (H) × 150 mm (W) × 50 mm (D) |
| Weight | 0.8 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | DIN rail or panel-mounted |
| Protection Features | Surge protection, short-circuit isolation |
| Country of Origin | United States |
Main Features and Advantages: GE IS200TDBTH6ABC
High-Density Connectivity: The IS200TDBTH6ABC offers 32 terminal channels, supporting a mix of analog and digital signals for versatile connectivity. This density allows compact installation in control cabinets, optimizing space in complex industrial setups.
Robust Environmental Resistance: Built with a rugged metal enclosure and rated for extreme temperatures, the module withstands vibration, dust, and moisture, ensuring reliable performance in harsh industrial environments. Its surge protection circuitry minimizes the risk of damage from electrical transients.
Modular and Serviceable Design: The module’s plug-and-play architecture enables quick replacement without system shutdown, reducing maintenance time. Standardized terminal blocks simplify wiring and troubleshooting, even for technicians unfamiliar with the system.
Compatibility with Mark VIe System: Specifically engineered for GE’s Mark VIe Turbine Control System, the IS200TDBTH6ABC ensures seamless integration with control modules (e.g., IS200TBCIH2CAA) and communication gateways, maintaining signal integrity and system coherence.
Enhanced Safety Features: Built-in short-circuit isolation and overcurrent protection safeguard connected field devices and control modules, enhancing overall system safety and reducing the likelihood of cascading failures.
Application Areas: GE IS200TDBTH6ABC
The GE IS200TDBTH6ABC terminal board module is essential for industries relying on precise control and monitoring of heavy machinery:
- Power Generation: Installed in gas and steam turbine control systems to connect sensors (temperature, pressure, vibration) to the Mark VIe controller, enabling real-time data acquisition and turbine protection.
- Oil and Gas: Used in refineries and pipeline compressor stations to interface with flow meters, pressure switches, and valve actuators, supporting process control and safety interlocks.
- Manufacturing: Integrates with industrial robots, CNC machines, and conveyor systems, providing a reliable wiring platform for control signals and power distribution.
- Water Treatment: Connects pumps, valves, and analytical instruments in water/wastewater plants, ensuring continuous operation and regulatory compliance.
- Marine Engineering: Deployed in shipboard turbine and propulsion systems, withstanding the harsh marine environment (humidity, salt spray) while maintaining connectivity.
Related Products: GE IS200TDBTH6ABC
- GE IS200TBCIH2CAA Control Module: A 配套使用 control module for the Mark VIe system, interfacing with the IS200TDBTH6ABC to process sensor data.
- GE IS200TBPSH1AAA Power Supply Module: Provides stable power to the terminal board and connected devices, ensuring reliable operation.
- GE IS200TBRPH1BAA Relay Module: Works with the IS200TDBTH6ABC to enable relay-based control and alarm functions in turbine systems.
- GE IS200TCCPH2AAA Communication Module: Enables Ethernet/IP connectivity for the Mark VIe system, integrating the IS200TDBTH6ABC into supervisory control networks.
- GE IS200TADGH1BAA Analog Input Module: Connects analog sensors to the terminal board, expanding the system’s data acquisition capabilities.
- GE IS200TBDCH1AAA Digital Output Module: Controls actuators via the IS200TDBTH6ABC, translating digital signals into physical actions.
Installation and Maintenance: GE IS200TDBTH6ABC
Pre-installation Preparations:
Before installing the IS200TDBTH6ABC, verify the control cabinet meets environmental requirements (temperature, humidity) and is properly grounded. Clean the mounting surface and secure the module to a DIN rail or panel using the provided brackets. Route shielded cables to the terminal block, separating power and signal wires to minimize interference. Label each terminal connection according to the wiring diagram, ensuring correct polarity for power and signal lines. Test continuity and insulation resistance before powering up the system.
Before installing the IS200TDBTH6ABC, verify the control cabinet meets environmental requirements (temperature, humidity) and is properly grounded. Clean the mounting surface and secure the module to a DIN rail or panel using the provided brackets. Route shielded cables to the terminal block, separating power and signal wires to minimize interference. Label each terminal connection according to the wiring diagram, ensuring correct polarity for power and signal lines. Test continuity and insulation resistance before powering up the system.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for loose connections, frayed cables, or signs of corrosion. Tighten terminal screws to the specified torque (0.8–1.2 N·m) to prevent voltage drops.
- Environmental Monitoring: Regularly assess ambient conditions to ensure they remain within the module’s operating limits. Install additional cooling or heating if necessary to prevent temperature extremes.
- Functionality Testing: Quarterly test signal transmission by measuring voltage/current at terminals and comparing with expected values. Use GE’s Proficy software to verify data integrity between the terminal board and control modules.
- Spare Parts Management: Keep a spare IS200TDBTH6ABC on hand, along with replacement terminal blocks and surge protectors, to facilitate quick repairs. Leverage our global supply chain for urgent replacements of discontinued components.
Product Guarantee: GE IS200TDBTH6ABC
Our company provides a 12-month quality warranty for the GE IS200TDBTH6ABC terminal board module, covering hardware defects from non-human causes. During the warranty period, we will replace any module with faulty terminals, damaged enclosures, or connectivity issues at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt delivery, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable products and exceptional service. The IS200TDBTH6ABC exemplifies our dedication to quality, offering robust connectivity for critical turbine control systems. Contact us today to optimize your industrial wiring with this durable terminal board module.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for GE’s official technical manuals.
