DEIF IPM-1 | DU2.1 | DGU-1 | GPU-3 PCM5.1

Original price was: $650.00.Current price is: $597.00.

The DEIF IPM-1 is a high-performance Intelligent Power Module designed for critical power management and control applications in industrial and marine environments. Engineered by DEIF, a global leader in power system automation, the IPM-1 serves as a core component in distributed power generation systems, microgrids, and marine power plants.
Product Model：DEIF IPM-1
Manufacturer：DEIF
Product Type：Intelligent Power Module (Analog/Digital I/O Module)
Input Voltage Range：24 VDC ±15%
Input Channels：8 analog inputs (0–20 mA/0–10 V), 16 digital inputs (24 VDC)
Output Channels：8 digital outputs (24 VDC, 0.5 A per channel)

Get a Quote
Category: Brand:

Description

Product Overview

The DEIF IPM-1 is a high-performance Intelligent Power Module designed for critical power management and control applications in industrial and marine environments. Engineered by DEIF, a global leader in power system automation, the IPM-1 serves as a core component in distributed power generation systems, microgrids, and marine power plants. It acts as a bridge between field devices, sensors, and higher-level control systems, enabling real-time monitoring, data acquisition, and precise control of power generation and distribution processes.



As part of DEIF’s modular control platform, the IPM-1 offers flexible configuration options to adapt to diverse system requirements. It supports multiple analog and digital input/output channels, allowing seamless integration with generators, switchgear, and renewable energy sources. The module’s robust design ensures reliable operation in harsh conditions, including extreme temperatures, high humidity, and electromagnetic interference—common in offshore, industrial, and marine settings. By consolidating signal conditioning, data processing, and communication functions into a single unit, the IPM-1 simplifies system architecture while enhancing operational efficiency and scalability.



Key to its value is the IPM-1’s role in optimizing power system stability. It monitors parameters such as voltage, current, frequency, and temperature, providing actionable insights to prevent overloads, voltage fluctuations, and equipment failures. The module also facilitates advanced control strategies, such as load sharing, synchronization, and fault detection, ensuring smooth coordination between multiple power sources. Whether used in standalone generators or complex grid-connected systems, the IPM-1 delivers precision control and diagnostic capabilities that reduce downtime and maintenance costs.

Technical Specifications

Parameter Name Parameter Value
Product Model DEIF IPM-1
Manufacturer DEIF
Product Type Intelligent Power Module (Analog/Digital I/O Module)
Input Voltage Range 24 VDC ±15%
Input Channels 8 analog inputs (0–20 mA/0–10 V), 16 digital inputs (24 VDC)
Output Channels 8 digital outputs (24 VDC, 0.5 A per channel)
Communication Protocols Modbus RTU, CANopen, Ethernet (optional)
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +85°C
Relative Humidity 5%–95% non-condensing
Dimensions 122 mm (height) × 114 mm (depth) × 328.5 mm (width)
Weight 0.65 kg
Approvals CE, UL, DNV GL (marine certification)
ROHS Compliance Yes
IPM-1

IPM-1

Main Features and Advantages

Rugged and Reliable Design

The DEIF IPM-1 is built to withstand extreme environmental conditions, making it ideal for marine, offshore, and industrial applications. Its enclosure is engineered to resist vibrations, shocks, and corrosive elements, ensuring long-term durability. The module’s redundant power supply inputs (24 VDC) and fail-safe circuitry further enhance reliability, minimizing the risk of system disruptions.

Flexible I/O Configuration

With 8 analog inputs and 16 digital I/O channels, the IPM-1 supports a wide range of sensors and actuators. Analog inputs can be configured for current (0–20 mA) or voltage (0–10 V) signals, while digital channels provide isolated switching for control commands and status feedback. This versatility allows the module to interface with generators, circuit breakers, voltage regulators, and other critical components in power systems.

Advanced Communication Capabilities

The IPM-1 integrates seamlessly with DEIF’s control systems and third-party devices via industry-standard protocols like Modbus RTU and CANopen. An optional Ethernet interface enables high-speed data exchange with SCADA systems, PLCs, and cloud-based platforms, facilitating remote monitoring and predictive maintenance. This connectivity ensures real-time data synchronization and centralized control across distributed power networks.

Precision Monitoring and Control

Equipped with high-resolution ADCs and advanced signal processing algorithms, the IPM-1 delivers accurate measurements of electrical parameters. It supports frequency tracking, phase synchronization, and harmonic analysis, enabling precise load management and fault detection. The module’s built-in logic functions also allow for autonomous control actions, such as generator start/stop sequences and breaker tripping, reducing reliance on external controllers.

IPM-1

IPM-1

Easy Integration and Maintenance

The IPM-1 features a plug-and-play design with screw-terminal connections for quick installation. Its modular architecture allows for field replaceability of components, minimizing downtime during maintenance. DEIF’s intuitive configuration software (e.g., PICUS) simplifies parameter setup, calibration, and diagnostics, while firmware updates can be performed remotely to add new functionalities or address security patches.

