Product Overview：GE IS200AEPAH1ACB+IS210BPPBH2BMD
The GE IS200AEPAH1ACB+IS210BPPBH2BMD integrated control solution combines two critical components of GE’s Mark VI Speedtronic turbine control system, delivering a robust and scalable platform for industrial automation. The IS200AEPAH1ACB is a high-performance analog input/output (I/O) module, while the IS210BPPBH2BMD serves as a printed circuit board (PCB) for power distribution and signal conditioning. Together, they form a cohesive system for managing gas turbines, steam turbines, and other rotating machinery in mission-critical environments.
The IS200AEPAH1ACB supports 16-channel analog input/output with ±10V DC or 4–20mA signals, enabling precise monitoring and control of process variables such as temperature, pressure, and flow. Its isolated channels protect against electromagnetic interference (EMI), ensuring reliable data transmission in noisy industrial settings. The IS210BPPBH2BMD, meanwhile, interfaces with the main WETA board to provide redundant power supply management and signal routing, featuring two female plugs and transformers for stable voltage regulation.
In automation systems, the IS200AEPAH1ACB+IS210BPPBH2BMD combination acts as a backbone for turbine control, integrating seamlessly with GE’s Mark VI platform. The IS200AEPAH1ACB processes real-time sensor data, while the IS210BPPBH2BMD ensures consistent power delivery to downstream components. This synergy enhances system reliability, reduces downtime, and supports predictive maintenance strategies in industries such as power generation, oil & gas, and heavy manufacturing.
Technical Specifications：GE IS200AEPAH1ACB+IS210BPPBH2BMD
| Parameter Name | IS200AEPAH1ACB | IS210BPPBH2BMD |
|---|---|---|
| Product Model | IS200AEPAH1ACB | IS210BPPBH2BMD |
| Manufacturer | GE | GE |
| Product Type | Analog I/O Module | Power Distribution PCB |
| Input Voltage | 24–48V DC | 28V DC |
| Output Voltage | ±10V DC / 4–20mA | Regulated 24V DC |
| Channels | 16 analog (8 AI / 8 AO) | N/A |
| Connector Type | 50-pin DIN connectors | 3-position plug + DC62 connector |
| Physical Dimensions | 10.2 x 15.2 cm | 8.9 x 12.7 cm |
| Weight | 0.8 kg | 0.26 kg |
| Operating Temperature | -20°C to +60°C | -20°C to +60°C |
| Humidity | 5–95% non-condensing | 5–95% non-condensing |
| Protection Rating | IP20 | IP20 |
IS200AEPAH1ACB+IS210BPPBH2BMD
Key Features and Advantages：GE IS200AEPAH1ACB+IS210BPPBH2BMD
High-Precision Signal Handling: The IS200AEPAH1ACB’s 16-channel analog I/O supports ±0.1% accuracy, ensuring precise control of turbine operations. Its programmable input ranges allow seamless integration with a wide range of sensors, from thermocouples to pressure transmitters.
Redundant Power Architecture: The IS210BPPBH2BMD incorporates dual power input channels, ensuring continuous operation even if one path fails. This redundancy is critical for applications where downtime is costly, such as power plants and petrochemical facilities.
Rugged Design: Both modules feature industrial-grade PCB coatings to withstand harsh environmental conditions, including vibration, dust, and temperature fluctuations. The IS210BPPBH2BMD’s fiberglass NEMA 4X enclosure further enhances durability in corrosive environments.
Flexible Connectivity: The IS200AEPAH1ACB’s 50-pin DIN connectors enable easy integration with other Mark VI modules, while the IS210BPPBH2BMD’s three-position plug and DC62 connector support flexible power distribution to auxiliary systems.
Predictive Maintenance: By analyzing real-time data from the IS200AEPAH1ACB, the solution detects anomalies in turbine performance, enabling proactive maintenance. The IS210BPPBH2BMD’s LED indicators provide visual status monitoring, simplifying fault diagnosis.
