Description

Product Overview

Technical Specifications

Parameter Name	Parameter Value
Product Model	CS-TX3-3.81X2.54-64TW
Manufacturer	Eaton
Product Type	Dual-Row Terminal Block
Input Voltage	24–48V DC
Current Rating	10A per pole
Terminal Spacing	3.81mm (horizontal), 2.54mm (vertical)
Wire Range	AWG 22–14
Termination Type	Screw-clamp
Mounting Type	DIN rail (35mm)
Physical Dimensions	120 x 50 x 35mm
Weight	280g
Operating Temperature	-20°C to +60°C
Humidity	5–95% non-condensing
Protection Rating	IP20

CS-TX3-3. 81X2.54-64TW

Key Features and Advantages

Wide Compatibility: The CS-TX3-3.81X2.54-64TW supports a broad range of wire sizes (AWG 22–14) and integrates seamlessly with Eaton’s PLC modules, signal conditioners, and communication gateways, ensuring compatibility with diverse automation architectures.

CS-TX3-3. 81X2.54-64TW

Application Areas

• Manufacturing: Powers conveyor belts, robotics, and assembly lines by distributing power and signals to motors, sensors, and actuators.
• Power Generation: Connects control systems in gas/steam turbines and substations, ensuring stable operation of generators and grid infrastructure.
• Oil & Gas: Supports field devices in offshore platforms and refineries, including pressure transmitters, solenoid valves, and safety interlocks.
• Water Treatment: Manages power distribution for pumps, filtration systems, and wastewater treatment plants, ensuring compliance with environmental standards.
• Transportation: Integrates with railway signaling systems and electric vehicle charging stations, providing secure connections for critical infrastructure.

Related Products

1. CS-TX3-3.81X2.54-32TW: A smaller variant with 32 terminals, suitable for applications requiring fewer connections.
2. CS-TX3-5.08X5.08-64TW: Features larger terminal spacing (5.08mm) for high-current applications (up to 16A per pole).
3. Eaton 9533000000 Din Rail Mounting Kit: Includes clips and brackets for secure installation of CS-TX3 terminal blocks.
4. Eaton 9533000001 Marking Strips: Color-coded labels for easy wire identification in complex control panels.
5. Eaton 9533000002 Transparent Covers: Protects terminals from dust and accidental contact while allowing visual inspection.
6. Eaton 9533000003 Test Points: Optional accessories for voltage measurement without disconnecting wires.
7. Eaton 9533000004 Jumpers: Pre-cut connectors for quick parallel wiring between terminals.
8. Eaton 9533000005 Earth Terminals: Dedicated grounding terminals for safety-critical applications.

Installation and Maintenance

Installation Preparation:
Before installing the CS-TX3-3.81X2.54-64TW, verify the input voltage matches the system requirements (24–48V DC). Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the terminal block with the rail and secure it using the provided mounting clips. Strip wires to 8–10mm and insert them into the screw-clamp terminals, tightening to 0.5–0.8N·m torque. Use Eaton’s 9533000001 marking strips to label wires for easy identification.E-mail :sales@ygplc.com.

CS-TX3-3. 81X2.54-64TW

• Routine Inspections: Quarterly checks for loose connections, corrosion, or overheating. Tighten screws if necessary, ensuring torque specifications are met.
• Environmental Cleaning: Wipe the terminal block with a dry cloth to remove dust and debris, preventing insulation degradation.
• Cover Replacement: If the transparent cover becomes cracked or yellowed, replace it with Eaton’s 9533000002 to maintain IP20 protection.
• Wire Integrity: Inspect wires for fraying or oxidation. Replace damaged wires immediately to avoid signal loss or short circuits.