Application Areas

Marine and Offshore Power Systems

In marine environments, the DEIF IPM-1 is used to monitor and control onboard generators, switchboards, and propulsion systems. It ensures stable power supply during transients, such as when heavy loads are connected or disconnected, and supports load sharing between multiple gensets. The module’s marine certification (DNV GL) makes it suitable for vessels, offshore rigs, and port facilities.

Industrial Power Generation

In industrial settings, the IPM-1 plays a critical role in managing distributed energy resources (DERs), including diesel generators, gas turbines, and renewable energy sources. It optimizes power output, synchronizes generators with the grid, and coordinates load shedding to prevent overloading. This is particularly valuable in manufacturing plants, data centers, and mining operations where continuous power is essential.

Microgrids and Energy Storage Systems

For microgrids and energy storage applications, the IPM-1 facilitates seamless integration of solar panels, wind turbines, and battery banks. It monitors energy flow, balances supply and demand, and ensures grid stability during islanded or grid-connected modes. The module’s communication capabilities enable integration with energy management systems (EMS) for optimized resource allocation.

IPM-1

IPM-1

Power Distribution and Protection

The IPM-1 is deployed in switchgear and substation automation to monitor circuit breakers, relays, and transformers. It provides real-time data on fault currents, voltage sags, and harmonic distortion, triggering protective actions to prevent equipment damage. This makes it a key component in smart grid infrastructure and industrial power distribution networks.

Related Products

  1. DEIF SCM-1
    A communication module that works alongside the IPM-1 to enable Ethernet-based data transmission and remote access. It supports protocols like Modbus TCP and OPC UA, enhancing connectivity with higher-level systems 2.
  2. DEIF PPU 300

    A paralleling and protection unit designed for generator control. The PPU 300 integrates with the IPM-1 to manage load sharing, synchronization, and fault protection in multi-generator systems 12.

  3. DEIF GPU 300

    A generator protection unit that complements the IPM-1 by providing advanced protection functions, such as overcurrent, overvoltage, and reverse power protection. It interfaces with the IPM-1 to execute control actions during faults 12.

  4. DEIF CM-2

    A control module used in DEIF’s Delomatic system for comprehensive power management. The CM-2 can be paired with the IPM-1 to expand I/O capabilities and implement complex control logic 13.

  5. DEIF AI810

    An analog input module that supplements the IPM-1’s I/O channels for applications requiring additional sensor connectivity. It supports thermocouples, RTDs, and voltage/current inputs 12.

  6. DEIF AO810

    An analog output module used to control actuators, valves, and other devices based on data processed by the IPM-1. It provides 0–20 mA or 0–10 V signals for precise regulation 12.

  7. DEIF DSDI115

    A digital input module that interfaces with binary sensors and switches. It can be used alongside the IPM-1 to expand the system’s monitoring capabilities for discrete signals 12.

  8. DEIF DSDO115

    A digital output module for controlling relays and contactors. It works with the IPM-1 to execute control commands in power systems 12.

    IPM-1

    IPM-1

Installation and Maintenance

Installation Preparation:
Before installing the DEIF IPM-1, ensure the following steps are completed:



  • Verify the power supply voltage matches the module’s requirements (24 VDC ±15%).
  • Prepare the mounting rack or panel, ensuring adequate space for airflow and cable routing.
  • Use shielded cables for analog inputs and outputs to minimize electromagnetic interference.
  • Follow DEIF’s installation guidelines to correctly terminate connections on the terminal blocks.



Maintenance Recommendations:
To ensure optimal performance, perform the following maintenance tasks:



  • Regularly inspect the module for physical damage, loose connections, or signs of corrosion.
  • Clean the enclosure and ventilation slots to prevent dust accumulation, which can affect thermal performance.
  • Monitor the module’s diagnostic LEDs to identify  statuses (e.g., communication errors, power failures).
  • Periodically recalibrate analog inputs using DEIF’s calibration tools to maintain measurement accuracy.
  • Update the firmware to the latest version to access new features and security patches.



For advanced troubleshooting, use DEIF’s PICUS software to analyze real-time data, configure parameters, and generate diagnostic reports. In case of hardware failure, replace the module with a spare unit and contact DEIF’s technical support for repair or replacement.

IPM-1

IPM-1

Product Guarantee

Chengdu Sunshine XiHe Electric Co., LTD is a leading industrial control solutions provider with 17 years of expertise in distributing high-quality automation components. As an authorized supplier of DEIF products, we guarantee the authenticity and reliability of the DEIF IPM-1. All units are rigorously tested and come with a 1-year warranty covering defects in materials or workmanship.



Our company maintains a large inventory of new and obsolete industrial control parts, including the DEIF IPM-1, to meet urgent customer needs. With direct access to DEIF’s global supply chain, we ensure fast delivery and competitive pricing. For technical support or product inquiries, contact us via Whatsapp:+86 18859254943 .E-mail :sales@ygplc.com.Our team of certified engineers is available to assist with installation, configuration, and troubleshooting.



Choose the DEIF IPM-1 from Chengdu Sunshine XiHe Electric Co., LTD for a robust, flexible, and future-proof power management solution backed by industry-leading support.