IS200AEPAH1ACB+IS210BPPBH2BMD
Application Areas：GE IS200AEPAH1ACB+IS210BPPBH2BMD
The GE IS200AEPAH1ACB+IS210BPPBH2BMD integrated control solution is ideally suited for industries requiring reliable turbine control and power management:
- Power Generation: Manages gas and steam turbines in power plants, ensuring stable energy output and grid synchronization. The IS200AEPAH1ACB monitors turbine speed and temperature, while the IS210BPPBH2BMD ensures uninterrupted power supply to control systems.
- Oil & Gas: Deployed in offshore platforms and refineries to regulate compressors, pumps, and motors. The solution’s ATEX/IECEx certification (optional) ensures safe operation in explosive environments.
- Industrial Manufacturing: Optimizes performance of heavy machinery, such as rolling mills and conveyor belts, by providing real-time process control and power distribution.
- Water Treatment: Controls pumps, valves, and monitoring equipment in wastewater treatment plants, ensuring compliance with environmental standards.
- Mining: Enhances safety and productivity in mining operations by monitoring ventilation systems, crushers, and conveyor belts.
Related Products：GE IS200AEPAH1ACB+IS210BPPBH2BMD
- IS200ADIIH1A: A dual-channel I/O module sets with the IS200AEPAH1ACB for analog and digital signal processing in turbine control systems.
- IS200ACLAH1A: An application control layer module that interfaces with the IS200AEPAH1ACB to execute control algorithms and monitor system health.
- IS210BPPBH2BMD: The sets power distribution PCB for the IS200AEPAH1ACB, ensuring stable voltage regulation and signal routing.
- IS200AEPCH1A: An alternative energy pitch center module compatible with the Mark VI system, expanding its functionality for wind turbine applications.
- IS200BICLH1A: An IGBT drive/source bridge interface board that works alongside the IS200AEPAH1ACB to manage high-power loads.
- IS200BPIBG1A: A phase logic module that enhances the solution’s control capabilities for complex industrial processes.
- IS200AVSCG1A: An SCR control board that complements the IS200AEPAH1ACB in high-voltage applications.
- IS200BPIHH1A: A bridge personality interface board that enables customization of the control system for specific turbine configurations.
IS200AEPAH1ACB+IS210BPPBH2BMD
Installation and Maintenance：GE IS200AEPAH1ACB+IS210BPPBH2BMD
Installation Preparation:
Before installing the IS200AEPAH1ACB+IS210BPPBH2BMD, verify the input voltage matches the 24–48V DC (IS200AEPAH1ACB) and 28V DC (IS210BPPBH2BMD) requirements. Clean the DIN rail and ensure proper grounding to minimize EMI. Align the IS200AEPAH1ACB with the rail and secure it using mounting clips. Connect the IS210BPPBH2BMD to the main WETA board via its three-position plug and DC62 connector, following GE’s wiring guidelines.
Before installing the IS200AEPAH1ACB+IS210BPPBH2BMD, verify the input voltage matches the 24–48V DC (IS200AEPAH1ACB) and 28V DC (IS210BPPBH2BMD) requirements. Clean the DIN rail and ensure proper grounding to minimize EMI. Align the IS200AEPAH1ACB with the rail and secure it using mounting clips. Connect the IS210BPPBH2BMD to the main WETA board via its three-position plug and DC62 connector, following GE’s wiring guidelines.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections, blown fuses, or signs of overheating. Clean both modules quarterly to prevent dust accumulation.
- Sensor Calibration: Calibrate the IS200AEPAH1ACB’s analog inputs annually using GE-certified tools to ensure accuracy.
- Connector Checks: Inspect connectors for corrosion or damage during annual maintenance. Re-seat connectors if necessary to ensure reliable signal transmission.
- Firmware Updates: While the IS200AEPAH1ACB and IS210BPPBH2BMD do not require firmware updates, consult GE’s technical documentation for any hardware revisions or compatibility notices.
IS200AEPAH1ACB+IS210BPPBH2BMD
Product Warranty：GE IS200AEPAH1ACB+IS210BPPBH2BMD
We provide a 12-month quality warranty for the GE IS200AEPAH1ACB+IS210BPPBH2BMD integrated control solution, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your turbine control system with the IS200AEPAH1ACB+IS210BPPBH2BMD integrated solution.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
