Sale!

DATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

Original price was: $5,700.00.Current price is: $5,515.00.

The DATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422 Converter Module is a high-performance industrial communication device designed to bridge legacy RS-232 systems with modern RS-485/422 networks.
Product Model:ICP232.2-5V 029.361114
Manufacturer:DATEL
Product Type:RS-232 to RS-485/422 Converter Module
Input Voltage:5V DC ±10%
Power Consumption:<50 mA

Category: Brand:

Description

Product OverviewDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

The DATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422 Converter Module is a high-performance industrial communication device designed to bridge legacy RS-232 systems with modern RS-485/422 networks. As part of DATEL’s ICP series, this module delivers reliable signal conversion and extended communication capabilities for industrial automation, process control, and remote monitoring applications.



Engineered for robustness, the ICP232.2-5V 029.361114 features optocoupled isolation to protect against voltage spikes and electromagnetic interference (EMI), ensuring stable data transmission in harsh industrial environments. It supports bi-directional data conversion between RS-232 and RS-485/422 protocols, with a baud rate range of 300–115,200 bps to accommodate diverse communication requirements. The module’s 5V DC power input and compact form factor (3.5 x 2 inches) make it ideal for space-constrained installations, while its IP20-rated enclosure provides basic protection against dust and solid particles.



In automation systems, the ICP232.2-5V 029.361114 acts as a critical interface for integrating legacy equipment, such as PLCs, HMIs, and sensors, into modern distributed control systems (DCS). Its half-duplex RS-485 and full-duplex RS-422 modes enable multi-drop network configurations, supporting up to 32 nodes on a single bus. This versatility allows for seamless integration in applications requiring long-distance communication (up to 1,200 meters) or high-speed data transfer, enhancing operational efficiency and system scalability.

Technical SpecificationsDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

Parameter Name Parameter Value
Product Model ICP232.2-5V 029.361114
Manufacturer DATEL
Product Type RS-232 to RS-485/422 Converter Module
Input Voltage 5V DC ±10%
Power Consumption <50 mA
Communication Protocol RS-232, RS-485 (half-duplex), RS-422 (full-duplex)
Baud Rate Range 300–115,200 bps
Isolation Optocoupled (2.5 kVrms)
Node Capacity Up to 32 nodes (RS-485)
Max Transmission Distance 1,200 meters (RS-485)
Physical Dimensions 3.5 x 2 inches
Weight 50 g
Operating Temperature -20°C to +70°C
Humidity 5–95% non-condensing
Protection Rating IP20
DATEL ICP232.2-5V 029.361114

DATEL ICP232.2-5V 029.361114

Key Features and AdvantagesDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

Optocoupled Isolation: The ICP232.2-5V 029.361114 incorporates 2.5 kVrms optocoupled isolation to protect connected devices from ground loops and voltage transients, ensuring reliable operation in electrically noisy environments. This feature is critical for applications where equipment failure could lead to costly downtime.



Dual Protocol Support: With simultaneous RS-232 and RS-485/422 connectivity, the module enables seamless integration of legacy systems with modern industrial networks. Its half-duplex RS-485 mode supports multi-drop configurations, while full-duplex RS-422 mode ensures high-speed, bidirectional data transfer for demanding applications like SCADA systems.



Wide Baud Rate Compatibility: The module’s 300–115,200 bps baud rate range accommodates a broad spectrum of industrial devices, from slow-speed sensors to high-performance PLCs. This flexibility reduces the need for multiple converters, simplifying system design and lowering costs.



Compact Design: Measuring just 3.5 x 2 inches, the ICP232.2-5V 029.361114 fits easily into standard control panels or DIN rail-mounted enclosures. Its lightweight construction (50 g) and plug-and-play operation minimize installation complexity, making it suitable for retrofitting existing systems.



Extended Temperature Range: Rated for operation from -20°C to +70°C, the module withstands extreme industrial environments, including outdoor installations and high-temperature processing facilities. This durability ensures consistent performance in challenging conditions.

DATEL ICP232.2-5V 029.361114

DATEL ICP232.2-5V 029.361114

Application AreasDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

The DATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422 Converter Module is widely used in industries requiring reliable serial communication:



  • Manufacturing: Integrates legacy PLCs and HMIs with modern production line controllers, enabling real-time data exchange for quality control and process optimization.
  • Oil & Gas: Facilitates long-distance communication between field sensors and central control systems in offshore platforms and refineries, ensuring compliance with safety and environmental standards.
  • Power Generation: Connects turbine control systems and distributed generators to grid management platforms, supporting efficient energy distribution and grid synchronization.
  • Water Treatment: Bridges RS-232-based water quality monitors with RS-485 networks, enabling remote monitoring and control of pumps, valves, and filtration systems.
  • Transportation: Integrates RS-232-equipped vehicle diagnostics tools with RS-485-enabled fleet management systems, enhancing maintenance efficiency and reducing downtime.

Related ProductsDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

  1. DATEL ICP232.2-12V: A 12V-powered variant of the ICP232.2-5V 029.361114, suitable for applications with higher voltage requirements.
  2. DATEL ICP485.2-5V: A dedicated RS-485 converter module with similar isolation features, ideal for systems requiring multi-drop network configurations.
  3. DATEL ICP232.2-USB: A USB-to-RS-232/485 converter that complements the ICP232.2-5V 029.361114 for PC-based industrial automation setups.
  4. DATEL ICP232.2-GANG: A multi-channel converter supporting up to 8 RS-232 ports, designed for complex industrial control systems.
  5. DATEL ICP232.2-EX: An explosion-proof version certified for use in hazardous environments, ensuring compliance with ATEX and IECEx standards.
  6. DATEL ICP232.2-IP67: A ruggedized converter with IP67 protection, suitable for outdoor or harsh industrial applications.
  7. DATEL ICP232.2-5V 029.361114

    DATEL ICP232.2-5V 029.361114

    DATEL ICP232.2-ISO: A fully isolated converter with dual power supplies, offering enhanced protection for mission-critical systems.

Installation and MaintenanceDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

Installation Preparation:
Before installing the ICP232.2-5V 029.361114, verify the power supply matches the 5V DC input requirement. Clean the mounting surface and ensure proper grounding to minimize EMI. Connect the RS-232 cable to the DB9 female connector and the RS-485/422 cable to the terminal block, following DATEL’s wiring guidelines. Configure the baud rate and protocol settings using the dip switches on the module’s faceplate.



Maintenance Recommendations:



  • Routine Checks: Inspect the module quarterly for loose connections or signs of physical damage. Clean the enclosure with a dry cloth to prevent dust accumulation.
  • Signal Integrity Testing: Periodically verify data transmission using DATEL’s ICPComm software, ensuring error-free communication across the network.
  • Environmental Monitoring: Monitor ambient temperature and humidity to ensure they remain within the -20°C to +70°C and 5–95% non-condensing ranges.
  • Firmware Updates: Check DATEL’s official website for firmware updates to access new features and bug fixes, particularly for compatibility with emerging industrial protocols.
    DATEL ICP232.2-5V 029.361114

    DATEL ICP232.2-5V 029.361114

Product WarrantyDATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422

We provide a 12-month quality warranty for the DATEL ICP232.2-5V 029.361114 RS-232 to RS-485/422 Converter Module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.



With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to enhance your industrial communication infrastructure with the ICP232.2-5V 029.361114 converter module.



Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
